pcl::AstrometricReprojection Class Reference

Astrometric image reprojection. More...

#include <AstrometricReprojection.h>

Inheritance diagram for pcl::AstrometricReprojection:

Public Member Functions
	AstrometricReprojection (const AstrometricReprojection &)=default
	AstrometricReprojection (PixelInterpolation &interpolation, const AstrometricMetadata &targetSolution, const AstrometricMetadata &sourceSolution, const ImageVariant &sourceImage, bool onTargetBounds=false)
void	GetNewSizes (int &width, int &height) const override
bool	OnTargetBounds () const
const ImageVariant &	SourceImage () const
const AstrometricMetadata &	SourceSolution () const
const DRect &	TargetRect () const
const AstrometricMetadata &	TargetSolution () const
size_type	ZeroCount () const
Public Member Functions inherited from pcl::InterpolatingGeometricTransformation
	InterpolatingGeometricTransformation (const InterpolatingGeometricTransformation &)=default
	InterpolatingGeometricTransformation (InterpolatingGeometricTransformation &&x)
	InterpolatingGeometricTransformation (PixelInterpolation &p)
void	DisableUnclippedInterpolation (bool disable=true)
void	EnableUnclippedInterpolation (bool enable=true)
PixelInterpolation &	Interpolation ()
const PixelInterpolation &	Interpolation () const
InterpolatingGeometricTransformation &	operator= (const InterpolatingGeometricTransformation &)=default
InterpolatingGeometricTransformation &	operator= (InterpolatingGeometricTransformation &&x)
void	SetInterpolation (PixelInterpolation &p)
bool	UsingUnclippedInterpolation () const
Public Member Functions inherited from pcl::GeometricTransformation
	GeometricTransformation ()=default
	GeometricTransformation (const GeometricTransformation &)=default
	GeometricTransformation (GeometricTransformation &&)=default
	~GeometricTransformation () override
GeometricTransformation &	operator= (const GeometricTransformation &)=default
GeometricTransformation &	operator= (GeometricTransformation &&)=default
Public Member Functions inherited from pcl::ImageTransformation
	ImageTransformation ()=default
	ImageTransformation (const ImageTransformation &)=default
virtual	~ImageTransformation ()
template<class P >
GenericImage< P > &	operator>> (GenericImage< P > &image) const
ImageVariant &	operator>> (ImageVariant &image) const
Public Member Functions inherited from pcl::ParallelProcess
	ParallelProcess ()=default
	ParallelProcess (const ParallelProcess &)=default
virtual	~ParallelProcess ()
void	DisableParallelProcessing (bool disable=true) noexcept
void	EnableParallelProcessing (bool enable=true, int maxProcessors=0) noexcept
bool	IsParallelProcessingEnabled () const noexcept
int	MaxProcessors () const noexcept
ParallelProcess &	operator= (const ParallelProcess &)=default
void	SetMaxProcessors (int maxProcessors) noexcept
void	Swap (ParallelProcess &process) noexcept

Static Public Member Functions
static bool	TargetPointInsideSourceRect (const AstrometricMetadata &targetSolution, const AstrometricMetadata &sourceSolution, const DPoint &targetPt, const DRect &sourceRect)
static DRect	TargetRect (const AstrometricMetadata &targetSolution, const AstrometricMetadata &sourceSolution, const Rect &sourceRect)
static bool	TargetRectInsideSourceRect (const AstrometricMetadata &targetSolution, const AstrometricMetadata &sourceSolution, const DRect &targetRect, const DRect &sourceRect)
Static Public Member Functions inherited from pcl::GeometricTransformation
template<class P >
static void	ApplyGammaExponentCorrection (typename P::sample *samples, size_type length, double gamma, AbstractImage::ThreadData &threadData, int maxProcessors=PCL_MAX_PROCESSORS)
template<class P >
static void	ApplyInverseGammaExponentCorrection (typename P::sample *samples, size_type length, double gamma, AbstractImage::ThreadData &threadData, int maxProcessors=PCL_MAX_PROCESSORS)
template<class P >
static void	ApplyInverseSRGBGammaCorrection (typename P::sample *samples, size_type length, AbstractImage::ThreadData &threadData, int maxProcessors=PCL_MAX_PROCESSORS)
template<class P >
static void	ApplySRGBGammaCorrection (typename P::sample *samples, size_type length, AbstractImage::ThreadData &threadData, int maxProcessors=PCL_MAX_PROCESSORS)

Protected Member Functions
void	Apply (pcl::DImage &) const override
void	Apply (pcl::Image &) const override
void	Apply (pcl::UInt16Image &) const override
void	Apply (pcl::UInt32Image &) const override
void	Apply (pcl::UInt8Image &) const override
Protected Member Functions inherited from pcl::ImageTransformation
virtual void	Apply (pcl::ComplexImage &image) const
virtual void	Apply (pcl::DComplexImage &image) const

Detailed Description

TODO: Write a detailed description for AstrometricReprojection

Definition at line 75 of file AstrometricReprojection.h.

Constructor & Destructor Documentation

AstrometricReprojection() [1/2]

pcl::AstrometricReprojection::AstrometricReprojection ( PixelInterpolation &  interpolation, const AstrometricMetadata &  targetSolution, const AstrometricMetadata &  sourceSolution, const ImageVariant &  sourceImage, bool  onTargetBounds = false  )

inline

Constructs a new AstrometricReprojection object.

Parameters

interpolation	Reference to a pixel interpolation for reprojection of source pixels.
targetSolution	The astrometric solution of the target image. This object provides image-to-celestial coordinate transformations for reverse projection of interpolated source pixels on a target image.
sourceSolution	The astrometric solution of the source image. This object provides celestial-to-image coordinate transformations for interpolation of source image pixels.
sourceImage	The source image that will be reprojected.
onTargetBounds	If true, the reprojection will be calculated for the entire target image bounds. If false, the reprojection will be calculated exclusively within the reprojected rectangular region in target solution coordinates. The default value is false.

Setting onTargetBounds=true can be useful to accelerate reprojections performed on entire images, avoiding the performance penalty caused by the calculation of reprojected regions, when one knows in advance that the target solution is contained by the source solution. However, with onTargetBounds=false (default value), partial reprojections can be significantly accelerated by avoiding unnecessary calculations for pixels outside reprojected regions. This is typically the case of mosaic frame reprojections.

All objects specified in a call to this constructor must remain valid while this instance exists.

Definition at line 117 of file AstrometricReprojection.h.

AstrometricReprojection() [2/2]

pcl::AstrometricReprojection::AstrometricReprojection ( const AstrometricReprojection &  )

default

Copy constructor.

Member Function Documentation

Apply() [1/5]

void pcl::AstrometricReprojection::Apply ( pcl::DImage &  image ) const

overrideprotectedvirtual

Applies this transformation to a 64-bit floating point image.

Reimplemented from pcl::ImageTransformation.

Apply() [2/5]

void pcl::AstrometricReprojection::Apply ( pcl::Image &  image ) const

overrideprotectedvirtual

Applies this transformation to a 32-bit floating point image.

Reimplemented from pcl::ImageTransformation.

Apply() [3/5]

void pcl::AstrometricReprojection::Apply ( pcl::UInt16Image &  image ) const

overrideprotectedvirtual

Applies this transformation to a 16-bit unsigned integer image.

Reimplemented from pcl::ImageTransformation.

Apply() [4/5]

void pcl::AstrometricReprojection::Apply ( pcl::UInt32Image &  image ) const

overrideprotectedvirtual

Applies this transformation to a 32-bit unsigned integer image.

Reimplemented from pcl::ImageTransformation.

Apply() [5/5]

void pcl::AstrometricReprojection::Apply ( pcl::UInt8Image &  image ) const

overrideprotectedvirtual

Applies this transformation to an 8-bit unsigned integer image.

Reimplemented from pcl::ImageTransformation.

GetNewSizes()

void pcl::AstrometricReprojection::GetNewSizes ( int &  width, int &  height  ) const

inlineoverridevirtual

Predicts transformed image dimensions.

Parameters

[in,out]	width	Reference to a variable whose value is a horizontal dimension in pixels (width). On output, it will receive the predicted horizontal dimension after the transformation.
[in,out]	height	Reference to a variable whose value is a vertical dimension in pixels (height). On output, it will receive the predicted vertical dimension after the transformation.

Note

This is a pure virtual member function that must be reimplemented in every derived class.

Implements pcl::GeometricTransformation.

Definition at line 241 of file AstrometricReprojection.h.

OnTargetBounds()

bool pcl::AstrometricReprojection::OnTargetBounds ( ) const

inline

Returns true iff this astrometric reprojection has been constructed to calculate reprojections on entire target images. See the class constructor for more information on partial and complete reprojections.

Definition at line 168 of file AstrometricReprojection.h.

SourceImage()

const ImageVariant& pcl::AstrometricReprojection::SourceImage ( ) const

inline

Returns a reference to the source image that will be reprojected.

Definition at line 158 of file AstrometricReprojection.h.

SourceSolution()

const AstrometricMetadata& pcl::AstrometricReprojection::SourceSolution ( ) const

inline

Returns a reference to the astrometric solution of the source image. The returned object provides celestial-to-image coordinate transformations for interpolation of source image pixels.

Definition at line 150 of file AstrometricReprojection.h.

TargetPointInsideSourceRect()

static bool pcl::AstrometricReprojection::TargetPointInsideSourceRect ( const AstrometricMetadata &  targetSolution, const AstrometricMetadata &  sourceSolution, const DPoint &  targetPt, const DRect &  sourceRect  )

static

Returns true iff the specified point in target solution coordinates lies inside the specified source solution coordinates after astrometric reprojection.

Parameters

targetSolution	The target astrometric solution.
sourceSolution	The source astrometric solution.
targetPt	The target point in target solution coordinates.
sourceRect	The source rectangular region in source solution coordinates.

TargetRect() [1/2]

const DRect& pcl::AstrometricReprojection::TargetRect ( ) const

inline

Returns the rectangle in target solution coordinates that encloses the boundaries of the reprojected source solution.

Definition at line 177 of file AstrometricReprojection.h.

TargetRect() [2/2]

static DRect pcl::AstrometricReprojection::TargetRect ( const AstrometricMetadata &  targetSolution, const AstrometricMetadata &  sourceSolution, const Rect &  sourceRect  )

static

Returns a reprojected rectangle in source solution coordinates.

Parameters

targetSolution	The target astrometric solution.
sourceSolution	The source astrometric solution.
sourceRect	The source rectangular region.

This function throws an Error exception in the event of invalid coordinate transformations.

TargetRectInsideSourceRect()

static bool pcl::AstrometricReprojection::TargetRectInsideSourceRect ( const AstrometricMetadata &  targetSolution, const AstrometricMetadata &  sourceSolution, const DRect &  targetRect, const DRect &  sourceRect  )

static

Returns true iff the specified rectangular region in target solution coordinates lies inside the specified source solution coordinates after astrometric reprojection.

Parameters

targetSolution	The target astrometric solution.
sourceSolution	The source astrometric solution.
targetRect	The target rectangular region in target solution coordinates.
sourceRect	The source rectangular region in source solution coordinates.

TargetSolution()

const AstrometricMetadata& pcl::AstrometricReprojection::TargetSolution ( ) const

inline

Returns a reference to the astrometric solution of the target image. The returned object provides image-to-celestial coordinate transformations for reverse projection of interpolated source pixels on a target image.

Definition at line 140 of file AstrometricReprojection.h.

ZeroCount()

size_type pcl::AstrometricReprojection::ZeroCount ( ) const

inline

Returns the total number of black (zero) source pixels reprojected in the last process execution. This is useful to detect reprojection of empty source image regions.

Returns zero if this instante has not yet been executed.

Definition at line 252 of file AstrometricReprojection.h.

---

The documentation for this class was generated from the following file:

• AstrometricReprojection.h
