pcl::SeparableMedianFilter Class Reference

A two-dimensional separable filter that approximates a median filter. More...

#include <SeparableMedianFilter.h>

Inheritance diagram for pcl::SeparableMedianFilter:

Public Member Functions
	SeparableMedianFilter (const SeparableMedianFilter &)=default
	SeparableMedianFilter (int size=3)
	~SeparableMedianFilter () override
void	SetSize (int size)
int	Size () const
Public Member Functions inherited from pcl::ImageTransformation
	ImageTransformation ()=default
	ImageTransformation (const ImageTransformation &)=default
virtual	~ImageTransformation ()
template<class P >
GenericImage< P > &	operator>> (GenericImage< P > &image) const
ImageVariant &	operator>> (ImageVariant &image) const
Public Member Functions inherited from pcl::ParallelProcess
	ParallelProcess ()=default
	ParallelProcess (const ParallelProcess &)=default
virtual	~ParallelProcess ()
void	DisableParallelProcessing (bool disable=true) noexcept
void	EnableParallelProcessing (bool enable=true, int maxProcessors=0) noexcept
bool	IsParallelProcessingEnabled () const noexcept
int	MaxProcessors () const noexcept
ParallelProcess &	operator= (const ParallelProcess &)=default
void	SetMaxProcessors (int maxProcessors) noexcept
void	Swap (ParallelProcess &process) noexcept

Protected Member Functions
void	Apply (pcl::DImage &) const override
void	Apply (pcl::Image &) const override
void	Apply (pcl::UInt16Image &) const override
void	Apply (pcl::UInt32Image &) const override
void	Apply (pcl::UInt8Image &) const override
Protected Member Functions inherited from pcl::ImageTransformation
virtual void	Apply (pcl::ComplexImage &image) const
virtual void	Apply (pcl::DComplexImage &image) const

Detailed Description

TODO: Write a detailed description for SeparableMedianFilter.

Definition at line 75 of file SeparableMedianFilter.h.

Constructor & Destructor Documentation

SeparableMedianFilter() [1/2]

pcl::SeparableMedianFilter::SeparableMedianFilter ( int  size = 3 )

inline

Constructs a SeparableMedianFilter object with the specified size.

Parameters

size	Size of the separable median filter in pixels. Must be an odd integer >= 3 (3, 5, 7, ...).

Definition at line 86 of file SeparableMedianFilter.h.

SeparableMedianFilter() [2/2]

pcl::SeparableMedianFilter::SeparableMedianFilter ( const SeparableMedianFilter &  )

default

Copy constructor.

~SeparableMedianFilter()

pcl::SeparableMedianFilter::~SeparableMedianFilter ( )

inlineoverride

Destroys a SeparableMedianFilter object.

Definition at line 100 of file SeparableMedianFilter.h.

Member Function Documentation

Apply() [1/5]

void pcl::SeparableMedianFilter::Apply ( pcl::DImage &  image ) const

overrideprotectedvirtual

Applies this transformation to a 64-bit floating point image.

Reimplemented from pcl::ImageTransformation.

Apply() [2/5]

void pcl::SeparableMedianFilter::Apply ( pcl::Image &  image ) const

overrideprotectedvirtual

Applies this transformation to a 32-bit floating point image.

Reimplemented from pcl::ImageTransformation.

Apply() [3/5]

void pcl::SeparableMedianFilter::Apply ( pcl::UInt16Image &  image ) const

overrideprotectedvirtual

Applies this transformation to a 16-bit unsigned integer image.

Reimplemented from pcl::ImageTransformation.

Apply() [4/5]

void pcl::SeparableMedianFilter::Apply ( pcl::UInt32Image &  image ) const

overrideprotectedvirtual

Applies this transformation to a 32-bit unsigned integer image.

Reimplemented from pcl::ImageTransformation.

Apply() [5/5]

void pcl::SeparableMedianFilter::Apply ( pcl::UInt8Image &  image ) const

overrideprotectedvirtual

Applies this transformation to an 8-bit unsigned integer image.

Reimplemented from pcl::ImageTransformation.

SetSize()

void pcl::SeparableMedianFilter::SetSize ( int  size )

inline

Sets a new size in pixels for this separable median filter object. The specified size must be an odd integer > 3 (3, 5, 7, ...).

Definition at line 116 of file SeparableMedianFilter.h.

Size()

int pcl::SeparableMedianFilter::Size ( ) const

inline

Returns the current size in pixels of this separable median filter.

Definition at line 107 of file SeparableMedianFilter.h.

---

The documentation for this class was generated from the following file:

• SeparableMedianFilter.h
