Image rotation algorithm. More...

#include <Rotation.h>

Inheritance diagram for pcl::Rotation:

Public Member Functions
	Rotation (const Rotation &)=default

	Rotation (PixelInterpolation &p, double angle, const DPoint &center)

	Rotation (PixelInterpolation &p, double angle=0, double cx=0, double cy=0)

double	Angle () const

DPoint	Center () const

double	CenterX () const

double	CenterY () const

void	DisableUnclippedRotation (bool disable=true)

void	EnableUnclippedRotation (bool enable=true)

const DVector &	FillValues () const

void	GetNewSizes (int &width, int &height) const override

bool	IsUnclipped () const

void	SetAngle (double rads)

void	SetCenter (const DPoint &center)

void	SetCenter (double xc, double yc)

void	SetFillValues (const DVector &fillValues)

Public Member Functions inherited from pcl::InterpolatingGeometricTransformation
	InterpolatingGeometricTransformation (const InterpolatingGeometricTransformation &)=default

	InterpolatingGeometricTransformation (InterpolatingGeometricTransformation &&x)

	InterpolatingGeometricTransformation (PixelInterpolation &p)

void	DisableUnclippedInterpolation (bool disable=true)

void	EnableUnclippedInterpolation (bool enable=true)

PixelInterpolation &	Interpolation ()

const PixelInterpolation &	Interpolation () const

InterpolatingGeometricTransformation &	operator= (const InterpolatingGeometricTransformation &)=default

InterpolatingGeometricTransformation &	operator= (InterpolatingGeometricTransformation &&x)

void	SetInterpolation (PixelInterpolation &p)

bool	UsingUnclippedInterpolation () const

Public Member Functions inherited from pcl::GeometricTransformation
	GeometricTransformation ()=default

	GeometricTransformation (const GeometricTransformation &)=default

	GeometricTransformation (GeometricTransformation &&)=default

	~GeometricTransformation () override

GeometricTransformation &	operator= (const GeometricTransformation &)=default

GeometricTransformation &	operator= (GeometricTransformation &&)=default

Public Member Functions inherited from pcl::ImageTransformation
	ImageTransformation ()=default

	ImageTransformation (const ImageTransformation &)=default

virtual	~ImageTransformation ()

template<class P >
GenericImage< P > &	operator>> (GenericImage< P > &image) const

ImageVariant &	operator>> (ImageVariant &image) const

Public Member Functions inherited from pcl::ParallelProcess
	ParallelProcess ()=default

	ParallelProcess (const ParallelProcess &)=default

virtual	~ParallelProcess ()

void	DisableParallelProcessing (bool disable=true) noexcept

void	EnableParallelProcessing (bool enable=true, int maxProcessors=0) noexcept

bool	IsParallelProcessingEnabled () const noexcept

int	MaxProcessors () const noexcept

ParallelProcess &	operator= (const ParallelProcess &)=default

void	SetMaxProcessors (int maxProcessors) noexcept

void	Swap (ParallelProcess &process) noexcept

Protected Member Functions
void	Apply (pcl::DImage &) const override

void	Apply (pcl::Image &) const override

void	Apply (pcl::UInt16Image &) const override

void	Apply (pcl::UInt32Image &) const override

void	Apply (pcl::UInt8Image &) const override

Protected Member Functions inherited from pcl::ImageTransformation
virtual void	Apply (pcl::ComplexImage &image) const

virtual void	Apply (pcl::DComplexImage &image) const

Additional Inherited Members
Static Public Member Functions inherited from pcl::GeometricTransformation
template<class P >
static void	ApplyGammaExponentCorrection (typename P::sample *samples, size_type length, double gamma, AbstractImage::ThreadData &threadData, int maxProcessors=PCL_MAX_PROCESSORS)

template<class P >
static void	ApplyInverseGammaExponentCorrection (typename P::sample *samples, size_type length, double gamma, AbstractImage::ThreadData &threadData, int maxProcessors=PCL_MAX_PROCESSORS)

template<class P >
static void	ApplyInverseSRGBGammaCorrection (typename P::sample *samples, size_type length, AbstractImage::ThreadData &threadData, int maxProcessors=PCL_MAX_PROCESSORS)

template<class P >
static void	ApplySRGBGammaCorrection (typename P::sample *samples, size_type length, AbstractImage::ThreadData &threadData, int maxProcessors=PCL_MAX_PROCESSORS)

Detailed Description

TODO: Write a detailed description for Rotation

Definition at line 74 of file Rotation.h.

Constructor & Destructor Documentation

◆ Rotation() [1/3]

pcl::Rotation::Rotation	(	PixelInterpolation &	p,
		double	angle = `0`,
		double	cx = `0`,
		double	cy = `0`
	)

inline

Constructs a new Rotation object.

Parameters

p	Reference to a pixel interpolation, which must remain valid while this object exists.
angle	Rotation angle in radians
cx	Horizontal coordinate of the center of rotation, measured in pixels in the image coordinate system.
cy	Vertical coordinate of the center of rotation, measured in pixels in the image coordinate system.

Definition at line 93 of file Rotation.h.

◆ Rotation() [2/3]

pcl::Rotation::Rotation	(	PixelInterpolation &	p,
		double	angle,
		const DPoint &	center
	)

inline

Constructs a new Rotation object.

Parameters

p	Reference to a pixel interpolation, which must remain valid while this object exists.
angle	Rotation angle in radians
center	Coordinates of the center of rotation, measured in pixels in the image coordinate system.

Definition at line 111 of file Rotation.h.

◆ Rotation() [3/3]

pcl::Rotation::Rotation ( const Rotation & )

default

Copy constructor.

Member Function Documentation

◆ Angle()

double pcl::Rotation::Angle ( ) const

inline

Returns the rotation angle in radians.

Definition at line 126 of file Rotation.h.

◆ Apply() [1/5]

void pcl::Rotation::Apply ( pcl::DImage & image ) const

overrideprotectedvirtual

Applies this transformation to a 64-bit floating point image.

Reimplemented from pcl::ImageTransformation.

◆ Apply() [2/5]

void pcl::Rotation::Apply ( pcl::Image & image ) const

overrideprotectedvirtual

Applies this transformation to a 32-bit floating point image.

Reimplemented from pcl::ImageTransformation.

◆ Apply() [3/5]

void pcl::Rotation::Apply ( pcl::UInt16Image & image ) const

overrideprotectedvirtual

Applies this transformation to a 16-bit unsigned integer image.

Reimplemented from pcl::ImageTransformation.

◆ Apply() [4/5]

void pcl::Rotation::Apply ( pcl::UInt32Image & image ) const

overrideprotectedvirtual

Applies this transformation to a 32-bit unsigned integer image.

Reimplemented from pcl::ImageTransformation.

◆ Apply() [5/5]

void pcl::Rotation::Apply ( pcl::UInt8Image & image ) const

overrideprotectedvirtual

Applies this transformation to an 8-bit unsigned integer image.

Reimplemented from pcl::ImageTransformation.

◆ Center()

DPoint pcl::Rotation::Center ( ) const

inline

Returns the center of rotation. The returned point coordinates are measured in pixels in the image coordinate system.

Definition at line 143 of file Rotation.h.

◆ CenterX()

double pcl::Rotation::CenterX ( ) const

inline

Returns the horizontal coordinate of the center of rotation, measured in pixels in the image coordinate system.

Definition at line 152 of file Rotation.h.

◆ CenterY()

double pcl::Rotation::CenterY ( ) const

inline

Returns the vertical coordinate of the center of rotation, measured in pixels in the image coordinate system.

Definition at line 161 of file Rotation.h.

◆ DisableUnclippedRotation()

void pcl::Rotation::DisableUnclippedRotation ( bool disable = true )

inline

Disables unclipped rotations for this object. See IsUnclipped() for information on unclipped rotations.

Definition at line 213 of file Rotation.h.

◆ EnableUnclippedRotation()

void pcl::Rotation::EnableUnclippedRotation ( bool enable = true )

inline

Enables unclipped rotations for this object. See IsUnclipped() for information on unclipped rotations.

Definition at line 204 of file Rotation.h.

◆ FillValues()

const DVector& pcl::Rotation::FillValues ( ) const

inline

Returns the current vector of per-channel filling values for uncovered image regions.

See the documentation for SetFillValues() for more information.

Definition at line 224 of file Rotation.h.

◆ GetNewSizes()

void pcl::Rotation::GetNewSizes	(	int &	width,
		int &	height
	)		const

overridevirtual

Predicts transformed image dimensions.

Parameters

[in,out]	width	Reference to a variable whose value is a horizontal dimension in pixels (width). On output, it will receive the predicted horizontal dimension after the transformation.
[in,out]	height	Reference to a variable whose value is a vertical dimension in pixels (height). On output, it will receive the predicted vertical dimension after the transformation.

Note: This is a pure virtual member function that must be reimplemented in every derived class.

Implements pcl::GeometricTransformation.

◆ IsUnclipped()

bool pcl::Rotation::IsUnclipped ( ) const

inline

Returns true iff this transformation will preserve the entire target image without clipping any pixels after rotating it.

An unclipped rotation ignores the specified rotation center coordinates (see CenterX() and CenterY(), as well as the class constructor) and rotates images with respect to their geometric centers. To accommodate all rotated pixels in the result, the unclipped rotated image will always be bigger than the original, except for the trivial cases of rotations by 0 and 180 degrees.

Definition at line 195 of file Rotation.h.

◆ SetAngle()

void pcl::Rotation::SetAngle ( double rads )

inline

Sets the rotation angle in radians.

Definition at line 134 of file Rotation.h.

◆ SetCenter() [1/2]

void pcl::Rotation::SetCenter ( const DPoint & center )

inline

Sets the center of rotation. The specified center point coordinates must be expressed in pixels in the image coordinate system.

Definition at line 170 of file Rotation.h.

◆ SetCenter() [2/2]

void pcl::Rotation::SetCenter	(	double	xc,
		double	yc
	)

inline

Sets the center of rotation to the specified coordinates xc and yc, which must be expressed in pixels in the image coordinate system.

Definition at line 179 of file Rotation.h.

◆ SetFillValues()

void pcl::Rotation::SetFillValues ( const DVector & fillValues )

inline

Sets a vector of per-channel filling values for uncovered image regions.

Uncovered regions result when an image is rotated by non-orthogonal angles.

By default, there are no filling values defined (and hence the returned vector is empty by default). When the Rotation instance is executed and a filling value is not defined for a channel of the target image, uncovered regions are filled with the minimum sample value in the native range of the image (usually zero).

Definition at line 241 of file Rotation.h.

The documentation for this class was generated from the following file:

Rotation.h
