Client-side interface to a PixInsight ImageView control. More...

#include <ImageView.h>

Inheritance diagram for pcl::ImageView:

Public Types
using	background_brush = BackgroundBrush::value_type

using	display_channel = DisplayChannel::value_type

using	gui_mode = ImageMode::value_type

using	scroll_event_handler = void(Control::*)(ImageView &sender, int dx, int dy)

using	transparency_mode = TransparencyMode::value_type

Public Types inherited from pcl::ScrollBox
using	pos_event_handler = void(Control::*)(ScrollBox &sender, int pos)

using	range_event_handler = void(Control::*)(ScrollBox &sender, int minValue, int maxValue)

Public Types inherited from pcl::Frame
using	style = FrameStyle::value_type

Public Types inherited from pcl::Control
using	child_event_handler = void(Control::*)(Control &sender, Control &child)

using	close_event_handler = void(Control::*)(Control &sender, bool &allowClose)

using	event_handler = void(Control::*)(Control &sender)

using	file_drag_event_handler = void(Control::*)(Control &sender, const pcl::Point &pos, const StringList &files, unsigned modifiers, bool &wantsFiles)

using	file_drop_event_handler = void(Control::*)(Control &sender, const pcl::Point &pos, const StringList &files, unsigned modifiers)

using	keyboard_event_handler = void(Control::*)(Control &sender, int key, unsigned modifiers, bool &wantsKey)

using	mouse_button_event_handler = void(Control::*)(Control &sender, const pcl::Point &pos, int button, unsigned buttons, unsigned modifiers)

using	mouse_event_handler = void(Control::*)(Control &sender, const pcl::Point &pos, unsigned buttons, unsigned modifiers)

using	mouse_wheel_event_handler = void(Control::*)(Control &sender, const pcl::Point &pos, int delta, unsigned buttons, unsigned modifiers)

using	move_event_handler = void(Control::*)(Control &sender, const pcl::Point &newPos, const pcl::Point &oldPos)

using	paint_event_handler = void(Control::*)(Control &sender, const pcl::Rect &updateRect)

using	resize_event_handler = void(Control::*)(Control &sender, int newWidth, int newHeight, int oldWidth, int oldHeight)

using	view_drag_event_handler = void(Control::*)(Control &sender, const pcl::Point &pos, const View &view, unsigned modifiers, bool &wantsView)

using	view_drop_event_handler = void(Control::*)(Control &sender, const pcl::Point &pos, const View &view, unsigned modifiers)

Public Member Functions
	ImageView (Control &parent=Control::Null(), int width=0, int height=0, int numberOfChannels=1, int bitsPerSample=32, bool floatSample=true, bool color=false)

	~ImageView () override

void	BeginSelection (const Point &p, uint32 flags=0)

void	BeginSelection (int x, int y, uint32 flags=0)

void	CancelSelection ()

void	CommitPendingUpdates ()

int	CurrentAlphaChannel () const

display_channel	CurrentChannel () const

gui_mode	CurrentMode () const

void	DeleteICCProfile ()

void	DisableColorManagement (bool disable=true)

void	DisableGamutCheck (bool disable=true)

void	DisableProofing (bool disable=true)

void	EnableColorManagement (bool=true)

void	EnableGamutCheck (bool=true)

void	EnableProofing (bool=true)

void	EndSelection ()

bool	GetICCProfile (ICCProfile &icc) const

void	GetImageGeometry (int &width, int &height, int &numberOfChannels) const

void	GetRGBWS (RGBColorSystem &rgbws) const

void	GetSampleFormat (int &bitsPerSample, bool &floatSample) const

void	GetViewportSize (int &width, int &height) const

Point	GlobalToViewport (const Point &p) const

Rect	GlobalToViewport (const Rect &r) const

void	GlobalToViewport (int &x, int &y) const

bool	HasPendingUpdates () const

void	HideTransparency ()

ImageVariant	Image () const

Rect	ImageBounds () const

int	ImageHeight () const

void	ImageScalarToViewport (double *d, size_type n) const

double	ImageScalarToViewport (double) const

void	ImageScalarToViewport (int *d, size_type n) const

int	ImageScalarToViewport (int) const

template<typename T >
void	ImageToViewport (Array< GenericPoint< T > > &a) const

template<typename T >
GenericPoint< T >	ImageToViewport (const GenericPoint< T > &p) const

template<typename T >
GenericRectangle< T >	ImageToViewport (const GenericRectangle< T > &r) const

void	ImageToViewport (double &x, double &y) const

void	ImageToViewport (DPoint *p, size_type n) const

void	ImageToViewport (int &x, int &y) const

void	ImageToViewport (Point *p, size_type n) const

int	ImageWidth () const

bool	IsAlphaChannelDisplayed () const

bool	IsColorImage () const

bool	IsColorManagementEnabled () const

bool	IsGamutCheckEnabled () const

bool	IsProofingEnabled () const

bool	IsSelection () const

bool	IsTransparencyVisible () const

void	ModifySelection (const Point &p, uint32 flags=0)

void	ModifySelection (int x, int y, uint32 flags=0)

void	OnScrollViewport (scroll_event_handler handler, Control &receiver)

void	Regenerate ()

void	RegenerateImageRect (const pcl::DRect &r)

void	RegenerateImageRect (double x0, double y0, double x1, double y1)

void	RegenerateViewportRect (const Rect &r)

void	RegenerateViewportRect (int x0, int y0, int x1, int y1)

void	Reset ()

void	SelectChannel (display_channel channel)

Rect	SelectionRect (uint32 *flags=0) const

void	SelectMode (gui_mode mode)

void	SetColorManagementFeatures (bool cmEnabled, bool proofing, bool gamutCheck)

void	SetICCProfile (const ICCProfile &icc)

void	SetICCProfile (const String &filePath)

void	SetRGBWS (const RGBColorSystem &rgbws)

void	SetSampleFormat (int bitsPerSample, bool floatSample)

void	SetTransparencyMode (transparency_mode mode, RGBA color=0)

void	SetViewport (const DPoint &center, int zoom=0)

void	SetViewport (double cx, double cy, int zoom=0)

void	SetViewportPosition (const Point &p)

void	SetViewportPosition (int x, int y)

void	SetZoomFactor (int z)

RGBA	TransparencyColor () const

transparency_mode	TransparencyMode () const

void	UpdateImageRect (const pcl::DRect &r)

void	UpdateImageRect (double x0, double y0, double x1, double y1)

void	UpdateSelection ()

void	UpdateViewport ()

void	UpdateViewportRect (const Rect &r)

void	UpdateViewportRect (int x0, int y0, int x1, int y1)

Bitmap	ViewportBitmap (const Rect &r, uint32 flags=0) const

Bitmap	ViewportBitmap (int x0, int y0, int x1, int y1, uint32 flags=0) const

int	ViewportHeight () const

Point	ViewportPosition () const

void	ViewportScalarToImage (double *d, size_type n) const

double	ViewportScalarToImage (double d) const

void	ViewportScalarToImage (int *d, size_type n) const

template<typename T >
double	ViewportScalarToImage (T d) const

Point	ViewportToGlobal (const Point &p) const

Rect	ViewportToGlobal (const Rect &r) const

void	ViewportToGlobal (int &x, int &y) const

template<typename T >
void	ViewportToImage (Array< GenericPoint< T > > &a) const

template<typename T >
DPoint	ViewportToImage (const GenericPoint< T > &p) const

template<typename T >
DRect	ViewportToImage (const GenericRectangle< T > &r) const

void	ViewportToImage (double &x, double &y) const

void	ViewportToImage (DPoint *p, size_type n) const

void	ViewportToImage (int &x, int &y) const

void	ViewportToImage (Point *p, size_type n) const

Rect	ViewportUpdateRect () const

int	ViewportWidth () const

int	VisibleViewportHeight () const

Rect	VisibleViewportRect () const

int	VisibleViewportWidth () const

int	ZoomFactor () const

void	ZoomIn ()

void	ZoomOut ()

Public Member Functions inherited from pcl::ScrollBox
	ScrollBox (Control &parent=Control::Null())

	~ScrollBox () override

void	DisableAutoScroll (bool disableHorz=true, bool disableVert=true)

void	DisableHorizontalTracking (bool disableHorz=true)

void	DisableTracking (bool disableHorz=true, bool disableVert=true)

void	DisableVerticalTracking (bool disableVert=true)

void	EnableAutoScroll (bool enableHorz=true, bool enableVert=true)

void	EnableHorizontalTracking (bool enableHorz=true)

void	EnableTracking (bool enableHorz=true, bool enableVert=true)

void	EnableVerticalTracking (bool enableVert=true)

void	GetHorizontalScrollRange (int &minPos, int &maxPos) const

void	GetVerticalScrollRange (int &minPos, int &maxPos) const

void	HideHorizontalScrollBar (bool hide=true)

void	HideScrollBars (bool hideHorz=true, bool hideVert=true)

void	HideVerticalScrollBar (bool hide=true)

int	HorizontalScrollPosition () const

bool	IsHorizontalAutoScrollEnabled () const

bool	IsHorizontalScrollBarVisible () const

bool	IsHorizontalTrackingEnabled () const

bool	IsVerticalAutoScrollEnabled () const

bool	IsVerticalScrollBarVisible () const

bool	IsVerticalTrackingEnabled () const

int	LineHeight () const

int	LineWidth () const

int	MaxHorizontalScrollPosition () const

int	MaxVerticalScrollPosition () const

int	MinHorizontalScrollPosition () const

int	MinVerticalScrollPosition () const

void	OnHorizontalScrollPosUpdated (pos_event_handler handler, Control &receiver)

void	OnHorizontalScrollRangeUpdated (range_event_handler handler, Control &receiver)

void	OnVerticalScrollPosUpdated (pos_event_handler handler, Control &receiver)

void	OnVerticalScrollRangeUpdated (range_event_handler handler, Control &receiver)

int	PageHeight () const

int	PageWidth () const

pcl::Point	ScrollPosition () const

void	SetHorizontalScrollPosition (int horzPos)

void	SetHorizontalScrollRange (int minPos, int maxPos)

void	SetLineHeight (int height)

void	SetLineSize (int width, int height)

void	SetLineWidth (int width)

void	SetPageHeight (int height)

void	SetPageSize (int width, int height)

void	SetPageWidth (int width)

void	SetScrollPosition (const pcl::Point &pos)

void	SetScrollPosition (int horzPos, int vertPos)

void	SetVerticalScrollPosition (int vertPos)

void	SetVerticalScrollRange (int minPos, int maxPos)

void	ShowHorizontalScrollBar (bool show=true)

void	ShowScrollBars (bool showHorz=true, bool showVert=true)

void	ShowVerticalScrollBar (bool show=true)

int	VerticalScrollPosition () const

Control &	Viewport ()

const Control &	Viewport () const

Public Member Functions inherited from pcl::Frame
	Frame (Control &parent=Control::Null())

	~Frame () override

int	BorderWidth () const

int	LineWidth () const

int	ScaledBorderWidth () const

int	ScaledLineWidth () const

void	SetLineWidth (int)

void	SetScaledLineWidth (int width)

void	SetStyle (style)

style	Style () const

Public Member Functions inherited from pcl::Control
	Control (const Control &)=delete

	Control (Control &&)=delete

	Control (Control &parent=Null(), uint32=0)

	~Control () override

void	ActivateRealTimePreview ()

void	ActivateTrackView ()

void	ActivateWindow ()

void	AdjustToContents ()

RGBA	AlternateCanvasColor () const

RGBA	BackgroundColor () const

pcl::Rect	BoundsRect () const

void	BringToFront ()

RGBA	ButtonColor () const

RGBA	ButtonTextColor () const

bool	CanUpdate () const

RGBA	CanvasColor ()

Control &	ChildByPos (const pcl::Point &p) const

Control &	ChildByPos (int x, int y) const

pcl::Rect	ChildrenRect () const

Control &	ChildToFocus () const

void	ClearInfoText ()

int	ClientHeight () const

pcl::Rect	ClientRect () const

int	ClientWidth () const

void	ControlToLocal (const Control &, int &x, int &y) const

pcl::Point	ControlToLocal (const Control &w, const pcl::Point &p) const

pcl::Cursor	Cursor () const

void	DeactivateRealTimePreview ()

void	DeactivateTrackView ()

void	Disable (bool disabled=true)

void	DisableExpansion (bool horzDisable=true, bool vertDisable=true)

void	DisableMouseTracking (bool disable=true)

void	DisableUpdates (bool disable=true)

double	DisplayPixelRatio () const

virtual void	Enable (bool enabled=true)

void	EnableExpansion (bool horzEnable=true, bool vertEnable=true)

void	EnableMouseTracking (bool=true)

void	EnableUpdates (bool enable=true)

void	EnsureLayoutUpdated ()

void	EnsureUnique () override

void	Focus (bool focus=true)

Control &	FocusedChild () const

FocusStyles	FocusStyle () const

pcl::Font	Font () const

RGBA	ForegroundColor () const

int	FrameHeight () const

pcl::Rect	FrameRect () const

int	FrameWidth () const

pcl::Cursor	GetCursor () const

pcl::Font	GetFont () const

void	GetMaxSize (int &w, int &h) const

void	GetMinSize (int &w, int &h) const

void	GetScaledMaxSize (int &w, int &h) const

void	GetScaledMinSize (int &w, int &h) const

pcl::Sizer	GetSizer () const

pcl::Point	GlobalToLocal (const pcl::Point &p) const

void	GlobalToLocal (int &x, int &y) const

int	Height () const

void	Hide ()

RGBA	HighlightColor () const

RGBA	HighlightedTextColor () const

String	InfoText () const

bool	IsActiveWindow () const

bool	IsAncestorOf (const Control &) const

virtual bool	IsEnabled () const

bool	IsFixedHeight () const

bool	IsFixedWidth () const

bool	IsFocused () const

bool	IsHidden () const

bool	IsHorizontalExpansionEnabled () const

bool	IsMaximized () const

bool	IsMinimized () const

bool	IsModal () const

bool	IsMouseTrackingEnabled () const

bool	IsRealTimePreviewActive () const

bool	IsTrackViewActive () const

bool	IsUnderMouse () const

bool	IsVerticalExpansionEnabled () const

bool	IsVisible () const

bool	IsWindow () const

void	LocalToControl (const Control &, int &x, int &y) const

pcl::Point	LocalToControl (const Control &w, const pcl::Point &p) const

pcl::Point	LocalToGlobal (const pcl::Point &p) const

void	LocalToGlobal (int &x, int &y) const

pcl::Point	LocalToParent (const pcl::Point &p) const

void	LocalToParent (int &x, int &y) const

int	LogicalPixelsToPhysical (int size) const

int	LogicalPixelsToResource (int size) const

int	MaxHeight () const

int	MaxWidth () const

int	MinHeight () const

int	MinWidth () const

void	Move (const pcl::Point &p)

void	Move (int x, int y)

Control &	NextSiblingToFocus () const

void	OnChildCreate (child_event_handler, Control &)

void	OnChildDestroy (child_event_handler, Control &)

void	OnClose (close_event_handler, Control &)

void	OnDestroy (event_handler, Control &)

void	OnEnter (event_handler, Control &)

void	OnFileDrag (file_drag_event_handler, Control &)

void	OnFileDrop (file_drop_event_handler, Control &)

void	OnGetFocus (event_handler, Control &)

void	OnHide (event_handler, Control &)

void	OnKeyPress (keyboard_event_handler, Control &)

void	OnKeyRelease (keyboard_event_handler, Control &)

void	OnLeave (event_handler, Control &)

void	OnLoseFocus (event_handler, Control &)

void	OnMouseDoubleClick (mouse_event_handler, Control &)

void	OnMouseMove (mouse_event_handler, Control &)

void	OnMousePress (mouse_button_event_handler, Control &)

void	OnMouseRelease (mouse_button_event_handler, Control &)

void	OnMouseWheel (mouse_wheel_event_handler, Control &)

void	OnMove (move_event_handler, Control &)

void	OnPaint (paint_event_handler, Control &)

void	OnResize (resize_event_handler, Control &)

void	OnShow (event_handler, Control &)

void	OnViewDrag (view_drag_event_handler, Control &)

void	OnViewDrop (view_drop_event_handler, Control &)

Control &	operator= (const Control &)=delete

Control &	operator= (Control &&)=delete

Control &	Parent () const

pcl::Point	ParentToLocal (const pcl::Point &p) const

void	ParentToLocal (int &x, int &y) const

int	PhysicalPixelsToLogical (int size) const

pcl::Point	Position () const

void	Repaint ()

void	Repaint (const pcl::Rect &r)

void	Repaint (int x0, int y0, int x1, int y1)

void	Resize (int w, int h)

double	ResourcePixelRatio () const

int	ResourcePixelsToLogical (int size) const

void	Restyle ()

Point	ScaledCursorHotSpot (const Point &hotSpot) const

Point	ScaledCursorHotSpot (int xHot, int yHot) const

int	ScaledMaxHeight () const

int	ScaledMaxWidth () const

int	ScaledMinHeight () const

int	ScaledMinWidth () const

template<class R >
String	ScaledResource (R resource) const

template<class S >
String	ScaledStyleSheet (S cssCode, int fontDPI=0) const

void	Scroll (const pcl::Point &d)

void	Scroll (const pcl::Point &d, const pcl::Rect &r)

void	Scroll (int dx, int dy)

void	Scroll (int dx, int dy, int x0, int y0, int x1, int y1)

void	SendToBack ()

void	SetAlternateCanvasColor (RGBA)

void	SetBackgroundColor (RGBA)

void	SetButtonColor (RGBA)

void	SetButtonTextColor (RGBA)

void	SetCanvasColor (RGBA)

void	SetChildToFocus (Control &)

void	SetClientRect (const pcl::Rect &r)

void	SetClientRect (int x0, int y0, int x1, int y1)

void	SetCursor (const pcl::Cursor &)

void	SetCursorToParent ()

void	SetFixedHeight ()

void	SetFixedHeight (int h)

void	SetFixedSize ()

void	SetFixedSize (int w, int h)

void	SetFixedWidth ()

void	SetFixedWidth (int w)

void	SetFocusStyle (FocusStyles)

void	SetFont (const pcl::Font &)

void	SetForegroundColor (RGBA)

void	SetHighlightColor (RGBA)

void	SetHighlightedTextColor (RGBA)

void	SetInfoText (const String &)

void	SetMaxHeight ()

void	SetMaxHeight (int h)

void	SetMaxSize ()

void	SetMaxSize (int w, int h)

void	SetMaxWidth ()

void	SetMaxWidth (int w)

void	SetMinHeight ()

void	SetMinHeight (int h)

void	SetMinSize ()

void	SetMinSize (int w, int h)

void	SetMinWidth ()

void	SetMinWidth (int w)

void	SetNextSiblingToFocus (Control &)

void	SetParent (Control &)

void	SetRealTimePreviewActive (bool=true)

void	SetScaledFixedHeight (int h)

void	SetScaledFixedSize (int w, int h)

void	SetScaledFixedWidth (int w)

void	SetScaledMaxHeight (int h)

void	SetScaledMaxSize (int w, int h)

void	SetScaledMaxWidth (int w)

void	SetScaledMinHeight (int h)

void	SetScaledMinSize (int w, int h)

void	SetScaledMinWidth (int w)

void	SetSizer (pcl::Sizer &)

void	SetStyleSheet (const String &css)

void	SetTextColor (RGBA)

void	SetToolTip (const String &)

void	SetTrackViewActive (bool=true)

void	SetVariableHeight ()

void	SetVariableSize ()

void	SetVariableWidth ()

void	SetVisible (bool visible)

void	SetWindowOpacity (double)

void	SetWindowTitle (const String &)

void	Show ()

pcl::Sizer	Sizer () const

void	StackUnder (Control &)

String	StyleSheet () const

RGBA	TextColor () const

String	ToolTip () const

void	Unfocus ()

void	Update ()

void	Update (const pcl::Rect &r)

void	Update (int x0, int y0, int x1, int y1)

pcl::Rect	VisibleRect () const

int	Width () const

Control &	Window () const

double	WindowOpacity () const

String	WindowTitle () const

int	X () const

int	Y () const

Public Member Functions inherited from pcl::UIObject
virtual	~UIObject () noexcept(false)

bool	IsAlias () const

bool	IsGarbage () const

bool	IsNull () const

bool	IsSameObject (const UIObject &o) const

bool	IsUnique () const

String	ObjectId () const

IsoString	ObjectType () const

bool	operator< (const UIObject &o) const

bool	operator== (const UIObject &o) const

size_type	RefCount () const

void	SetObjectId (const String &id)

Additional Inherited Members
Static Public Member Functions inherited from pcl::Control
static void	HideToolTip ()

static Control &	Null ()

static void	ShowToolTip (const Point &pos, const String &text, const Control &control=Control::Null(), const Rect &rect=Rect(0))

static void	ShowToolTip (int x, int y, const String &text, const Control &control=Control::Null(), const Rect &rect=Rect(0))

static String	ToolTipText ()

Static Public Member Functions inherited from pcl::UIObject
static UIObject &	Null ()

Protected Member Functions inherited from pcl::UIObject
	UIObject ()=default

	UIObject (const UIObject &x)

	UIObject (UIObject &&x)

UIObject &	operator= (const UIObject &x)

UIObject &	operator= (UIObject &&x)

Detailed Description

TODO: Write a detailed description for ImageView.

See also: ImageWindow

Definition at line 79 of file ImageView.h.

Member Typedef Documentation

◆ background_brush

using pcl::ImageView::background_brush = BackgroundBrush::value_type

Represents a transparency background brush supported by the PixInsight core application. Valid transparency brushes are defined in the BackgroundBrush namespace.

Definition at line 101 of file ImageView.h.

◆ display_channel

using pcl::ImageView::display_channel = DisplayChannel::value_type

Represents a display image channel supported by the PixInsight core application. Valid display channels and components are defined in the DisplayChannel namespace.

Definition at line 94 of file ImageView.h.

◆ gui_mode

using pcl::ImageView::gui_mode = ImageMode::value_type

Represents a GUI working mode. Valid modes are defined in the ImageMode namespace.

Definition at line 87 of file ImageView.h.

◆ transparency_mode

using pcl::ImageView::transparency_mode = TransparencyMode::value_type

Represents a transparency rendering mode supported by the PixInsight core application. Valid transparency rendering modes are defined in the TransparencyMode namespace.

Definition at line 108 of file ImageView.h.

Constructor & Destructor Documentation

◆ ImageView()

pcl::ImageView::ImageView	(	Control &	parent = `Control::Null()`,
		int	width = `0`,
		int	height = `0`,
		int	numberOfChannels = `1`,
		int	bitsPerSample = `32`,
		bool	floatSample = `true`,
		bool	color = `false`
	)

Creates a new ImageView control with the specified image parameters.

Parameters

parent	Parent control of the newly created ImageView.
width	Image width in pixels. Must be >= 0. There is no specific upper limit. If zero is specified, the ImageView will contain an empty image. The default value is zero.
height	Image width in pixels. Must be >= 0. There is no specific upper limit. If zero is specified, the ImageView will contain an empty image. The default value is zero.
numberOfChannels	Number of channels in the image. Must be >= 0. There is no specific upper limit. If zero is specified, the ImageView will contain an empty image. If a value > 0 is specified, it should not be less than the number of nominal channels: 1 for grayscale images, 3 for color images. Channels in excess of nominal channels are generated as alpha channels. The default value is one.
bitsPerSample	Number of bits per sample. Supported values are 8, 16 and 32 for integer images; 32 and 64 for floating point images. The default value is 32.
floatSample	True to create a floating point image; false to create an integer image. The default value is true.
color	True to create an RGB color image; false to create a grayscale image. The default value is false.

If not empty, all nominal and alpha channels of the newly created image are initialized with zero pixel sample values (black pixels).

◆ ~ImageView()

pcl::ImageView::~ImageView ( )

inlineoverride

Destroys an ImageView control.

Definition at line 151 of file ImageView.h.

Member Function Documentation

◆ BeginSelection() [1/2]

void pcl::ImageView::BeginSelection	(	const Point &	p,
		uint32	flags = `0`
	)

inline

Begins a new interactive rectangular selection procedure on the viewport of this ImageView control.

Calling this function is equivalent to:

BeginSelection( p.x, p.y, flags );

pcl::ImageView::BeginSelection

void BeginSelection(const Point &p, uint32 flags=0)

Definition: ImageView.h:1296

Definition at line 1296 of file ImageView.h.

References pcl::GenericPoint< T >::x, and pcl::GenericPoint< T >::y.

◆ BeginSelection() [2/2]

void pcl::ImageView::BeginSelection	(	int	x,
		int	y,
		uint32	flags = `0`
	)

Starts a new interactive rectangular selection procedure on the viewport of this ImageView control.

Parameters

x,y	Image coordinates of the starting point of a new rectangular selection.
flags	Currently not used; reserved for future extensions of PCL. Must be set to zero.

Interfaces typically use BeginSelection() in response to an OnMousePress event to start a rectangular selection. ModifySelection() is then called from an OnMouseMove event handler, and the final selection coordinates are obtained by calling SelectionRect() from an OnMouseRelease event handler.

◆ CancelSelection()

void pcl::ImageView::CancelSelection ( )

Aborts the current interactive selection procedure.

◆ CommitPendingUpdates()

void pcl::ImageView::CommitPendingUpdates ( )

Executes all pending viewport update requests for this ImageView control.

Viewport update requests are not executed immediately by the core PixInsight application. For the sake of performance, The GUI tries to optimize screen updates by performing the minimum possible redrawing work.

This means that update requests are placed on a queue, waiting while the main GUI thread is busy or until a sufficiently large update region becomes available.

With this function, an interface can force the immediate screen update for all pending update viewport regions. If multiple update regions are pending, the core application will still minimize the required drawing work by grouping all of them into the minimum possible amount of larger regions.

◆ CurrentAlphaChannel()

int pcl::ImageView::CurrentAlphaChannel ( ) const

inline

Returns the alpha channel index displayed for the image in this ImageView control. If the current display channel does not correspond to an alpha channel, a negative integer value is returned.

Alpha channel indices are relative to the first alpha channel in an image. For example, the first alpha channel is always indexed as alpha channel #0, and so on.

Definition at line 487 of file ImageView.h.

◆ CurrentChannel()

display_channel pcl::ImageView::CurrentChannel ( ) const

Returns the current display channel for this ImageView control.

The returned value can be identified with the symbolic constants defined int the DisplayChannel namespace.

◆ CurrentMode()

gui_mode pcl::ImageView::CurrentMode ( ) const

Returns the current GUI working mode for this ImageView control.

The returned value can be identified with the symbolic constants defined in the ImageMode namespace.

◆ DeleteICCProfile()

void pcl::ImageView::DeleteICCProfile ( )

Causes the image in this ImageView control to be associated with the default ICC profile globally defined in the PixInsight core application.

If this control has its own associated ICC profile, this funtion destroys it and frees its allocated space.

If this control is visible and has color management enabled, its screen rendition is updated immediately after calling this function.

◆ DisableColorManagement()

void pcl::ImageView::DisableColorManagement ( bool disable = true )

inline

Disables color management for the image in this ImageView control.

See the documentation for EnableColorManagement() for additional information on color management in PixInsight.

If this control is visible, its screen rendition is updated immediately after calling this function.

Definition at line 291 of file ImageView.h.

◆ DisableGamutCheck()

void pcl::ImageView::DisableGamutCheck ( bool disable = true )

inline

Disables the gamut check proofing feature for the image in this ImageView control.

See the documentation for EnableGamutCheck() for additional information on the gamut check color proofing feature.

If this control is visible, has color management enabled, and has soft proofing enabled, its screen rendition is updated immediately after calling this function. If color proofing is disabled, calling this function has no effect.

Definition at line 365 of file ImageView.h.

◆ DisableProofing()

void pcl::ImageView::DisableProofing ( bool disable = true )

inline

Disables soft-proofing for the image in this ImageView control.

See the documentation for EnableProofing() for additional information on color proofing.

If this control is visible and has color management enabled, its screen rendition is updated immediately after calling this function.

Definition at line 326 of file ImageView.h.

◆ EnableColorManagement()

void pcl::ImageView::EnableColorManagement ( bool = true )

Enables color management for the image in this ImageView control.

Color management uses ICC profiles for the image in this control (either a profile associated with the image or a global profile) and the monitor device to control how the image is rendered on the screen. Color management transformations are applied to yield a visual representation that takes into account the actual meaning of numerical pixel sample values, considering the chromatic responses of the screen and of the devices and color spaces that have originated the image.

If color management is disabled for an image, its pixel sample values are sent directly to the screen, avoiding ICC profile transformations. This improves output performance, but may give a false representation of the image on the screen.

If this control is visible, its screen rendition is updated immediately after calling this function.

◆ EnableGamutCheck()

void pcl::ImageView::EnableGamutCheck ( bool = true )

Enables the gamut check proofing feature for the image in this ImageView control.

The gamut check feature represents out-of-gamut colors (i.e., colors that are not defined in the color space of the image) with a special color (selectable via global color management preferences) for quick visual detection.

If this control is visible, has color management enabled, and has soft proofing enabled, its screen rendition is updated immediately after calling this function. If color proofing is disabled, calling this function has no effect.

◆ EnableProofing()

void pcl::ImageView::EnableProofing ( bool = true )

Enables soft-proofing for the image in this ImageView control.

Color proofing is used to emulate an output device (usually a printer) on the screen. Proofing requires three ICC profiles: the image profile (either an embedded profile or the default profile), the monitor profile, and a proofing profile that describes the emulated device. Color proofing is useful to preview the final printed result without rendering images to physical media.

If this control is visible and has color management enabled, its screen rendition is updated immediately after calling this function.

◆ EndSelection()

void pcl::ImageView::EndSelection ( )

Terminates the current interactive selection procedure.

◆ GetICCProfile()

bool pcl::ImageView::GetICCProfile ( ICCProfile & icc ) const

Obtains a copy of the current ICC profile associated with the image in this ImageView control.

Parameters

[out] icc Reference to an object where a copy of the current ICC profile will be stored.

◆ GetImageGeometry()

void pcl::ImageView::GetImageGeometry	(	int &	width,
		int &	height,
		int &	numberOfChannels
	)		const

Copies the width and height in pixels, and the number of channels of the image in this ImageView control to the specified variables.

◆ GetRGBWS()

void pcl::ImageView::GetRGBWS ( RGBColorSystem & rgbws ) const

Obtains a copy of the RGB working space (RGBWS) associated with the image owned by this ImageView control.

Parameters

[out] rgbws Reference to an object where the parameters of the current RGBWS will be copied.

◆ GetSampleFormat()

void pcl::ImageView::GetSampleFormat	(	int &	bitsPerSample,
		bool &	floatSample
	)		const

Retrieves the pixel sample data format used by the image owned by this ImageView control.

Parameters

[out]	bitsPerSample	On output, will be equal to the number of bits per sample used by the image. Can be 8, 16 or 32 for an integer image; 32 or 64 for a floating point image.
[out]	floatSample	On output, will be true if the image uses floating point samples; false if it uses integer samples.

◆ GetViewportSize()

void pcl::ImageView::GetViewportSize	(	int &	width,
		int &	height
	)		const

Gets the current sizes of the viewport in this ImageView control.

Parameters

[out]	width	Reference to a variable where the viewport width in pixels will be stored.
[out]	height	Reference to a variable where the viewport height in pixels will be stored.

The provided sizes represent the entire image in this control, as represented on its viewport after applying the current zoom factor. Viewport sizes can also be thought of as the available navigation ranges in an ImageView control.

◆ GlobalToViewport() [1/3]

Point pcl::ImageView::GlobalToViewport ( const Point & p ) const

inline

Converts a point p in the global coordinate system to the viewport coordinate system. Returns a point with the resulting viewport coordinates.

Definition at line 1062 of file ImageView.h.

References pcl::GenericPoint< T >::x, and pcl::GenericPoint< T >::y.

◆ GlobalToViewport() [2/3]

Rect pcl::ImageView::GlobalToViewport ( const Rect & r ) const

inline

Converts a rectangle r in the global coordinate system to the viewport coordinate system. Returns a rectangle with the resulting viewport coordinates.

Definition at line 1074 of file ImageView.h.

References pcl::GenericRectangle< T >::x0, pcl::GenericRectangle< T >::x1, pcl::GenericRectangle< T >::y0, and pcl::GenericRectangle< T >::y1.

◆ GlobalToViewport() [3/3]

void pcl::ImageView::GlobalToViewport	(	int &	x,
		int &	y
	)		const

Converts the specified x and y integer coordinates from the global coordinate system to the viewport coordinate system.

The converted viewport coordinates are rounded to the nearest integers.

◆ HasPendingUpdates()

bool pcl::ImageView::HasPendingUpdates ( ) const

Returns true iff there are pending viewport updates for this ImageView control.

◆ HideTransparency()

void pcl::ImageView::HideTransparency ( )

inline

Disables transparency renditions for this ImageView control.

Calling this function is equivalent to:

SetTransparencyMode( pcl::TransparencyMode::Hide );

pcl::ImageView::SetTransparencyMode

void SetTransparencyMode(transparency_mode mode, RGBA color=0)

Definition at line 559 of file ImageView.h.

◆ Image()

ImageVariant pcl::ImageView::Image ( ) const

Returns an ImageVariant instance that transports the image owned by this ImageView control.

The returned ImageVariant object transports a shared image. A shared image is a managed alias for an actual image living in the PixInsight core application. This is because a GUI control is also a managed object.

◆ ImageBounds()

Rect pcl::ImageView::ImageBounds ( ) const

inline

Returns the bounding rectangle of the image in this ImageView control. The upper left corner of the returned rectangle (x0, y0) is always (0,0). The lower right corner coordinates (x1, y1) correspond to the width and height of the image.

Definition at line 200 of file ImageView.h.

◆ ImageHeight()

int pcl::ImageView::ImageHeight ( ) const

inline

Returns the height in pixels of the image in this ImageView control.

Definition at line 189 of file ImageView.h.

◆ ImageScalarToViewport() [1/4]

void pcl::ImageView::ImageScalarToViewport	(	double *	d,
		size_type	n
	)		const

Converts a set of real floating-point scalars from the image coordinate system to the viewport coordinate system.

Parameters

d	Pointer to the first element in the array of scalars that will be converted from image coordinates to viewport coordinates.
n	Number of scalars in the p array.

◆ ImageScalarToViewport() [2/4]

double pcl::ImageView::ImageScalarToViewport ( double ) const

Converts a real floating-point scalar d in the image coordinate system to the viewport coordinate system. Returns the resulting scalar in viewport coordinates.

◆ ImageScalarToViewport() [3/4]

void pcl::ImageView::ImageScalarToViewport	(	int *	d,
		size_type	n
	)		const

Converts a set of integer scalars from the image coordinate system to the viewport coordinate system.

Parameters

d	Pointer to the first element in the array of scalars that will be converted from image coordinates to viewport coordinates.
n	Number of scalars in the p array.

Converted scalars in viewport coordinates are rounded to the nearest integers.

◆ ImageScalarToViewport() [4/4]

int pcl::ImageView::ImageScalarToViewport ( int ) const

Converts an integer scalar d in the image coordinate system to the viewport coordinate system. Returns the resulting scalar in viewport coordinates.

The resulting scalar in viewport coordinates is rounded to the nearest integer.

◆ ImageToViewport() [1/7]

template<typename T >

void pcl::ImageView::ImageToViewport ( Array< GenericPoint< T > > & a ) const

inline

Converts a set of points in a dynamic array from the image coordinate system to the viewport coordinate system.

Parameters

a	Reference to a dynamic array of points that will be converted from image coordinates to viewport coordinates.

Definition at line 968 of file ImageView.h.

◆ ImageToViewport() [2/7]

template<typename T >

GenericPoint<T> pcl::ImageView::ImageToViewport ( const GenericPoint< T > & p ) const

inline

Converts a point p in the image coordinate system to the viewport coordinate system. Returns a point with the resulting viewport coordinates.

If the template argument T corresponds to an integer type, the converted viewport coordinates in the resulting point are rounded to the nearest integers.

Definition at line 911 of file ImageView.h.

References pcl::GenericPoint< T >::x, and pcl::GenericPoint< T >::y.

◆ ImageToViewport() [3/7]

template<typename T >

GenericRectangle<T> pcl::ImageView::ImageToViewport ( const GenericRectangle< T > & r ) const

inline

Converts a rectangle r in the image coordinate system to the viewport coordinate system. Returns a rectangle with the resulting viewport coordinates.

If the template argument T corresponds to an integer type, the converted viewport coordinates in the resulting rectangle are rounded to the nearest integers.

Definition at line 928 of file ImageView.h.

References pcl::GenericRectangle< T >::x0, pcl::GenericRectangle< T >::x1, pcl::GenericRectangle< T >::y0, and pcl::GenericRectangle< T >::y1.

◆ ImageToViewport() [4/7]

void pcl::ImageView::ImageToViewport	(	double &	x,
		double &	y
	)		const

Converts the specified x and y real floating-point coordinates from the image coordinate system to the viewport coordinate system.

◆ ImageToViewport() [5/7]

void pcl::ImageView::ImageToViewport	(	DPoint *	p,
		size_type	n
	)		const

Converts a set of real floating-point points from the image coordinate system to the viewport coordinate system.

Parameters

p	Pointer to the first point in the array of points that will be converted from image coordinates to viewport coordinates.
n	Number of points in the p array.

◆ ImageToViewport() [6/7]

void pcl::ImageView::ImageToViewport	(	int &	x,
		int &	y
	)		const

Converts the specified x and y integer coordinates from the image coordinate system to the viewport coordinate system.

The converted viewport coordinates are rounded to the nearest integers.

◆ ImageToViewport() [7/7]

void pcl::ImageView::ImageToViewport	(	Point *	p,
		size_type	n
	)		const

Converts a set of integer points from the image coordinate system to the viewport coordinate system.

Parameters

p	Pointer to the first point in the array of points that will be converted from image coordinates to viewport coordinates.
n	Number of points in the p array.

Converted point viewport coordinates are rounded to the nearest integers.

◆ ImageWidth()

int pcl::ImageView::ImageWidth ( ) const

inline

Returns the width in pixels of the image in this ImageView control.

Definition at line 181 of file ImageView.h.

◆ IsAlphaChannelDisplayed()

bool pcl::ImageView::IsAlphaChannelDisplayed ( ) const

inline

Returns true iff the current display channel for this ImageView control corresponds to an alpha channel of the image.

Definition at line 473 of file ImageView.h.

◆ IsColorImage()

bool pcl::ImageView::IsColorImage ( ) const

Returns true iff this ImageView control holds a color image, false if it is a grayscale image.

◆ IsColorManagementEnabled()

bool pcl::ImageView::IsColorManagementEnabled ( ) const

Returns true iff color management is active for the image in this ImageView control.

◆ IsGamutCheckEnabled()

bool pcl::ImageView::IsGamutCheckEnabled ( ) const

Returns true iff the gamut check soft-proofing feature is currently enabled for the image in this ImageView control.

◆ IsProofingEnabled()

bool pcl::ImageView::IsProofingEnabled ( ) const

Returns true iff soft-proofing is currently enabled for the image in this ImageView control.

◆ IsSelection()

bool pcl::ImageView::IsSelection ( ) const

Returns true iff an interactive selection procedure is currently active on the viewport of this ImageView control.

◆ IsTransparencyVisible()

bool pcl::ImageView::IsTransparencyVisible ( ) const

inline

Returns true iff transparent image areas are currently visible for this ImageView control.

Transparencies are visible if the current rendering mode is not TransparencyMode::Hide.

Definition at line 533 of file ImageView.h.

◆ ModifySelection() [1/2]

void pcl::ImageView::ModifySelection	(	const Point &	p,
		uint32	flags = `0`
	)

inline

Updates an ongoing interactive rectangular selection procedure on the viewport of this ImageView control.

Calling this function is equivalent to:

ModifySelection( p.x, p.y, flags );

pcl::ImageView::ModifySelection

void ModifySelection(const Point &p, uint32 flags=0)

Definition: ImageView.h:1327

Definition at line 1327 of file ImageView.h.

References pcl::GenericPoint< T >::x, and pcl::GenericPoint< T >::y.

◆ ModifySelection() [2/2]

void pcl::ImageView::ModifySelection	(	int	x,
		int	y,
		uint32	flags = `0`
	)

Updates an ongoing interactive rectangular selection procedure on the viewport of this ImageView control.

Parameters

x,y	Image coordinates to update the current rectangular selection. The selection rectangle is defined by this position and the starting position defined in the call to BeginSelection() that originated the current selection procedure.
flags	Currently not used; reserved for future extensions of PCL. Must be set to zero.

◆ Regenerate()

void pcl::ImageView::Regenerate ( )

Regenerates the screen rendition for the visible viewport region in this ImageView control.

◆ RegenerateImageRect() [1/2]

void pcl::ImageView::RegenerateImageRect ( const pcl::DRect & r )

inline

Regenerates the screen rendition for a rectangular region of the viewport, specified in image coordinates.

Calling this function is equivalent to:

RegenerateImageRect( r.x0, r.y0, r.x1, r.y1 );

pcl::ImageView::RegenerateImageRect

void RegenerateImageRect(const pcl::DRect &r)

Definition: ImageView.h:1137

Definition at line 1137 of file ImageView.h.

References pcl::GenericRectangle< T >::x0, pcl::GenericRectangle< T >::x1, pcl::GenericRectangle< T >::y0, and pcl::GenericRectangle< T >::y1.

◆ RegenerateImageRect() [2/2]

void pcl::ImageView::RegenerateImageRect	(	double	x0,
		double	y0,
		double	x1,
		double	y1
	)

Regenerates the screen rendition for a rectangular region of the viewport, specified in image coordinates.

Parameters

x0,y0	Image coordinates (horizontal, vertical) of the upper left corner of the regenerated region.
x1,y1	Image coordinates (horizontal, vertical) of the lower right corner of the regenerated region.

The specified region will be updated on the screen. Only the visible portion of the specified region will be regenerated and updated, that is, its intersection with the visible viewport region.

◆ RegenerateViewportRect() [1/2]

void pcl::ImageView::RegenerateViewportRect ( const Rect & r )

inline

Regenerates the screen rendition for a rectangular region of the viewport, specified in viewport coordinates.

Calling this function is equivalent to:

RegenerateViewportRect( r.x0, r.y0, r.x1, r.y1 );

pcl::ImageView::RegenerateViewportRect

void RegenerateViewportRect(const Rect &r)

Definition: ImageView.h:1108

Definition at line 1108 of file ImageView.h.

References pcl::GenericRectangle< T >::x0, pcl::GenericRectangle< T >::x1, pcl::GenericRectangle< T >::y0, and pcl::GenericRectangle< T >::y1.

◆ RegenerateViewportRect() [2/2]

void pcl::ImageView::RegenerateViewportRect	(	int	x0,
		int	y0,
		int	x1,
		int	y1
	)

Regenerates the screen rendition for a rectangular region of the viewport, specified in viewport coordinates.

Parameters

x0,y0	Viewport coordinates (horizontal, vertical) of the upper left corner of the regenerated region.
x1,y1	Viewport coordinates (horizontal, vertical) of the lower right corner of the regenerated region.

The specified region will be updated on the screen. Only the visible portion of the specified region will be regenerated and updated, that is, its intersection with the visible viewport region.

◆ Reset()

void pcl::ImageView::Reset ( )

inline

Causes a complete regeneration of the whole viewport and its associated UI resources.

Calling this function may be necessary to force a regeneration after changing the geometry of the image owned by this ImageView control.

Definition at line 1089 of file ImageView.h.

◆ SelectChannel()

void pcl::ImageView::SelectChannel ( display_channel channel )

Selects the current display channel for this ImageView control.

Parameters

channel Specifies the new display channel. Supported display channels are enumerated in the DisplayChannel namespace.

Not all display channels are valid for all images in all contexts. For example, if the image in the current view is a grayscale image, the only valid display channels are the combined RGB/K channel (DisplayChannel::RGBK) and, if the image has n alpha channels, values in the range DisplayChannel::Alpha to DisplayChannel::Alpha+n-1. If an invalid display channel is specified, this function is simply ignored.

◆ SelectionRect()

Rect pcl::ImageView::SelectionRect ( uint32 * flags = 0 ) const

Returns the current rectangular selection in image coordinates.

Parameters

flags Currently not used; reserved for future extensions of PCL. Must be set to zero.

Before calling this function, a rectangular selection procedure should have been started with BeginSelection().

◆ SelectMode()

void pcl::ImageView::SelectMode ( gui_mode mode )

Sets the current GUI working mode for this ImageView control.

Parameters

mode	Specifies the new GUI mode. Supported modes are identified through symbolic constants defined in the ImageMode namespace.

Preview edition and dynamic modes are not valid for ImageView. The only valid GUI working modes are:

ImageMode::Readout
ImageMode::ZoomIn
ImageMode::ZoomOut
ImageMode::Pan
ImageMode::Center

◆ SetColorManagementFeatures()

void pcl::ImageView::SetColorManagementFeatures	(	bool	cmEnabled,
		bool	proofing,
		bool	gamutCheck
	)

Allows enabling or disabling all color management features at once for this ImageView control.

Parameters

cmEnabled	Enables (if true) or disables (if false) color management for the image in this control.
proofing	Enables (if true) or disables (if false) soft-proofing for the image in this control.
gamutCheck	Enables (if true) or disables (if false) the gamut check proofing feature. The state of this argument has no meaning if the proofing parameter is false.

If this control is visible, its screen rendition is updated immediately after calling this function.

◆ SetICCProfile() [1/2]

void pcl::ImageView::SetICCProfile ( const ICCProfile & icc )

Sets the current ICC profile for the image in this ImageView control as a copy of an existing ICC profile.

Parameters

icc	Reference to an object that will be used to set the current ICC profile.

If this control is visible and has color management enabled, its screen rendition is updated immediately after calling this function.

◆ SetICCProfile() [2/2]

void pcl::ImageView::SetICCProfile ( const String & filePath )

Sets the current ICC profile for the image in this ImageView control as a copy of an ICC profile loaded from a disk file.

Parameters

filePath A file path specification to an ICC profile that will be loaded and copied to the ICC profile of the image.

If this control is visible and has color management enabled, its screen rendition is updated immediately after calling this function.

◆ SetRGBWS()

void pcl::ImageView::SetRGBWS ( const RGBColorSystem & rgbws )

Sets the RGB working space (RGBWS) for the image owned by this ImageView control.

Parameters

rgbws Reference to a RGBWS that will be associated with the image owned by this object.

◆ SetSampleFormat()

void pcl::ImageView::SetSampleFormat	(	int	bitsPerSample,
		bool	floatSample
	)

Converts the image owned by this ImageView control to the specified sample data format.

Parameters

bitsPerSample	Number of bits per sample. Can be 8, 16 or 32 for an integer image; 32 or 64 for a floating point image.
floatSample	True to transform the image to a floating point data format; false to transform the image to an integer data format.

This function does nothing if the image in this control already has the specified sample data format.

◆ SetTransparencyMode()

void pcl::ImageView::SetTransparencyMode	(	transparency_mode	mode,
		RGBA	color = `0`
	)

Sets the current transparency rendering mode for this ImageView control.

Parameters

mode	Specifies the new mode that will be used to render transparent regions of images. Supported transparency modes are identified through symbolic constants defined in the TransparencyMode namespace.
color	New color that will be used when the transparency mode is TransparencyMode::Color. If zero is specified (the default value), the current color will not be changed.

◆ SetViewport() [1/2]

void pcl::ImageView::SetViewport	(	const DPoint &	center,
		int	zoom = `0`
	)

inline

Sets new viewport central location and zoom factor for this ImageView control.

Calling this function is equivalent to:

SetViewport( center.x, center.y, int );

pcl::ImageView::SetViewport

void SetViewport(double cx, double cy, int zoom=0)

See the documentation for SetViewport( double, double, int ).

Definition at line 619 of file ImageView.h.

References pcl::GenericPoint< T >::x, and pcl::GenericPoint< T >::y.

◆ SetViewport() [2/2]

void pcl::ImageView::SetViewport	(	double	cx,
		double	cy,
		int	zoom = `0`
	)

Sets new viewport central location coordinates and zoom factor for this ImageView control.

Parameters

cx,cy	Position (horizontal, vertical) of the new central viewport location in image coordinates.
zoom	New viewport zoom factor. Positive zoom factors are interpreted as magnifying factors; negative zoom factors are reduction factors:

          A zoom factor of -1 should not be used explicitly; it is a
           reserved value for internal use, and there is no guarantee
           that future versions of PCL continue accepting it.

If the specified viewport location cannot correspond to the viewport central position with the specified zoom factor, the nearest image coordinates are always selected automatically. For example, if you pass image coordinates cx=0 and cy=0 as arguments to this function, the GUI will set the viewport center to the necessary image location in order to display the upper left corner of the image just at the upper left corner of the viewport.

If the zoom argument is not specified, the current zoom factor is not changed since the default value of this parameter is zero; see the table above.

If this control is visible, calling this function causes an immediate regeneration of the screen rendition for the visible viewport region.

◆ SetViewportPosition() [1/2]

void pcl::ImageView::SetViewportPosition ( const Point & p )

inline

Sets the viewport position in this ImageView control to the specified position p in viewport coordinates.

Calling this function is equivalent to:

SetViewportPosition( p.x, p.y );

pcl::ImageView::SetViewportPosition

void SetViewportPosition(int x, int y)

Definition at line 732 of file ImageView.h.

References pcl::GenericPoint< T >::x, and pcl::GenericPoint< T >::y.

◆ SetViewportPosition() [2/2]

void pcl::ImageView::SetViewportPosition	(	int	x,
		int	y
	)

Sets the viewport position in this ImageView control to the specified x and y viewport coordinates.

If this control is visible, calling this function causes an immediate regeneration of the screen rendition for the visible viewport region.

◆ SetZoomFactor()

void pcl::ImageView::SetZoomFactor ( int z )

Sets the zoom factor for the viewport of this ImageView control to the specified value z.

To learn how zoom factors are interpreted in PixInsight, see the documentation for SetViewport( double, double, int ).

◆ TransparencyColor()

RGBA pcl::ImageView::TransparencyColor ( ) const

Returns the color used in this ImageView control to render transparent image regions, when the transparency mode is TransparencyMode::Color.

The returned color is an AARRGGBB value. The alpha value is always 0xff, since the transparency background cannot be transparent.

◆ TransparencyMode()

transparency_mode pcl::ImageView::TransparencyMode ( ) const

Returns the current transparency rendering mode for this ImageView control.

Supported transparency modes are defined in the TransparencyMode namespace.

◆ UpdateImageRect() [1/2]

void pcl::ImageView::UpdateImageRect ( const pcl::DRect & r )

inline

Requests a screen update for a rectangular region of the viewport, specified in image coordinates.

Calling this function is equivalent to:

UpdateImageRect( r.x0, r.y0, r.x1, r.y1 );

pcl::ImageView::UpdateImageRect

void UpdateImageRect(const pcl::DRect &r)

Definition: ImageView.h:1201

Definition at line 1201 of file ImageView.h.

References pcl::GenericRectangle< T >::x0, pcl::GenericRectangle< T >::x1, pcl::GenericRectangle< T >::y0, and pcl::GenericRectangle< T >::y1.

◆ UpdateImageRect() [2/2]

void pcl::ImageView::UpdateImageRect	(	double	x0,
		double	y0,
		double	x1,
		double	y1
	)

Requests a screen update for a rectangular region of the viewport, specified in image coordinates.

Parameters

x0,y0	Image coordinates (horizontal, vertical) of the upper left corner of the update region.
x1,y1	Image coordinates (horizontal, vertical) of the lower right corner of the update region.

The specified region will be updated on the screen. Only the visible portion of the specified region will be updated, that is, its intersection with the visible viewport region in the image coordinate system.

◆ UpdateSelection()

void pcl::ImageView::UpdateSelection ( )

Requests a screen viewport update for the current rectangular selection.

◆ UpdateViewport()

void pcl::ImageView::UpdateViewport ( )

Requests a screen update for the entire visible viewport region in this ImageView control.

◆ UpdateViewportRect() [1/2]

void pcl::ImageView::UpdateViewportRect ( const Rect & r )

inline

Requests a screen update for a rectangular region of the viewport, specified in viewport coordinates.

Calling this function is equivalent to:

UpdateViewportRect( r.x0, r.y0, r.x1, r.y1 );

pcl::ImageView::UpdateViewportRect

void UpdateViewportRect(const Rect &r)

Definition: ImageView.h:1172

Definition at line 1172 of file ImageView.h.

References pcl::GenericRectangle< T >::x0, pcl::GenericRectangle< T >::x1, pcl::GenericRectangle< T >::y0, and pcl::GenericRectangle< T >::y1.

◆ UpdateViewportRect() [2/2]

void pcl::ImageView::UpdateViewportRect	(	int	x0,
		int	y0,
		int	x1,
		int	y1
	)

Requests a screen update for a rectangular region of the viewport, specified in viewport coordinates.

Parameters

x0,y0	Viewport coordinates (horizontal, vertical) of the upper left corner of the update region.
x1,y1	Viewport coordinates (horizontal, vertical) of the lower right corner of the update region.

The specified region will be updated on the screen. Only the visible portion of the specified region will be updated, that is, its intersection with the visible viewport region.

◆ ViewportBitmap() [1/2]

Bitmap pcl::ImageView::ViewportBitmap	(	const Rect &	r,
		uint32	flags = `0`
	)		const

inline

Returns a RGBA bitmap with a screen rendition of a viewport region of this ImageView control.

Calling this function is equivalent to:

ViewportBitmap( r.x0, r.y0, r.x1, r.y1, flags );

pcl::ImageView::ViewportBitmap

Bitmap ViewportBitmap(const Rect &r, uint32 flags=0) const

Definition: ImageView.h:1264

Definition at line 1264 of file ImageView.h.

References pcl::GenericRectangle< T >::x0, pcl::GenericRectangle< T >::x1, pcl::GenericRectangle< T >::y0, and pcl::GenericRectangle< T >::y1.

◆ ViewportBitmap() [2/2]

Bitmap pcl::ImageView::ViewportBitmap	(	int	x0,
		int	y0,
		int	x1,
		int	y1,
		uint32	flags = `0`
	)		const

Returns a RGBA bitmap with a screen rendition of a viewport region of this ImageView control.

Parameters

x0,y0	Viewport coordinates (horizontal, vertical) of the upper left corner of the source viewport region.
x1,y1	Viewport coordinates (horizontal, vertical) of the lower right corner of the source viewport region.
flags	Currently not used; reserved for future extensions of PCL. Must be set to zero.

The returned bitmap will contain a screen rendition for the specified source region of the image in this ImageView control. It will be magnified or reduced according to the current zoom factor.

◆ ViewportHeight()

int pcl::ImageView::ViewportHeight ( ) const

inline

Gets the current height of the viewport in this ImageView control.

Definition at line 697 of file ImageView.h.

◆ ViewportPosition()

Point pcl::ImageView::ViewportPosition ( ) const

Returns the current viewport position in this ImageView control.

The viewport position corresponds to the viewport coordinates of the upper left corner of the visible viewport region. These coordinates can be negative if the represented image is smaller than the size of the viewport control, that is, when the extended viewport space is visible around the screen rendition of the image.

◆ ViewportScalarToImage() [1/4]

void pcl::ImageView::ViewportScalarToImage	(	double *	d,
		size_type	n
	)		const

Converts a set of real floating-point scalars from the viewport coordinate system to the image coordinate system.

Parameters

d	Pointer to the first element in the array of scalars that will be converted from viewport coordinates to image coordinates.
n	Number of scalars in the p array.

◆ ViewportScalarToImage() [2/4]

double pcl::ImageView::ViewportScalarToImage ( double d ) const

Converts a scalar d in the viewport coordinate system to the image coordinate system. Returns the resulting floating point real scalar in image coordinates.

◆ ViewportScalarToImage() [3/4]

void pcl::ImageView::ViewportScalarToImage	(	int *	d,
		size_type	n
	)		const

Converts a set of integer scalars from the viewport coordinate system to the image coordinate system.

Parameters

d	Pointer to the first element in the array of scalars that will be converted from viewport coordinates to image coordinates.
n	Number of scalars in the p array.

Converted scalars in image coordinates are rounded to the nearest integers.

◆ ViewportScalarToImage() [4/4]

template<typename T >

double pcl::ImageView::ViewportScalarToImage ( T d ) const

inline

Converts a scalar d in the viewport coordinate system to the image coordinate system. Returns the resulting floating point real scalar in image coordinates.

Definition at line 882 of file ImageView.h.

◆ ViewportToGlobal() [1/3]

Point pcl::ImageView::ViewportToGlobal ( const Point & p ) const

inline

Converts a point p in the viewport coordinate system to the global coordinate system. Returns a point with the resulting global coordinates.

Definition at line 1029 of file ImageView.h.

References pcl::GenericPoint< T >::x, and pcl::GenericPoint< T >::y.

◆ ViewportToGlobal() [2/3]

Rect pcl::ImageView::ViewportToGlobal ( const Rect & r ) const

inline

Converts a rectangle r in the viewport coordinate system to the global coordinate system. Returns a rectangle with the resulting global coordinates.

Definition at line 1041 of file ImageView.h.

References pcl::GenericRectangle< T >::x0, pcl::GenericRectangle< T >::x1, pcl::GenericRectangle< T >::y0, and pcl::GenericRectangle< T >::y1.

◆ ViewportToGlobal() [3/3]

void pcl::ImageView::ViewportToGlobal	(	int &	x,
		int &	y
	)		const

Converts the specified x and y integer coordinates from the viewport coordinate system to the global coordinate system.

The converted global coordinates are rounded to the nearest integers.

◆ ViewportToImage() [1/7]

template<typename T >

void pcl::ImageView::ViewportToImage ( Array< GenericPoint< T > > & a ) const

inline

Converts a set of points in a dynamic array from the viewport coordinate system to the image coordinate system.

Parameters

a	Reference to a dynamic array of points that will be converted from viewport coordinates to image coordinates.

Definition at line 837 of file ImageView.h.

◆ ViewportToImage() [2/7]

template<typename T >

DPoint pcl::ImageView::ViewportToImage ( const GenericPoint< T > & p ) const

inline

Converts a point p in the viewport coordinate system to the image coordinate system. Returns a point with the resulting floating point real image coordinates.

Definition at line 784 of file ImageView.h.

References pcl::GenericPoint< T >::x, and pcl::GenericPoint< T >::y.

◆ ViewportToImage() [3/7]

template<typename T >

DRect pcl::ImageView::ViewportToImage ( const GenericRectangle< T > & r ) const

inline

Converts a rectangle r in the viewport coordinate system to the image coordinate system. Returns a rectangle with the resulting floating point real image coordinates.

Definition at line 797 of file ImageView.h.

References pcl::GenericRectangle< T >::x0, pcl::GenericRectangle< T >::x1, pcl::GenericRectangle< T >::y0, and pcl::GenericRectangle< T >::y1.

◆ ViewportToImage() [4/7]

void pcl::ImageView::ViewportToImage	(	double &	x,
		double &	y
	)		const

Converts the specified x and y real floating point coordinates from the viewport coordinate system to the image coordinate system.

◆ ViewportToImage() [5/7]

void pcl::ImageView::ViewportToImage	(	DPoint *	p,
		size_type	n
	)		const

Converts a set of real floating-point points from the viewport coordinate system to the image coordinate system.

Parameters

p	Pointer to the first point in the array of points that will be converted from viewport coordinates to image coordinates.
n	Number of points in the p array.

◆ ViewportToImage() [6/7]

void pcl::ImageView::ViewportToImage	(	int &	x,
		int &	y
	)		const

Converts the specified x and y integer coordinates from the viewport coordinate system to the image coordinate system.

The converted image coordinates are rounded to the nearest integers.

◆ ViewportToImage() [7/7]

void pcl::ImageView::ViewportToImage	(	Point *	p,
		size_type	n
	)		const

Converts a set of integer points from the viewport coordinate system to the image coordinate system.

Parameters

p	Pointer to the first point in the array of points that will be converted from viewport coordinates to image coordinates.
n	Number of points in the p array.

Converted point image coordinates are rounded to the nearest integers.

◆ ViewportUpdateRect()

Rect pcl::ImageView::ViewportUpdateRect ( ) const

Returns a rectangle in viewport coordinates that includes all pending viewport update regions for this ImageView control.

◆ ViewportWidth()

int pcl::ImageView::ViewportWidth ( ) const

inline

Gets the current width of the viewport in this ImageView control.

Definition at line 687 of file ImageView.h.

◆ VisibleViewportHeight()

int pcl::ImageView::VisibleViewportHeight ( ) const

inline

Returns the height in pixels of the current visible viewport region in this ImageView control.

Definition at line 759 of file ImageView.h.

◆ VisibleViewportRect()

Rect pcl::ImageView::VisibleViewportRect ( ) const

Gets the current visible viewport region in this ImageView control.

The returned rectangle corresponds to the visible region of the image in viewport coordinates. It depends on the current viewport zoom factor and on the positions of the viewport's scroll bars, if they are visible.

◆ VisibleViewportWidth()

int pcl::ImageView::VisibleViewportWidth ( ) const

inline

Returns the width in pixels of the current visible viewport region in this ImageView control.

Definition at line 750 of file ImageView.h.

◆ ZoomFactor()

int pcl::ImageView::ZoomFactor ( ) const

Returns the current zoom factor in the viewport of this ImageView control.

To learn how zoom factors are interpreted in PixInsight, see the documentation for SetViewport( double, double, int ).

◆ ZoomIn()

void pcl::ImageView::ZoomIn ( )

inline

Increments the current zoom factor for the viewport of this ImageView control.

To learn how zoom factors are interpreted in PixInsight, see the documentation for SetViewport( double, double, int ).

Definition at line 649 of file ImageView.h.

◆ ZoomOut()

void pcl::ImageView::ZoomOut ( )

inline

Decrements the current zoom factor for the viewport of this ImageView control.

To learn how zoom factors are interpreted in PixInsight, see the documentation for SetViewport( double, double, int ).

Definition at line 662 of file ImageView.h.

The documentation for this class was generated from the following file:

ImageView.h

Public Types

Public Member Functions

Additional Inherited Members

Detailed Description

TODO: Write a detailed description for ImageView.

Member Typedef Documentation

◆ background_brush

◆ display_channel

◆ gui_mode

◆ transparency_mode

Constructor & Destructor Documentation

◆ ImageView()

◆ ~ImageView()

Member Function Documentation

◆ BeginSelection() [1/2]

◆ BeginSelection() [2/2]

◆ CancelSelection()

◆ CommitPendingUpdates()

◆ CurrentAlphaChannel()

◆ CurrentChannel()

◆ CurrentMode()

◆ DeleteICCProfile()

◆ DisableColorManagement()

◆ DisableGamutCheck()

◆ DisableProofing()

◆ EnableColorManagement()

◆ EnableGamutCheck()

◆ EnableProofing()

◆ EndSelection()

◆ GetICCProfile()

◆ GetImageGeometry()

◆ GetRGBWS()

◆ GetSampleFormat()

◆ GetViewportSize()

◆ GlobalToViewport() [1/3]

◆ GlobalToViewport() [2/3]

◆ GlobalToViewport() [3/3]

◆ HasPendingUpdates()

◆ HideTransparency()

◆ Image()

◆ ImageBounds()

◆ ImageHeight()

◆ ImageScalarToViewport() [1/4]

◆ ImageScalarToViewport() [2/4]

◆ ImageScalarToViewport() [3/4]

◆ ImageScalarToViewport() [4/4]

◆ ImageToViewport() [1/7]

◆ ImageToViewport() [2/7]

◆ ImageToViewport() [3/7]

◆ ImageToViewport() [4/7]

◆ ImageToViewport() [5/7]

◆ ImageToViewport() [6/7]

◆ ImageToViewport() [7/7]

◆ ImageWidth()

◆ IsAlphaChannelDisplayed()

◆ IsColorImage()

◆ IsColorManagementEnabled()

◆ IsGamutCheckEnabled()

◆ IsProofingEnabled()

◆ IsSelection()

◆ IsTransparencyVisible()

◆ ModifySelection() [1/2]

◆ ModifySelection() [2/2]

◆ Regenerate()

◆ RegenerateImageRect() [1/2]

◆ RegenerateImageRect() [2/2]

◆ RegenerateViewportRect() [1/2]

◆ RegenerateViewportRect() [2/2]

◆ Reset()

◆ SelectChannel()

◆ SelectionRect()

◆ SelectMode()

◆ SetColorManagementFeatures()

◆ SetICCProfile() [1/2]

◆ SetICCProfile() [2/2]

◆ SetRGBWS()

◆ SetSampleFormat()

◆ SetTransparencyMode()

◆ SetViewport() [1/2]

◆ SetViewport() [2/2]
