pcl::PolarTransform Class Reference

In-place transformation to polar coordinates. More...

#include <PolarTransform.h>

+ Inheritance diagram for pcl::PolarTransform:

Public Member Functions

 PolarTransform (const PolarTransform &)=default

 PolarTransform (PixelInterpolation &p)

- Public Member Functions inherited from pcl::PolarTransformBase
 PolarTransformBase (const PolarTransformBase &)=default

 PolarTransformBase (PixelInterpolation &p)

float FinalRotation () const

void GetNewSizes (int &w, int &h) const override

float InitialRotation () const

void SetFinalRotation (float angle)

void SetInitialRotation (float angle)

void SetRotationRange (float initialAngle, float finalAngle)

- Public Member Functions inherited from pcl::InterpolatingGeometricTransformation
 InterpolatingGeometricTransformation (const InterpolatingGeometricTransformation &)=default

 InterpolatingGeometricTransformation (InterpolatingGeometricTransformation &&x)

 InterpolatingGeometricTransformation (PixelInterpolation &p)

void DisableUnclippedInterpolation (bool disable=true)

void EnableUnclippedInterpolation (bool enable=true)

PixelInterpolationInterpolation ()

const PixelInterpolationInterpolation () const

InterpolatingGeometricTransformationoperator= (const InterpolatingGeometricTransformation &)=default

InterpolatingGeometricTransformationoperator= (InterpolatingGeometricTransformation &&x)

void SetInterpolation (PixelInterpolation &p)

bool UsingUnclippedInterpolation () const

- Public Member Functions inherited from pcl::GeometricTransformation
 GeometricTransformation ()=default

 GeometricTransformation (const GeometricTransformation &)=default

 GeometricTransformation (GeometricTransformation &&)=default

 ~GeometricTransformation () override

GeometricTransformationoperator= (const GeometricTransformation &)=default

GeometricTransformationoperator= (GeometricTransformation &&)=default

- Public Member Functions inherited from pcl::ImageTransformation
 ImageTransformation ()=default

 ImageTransformation (const ImageTransformation &)=default

virtual ~ImageTransformation ()

template<class P >
GenericImage< P > & operator>> (GenericImage< P > &image) const

ImageVariantoperator>> (ImageVariant &image) const

- Public Member Functions inherited from pcl::ParallelProcess
 ParallelProcess ()=default

 ParallelProcess (const ParallelProcess &)=default

virtual ~ParallelProcess ()

void DisableParallelProcessing (bool disable=true) noexcept

void EnableParallelProcessing (bool enable=true, int maxProcessors=0) noexcept

bool IsParallelProcessingEnabled () const noexcept

int MaxProcessors () const noexcept

ParallelProcessoperator= (const ParallelProcess &)=default

void SetMaxProcessors (int maxProcessors) noexcept

void Swap (ParallelProcess &process) noexcept


Protected Member Functions

void Apply (pcl::DImage &) const override

void Apply (pcl::Image &) const override

void Apply (pcl::UInt16Image &) const override

void Apply (pcl::UInt32Image &) const override

void Apply (pcl::UInt8Image &) const override

- Protected Member Functions inherited from pcl::ImageTransformation
virtual void Apply (pcl::ComplexImage &image) const

virtual void Apply (pcl::DComplexImage &image) const


Additional Inherited Members

- Static Public Member Functions inherited from pcl::GeometricTransformation
template<class P >
static void ApplyGammaExponentCorrection (typename P::sample *samples, size_type length, double gamma, AbstractImage::ThreadData &threadData, int maxProcessors=PCL_MAX_PROCESSORS)

template<class P >
static void ApplyInverseGammaExponentCorrection (typename P::sample *samples, size_type length, double gamma, AbstractImage::ThreadData &threadData, int maxProcessors=PCL_MAX_PROCESSORS)

template<class P >
static void ApplyInverseSRGBGammaCorrection (typename P::sample *samples, size_type length, AbstractImage::ThreadData &threadData, int maxProcessors=PCL_MAX_PROCESSORS)

template<class P >
static void ApplySRGBGammaCorrection (typename P::sample *samples, size_type length, AbstractImage::ThreadData &threadData, int maxProcessors=PCL_MAX_PROCESSORS)


Detailed Description

This class implements a Cartesian to polar coordinate transform with the following properties:

  • The origin of polar coordinates is located at the geometric center of the image.
  • Rotation angles are encoded linearly on the vertical axis, growing from bottom to top.
  • Distance to the origin is encoded linearly on the horizontal axis, growing from left to right.
  • Transform pixels mapped outside the source image (in Cartesian coordinates) are set to zero.
See also
LogPolarTransform, PolarTransformBase, FFTRegistrationEngine

Definition at line 203 of file PolarTransform.h.

Constructor & Destructor Documentation

◆ PolarTransform() [1/2]

pcl::PolarTransform::PolarTransform ( PixelInterpolation p)
inline

Constructs a PolarTransform object using the specified pixel interpolation p. The referenced interpolation object p must remain valid while this PolarTransform object exists.

Definition at line 212 of file PolarTransform.h.

◆ PolarTransform() [2/2]

pcl::PolarTransform::PolarTransform ( const PolarTransform )
default

Copy constructor.

Member Function Documentation

◆ Apply() [1/5]

void pcl::PolarTransform::Apply ( pcl::DImage image) const
overrideprotectedvirtual

Applies this transformation to a 64-bit floating point image.

Reimplemented from pcl::ImageTransformation.

◆ Apply() [2/5]

void pcl::PolarTransform::Apply ( pcl::Image image) const
overrideprotectedvirtual

Applies this transformation to a 32-bit floating point image.

Reimplemented from pcl::ImageTransformation.

◆ Apply() [3/5]

void pcl::PolarTransform::Apply ( pcl::UInt16Image image) const
overrideprotectedvirtual

Applies this transformation to a 16-bit unsigned integer image.

Reimplemented from pcl::ImageTransformation.

◆ Apply() [4/5]

void pcl::PolarTransform::Apply ( pcl::UInt32Image image) const
overrideprotectedvirtual

Applies this transformation to a 32-bit unsigned integer image.

Reimplemented from pcl::ImageTransformation.

◆ Apply() [5/5]

void pcl::PolarTransform::Apply ( pcl::UInt8Image image) const
overrideprotectedvirtual

Applies this transformation to an 8-bit unsigned integer image.

Reimplemented from pcl::ImageTransformation.


The documentation for this class was generated from the following file:
