Discrete two-dimensional separable convolution in the spatial domain. More...

#include <SeparableConvolution.h>

Inheritance diagram for pcl::SeparableConvolution:

Public Types
using	coefficient = SeparableFilter::coefficient

using	coefficient_vector = SeparableFilter::coefficient_vector

Public Member Functions
	SeparableConvolution ()=default

	SeparableConvolution (const SeparableConvolution &x)

	SeparableConvolution (const SeparableFilter &filter)

	SeparableConvolution (SeparableConvolution &&)=default

	~SeparableConvolution () override

void	DisableColumnConvolution (bool disable=true)

void	DisableHighPassRescaling (bool disable=true)

void	DisableRawHighPass (bool disable=true)

void	DisableRowConvolution (bool disable=true)

void	EnableColumnConvolution (bool enable=true)

void	EnableHighPassRescaling (bool enable=true)

void	EnableRawHighPass (bool enable=true)

void	EnableRowConvolution (bool enable=true)

const SeparableFilter &	Filter () const

coefficient_vector	Filter (int phase) const

template<typename T >
GenericVector< T >	FilterAs (int phase, T *) const

double	FilterWeight () const

bool	IsColumnConvolutionEnabled () const

bool	IsHighPassFilter () const

bool	IsHighPassRescalingEnabled () const

bool	IsRawHighPassEnabled () const

bool	IsRowConvolutionEnabled () const

SeparableConvolution &	operator= (const SeparableConvolution &x)

SeparableConvolution &	operator= (SeparableConvolution &&)=default

int	OverlappingDistance () const

void	SetFilter (const SeparableFilter &filter)

Public Member Functions inherited from pcl::InterlacedTransformation
	InterlacedTransformation (const InterlacedTransformation &)=default

	InterlacedTransformation (int n=1)

	~InterlacedTransformation () override

void	DisableInterlacing ()

int	InterlacingDistance () const

bool	IsInterlaced () const

void	SetInterlacingDistance (int n)

Public Member Functions inherited from pcl::ImageTransformation
	ImageTransformation ()=default

	ImageTransformation (const ImageTransformation &)=default

virtual	~ImageTransformation ()

template<class P >
GenericImage< P > &	operator>> (GenericImage< P > &image) const

ImageVariant &	operator>> (ImageVariant &image) const

Public Member Functions inherited from pcl::ParallelProcess
	ParallelProcess ()=default

	ParallelProcess (const ParallelProcess &)=default

virtual	~ParallelProcess ()

void	DisableParallelProcessing (bool disable=true) noexcept

void	EnableParallelProcessing (bool enable=true, int maxProcessors=0) noexcept

bool	IsParallelProcessingEnabled () const noexcept

int	MaxProcessors () const noexcept

ParallelProcess &	operator= (const ParallelProcess &)=default

void	SetMaxProcessors (int maxProcessors) noexcept

void	Swap (ParallelProcess &process) noexcept

Static Public Member Functions
static constexpr int	FasterThanNonseparableFilterSize (int numThreads)

Protected Member Functions
void	Apply (pcl::DImage &) const override

void	Apply (pcl::Image &) const override

void	Apply (pcl::UInt16Image &) const override

void	Apply (pcl::UInt32Image &) const override

void	Apply (pcl::UInt8Image &) const override

Protected Member Functions inherited from pcl::ImageTransformation
virtual void	Apply (pcl::ComplexImage &image) const

virtual void	Apply (pcl::DComplexImage &image) const

Detailed Description

SeparableConvolution implements a fully multithreaded, two-dimensional discrete separable convolution algorithm. It performs automatic fixing of border artifacts by applying Neumann boundary conditions (mirroring).

See also: Convolution, FFTConvolution, SeparableFilter

Definition at line 82 of file SeparableConvolution.h.

Member Typedef Documentation

◆ coefficient

using pcl::SeparableConvolution::coefficient = SeparableFilter::coefficient

Represents a filter coefficient.

Definition at line 90 of file SeparableConvolution.h.

◆ coefficient_vector

using pcl::SeparableConvolution::coefficient_vector = SeparableFilter::coefficient_vector

Represents a one-dimensional filter.

Definition at line 95 of file SeparableConvolution.h.

Constructor & Destructor Documentation

◆ SeparableConvolution() [1/4]

pcl::SeparableConvolution::SeparableConvolution ( )

default

Default constructor.

Note: This constructor yields an uninitialized instance that cannot be used before explicit association with a SeparableFilter instance.

◆ SeparableConvolution() [2/4]

pcl::SeparableConvolution::SeparableConvolution ( const SeparableFilter & filter )

inline

Constructs a SeparableConvolution object with the specified filter.

Parameters

filter Response function, or convolution filter. The specified object does not have to remain valid while this instance is actively used, since SeparableConvolution owns a private copy of the separable filter (note that SeparableFilter is a reference-counted class).

Definition at line 114 of file SeparableConvolution.h.

◆ SeparableConvolution() [3/4]

pcl::SeparableConvolution::SeparableConvolution ( const SeparableConvolution & x )

inline

Copy constructor.

Definition at line 122 of file SeparableConvolution.h.

◆ SeparableConvolution() [4/4]

pcl::SeparableConvolution::SeparableConvolution ( SeparableConvolution && )

default

Move constructor.

◆ ~SeparableConvolution()

pcl::SeparableConvolution::~SeparableConvolution ( )

inlineoverride

Destroys a SeparableConvolution object.

Definition at line 144 of file SeparableConvolution.h.

Member Function Documentation

◆ Apply() [1/5]

void pcl::SeparableConvolution::Apply ( pcl::DImage & image ) const

overrideprotectedvirtual

Applies this transformation to a 64-bit floating point image.

Reimplemented from pcl::ImageTransformation.

◆ Apply() [2/5]

void pcl::SeparableConvolution::Apply ( pcl::Image & image ) const

overrideprotectedvirtual

Applies this transformation to a 32-bit floating point image.

Reimplemented from pcl::ImageTransformation.

◆ Apply() [3/5]

void pcl::SeparableConvolution::Apply ( pcl::UInt16Image & image ) const

overrideprotectedvirtual

Applies this transformation to a 16-bit unsigned integer image.

Reimplemented from pcl::ImageTransformation.

◆ Apply() [4/5]

void pcl::SeparableConvolution::Apply ( pcl::UInt32Image & image ) const

overrideprotectedvirtual

Applies this transformation to a 32-bit unsigned integer image.

Reimplemented from pcl::ImageTransformation.

◆ Apply() [5/5]

void pcl::SeparableConvolution::Apply ( pcl::UInt8Image & image ) const

overrideprotectedvirtual

Applies this transformation to an 8-bit unsigned integer image.

Reimplemented from pcl::ImageTransformation.

◆ DisableColumnConvolution()

void pcl::SeparableConvolution::DisableColumnConvolution ( bool disable = true )

inline

Disables (or enables) convolution of pixel columns.

This is a convenience function, equivalent to: EnableColumnConvolution( !disable )

Definition at line 381 of file SeparableConvolution.h.

◆ DisableHighPassRescaling()

void pcl::SeparableConvolution::DisableHighPassRescaling ( bool disable = true )

inline

Disables (or enables) high-pass rescaling of out-of-range convolved pixel values. See the documentation for IsHighPassRescalingEnabled() for more information.

Definition at line 294 of file SeparableConvolution.h.

◆ DisableRawHighPass()

void pcl::SeparableConvolution::DisableRawHighPass ( bool disable = true )

inline

Disables (or enables) raw high-pass convolution. See the documentation for IsRawHighPassEnabled() for more information.

Definition at line 327 of file SeparableConvolution.h.

◆ DisableRowConvolution()

void pcl::SeparableConvolution::DisableRowConvolution ( bool disable = true )

inline

Disables (or enables) convolution of pixel rows.

This is a convenience function, equivalent to: EnableRowConvolution( !disable )

Definition at line 354 of file SeparableConvolution.h.

◆ EnableColumnConvolution()

void pcl::SeparableConvolution::EnableColumnConvolution ( bool enable = true )

inline

Enables (or disables) convolution of pixel columns.

Definition at line 370 of file SeparableConvolution.h.

◆ EnableHighPassRescaling()

void pcl::SeparableConvolution::EnableHighPassRescaling ( bool enable = true )

inline

Enables (or disables) high-pass rescaling of out-of-range convolved pixel values. See the documentation for IsHighPassRescalingEnabled() for more information.

Definition at line 284 of file SeparableConvolution.h.

◆ EnableRawHighPass()

void pcl::SeparableConvolution::EnableRawHighPass ( bool enable = true )

inline

Enables (or disables) raw high-pass convolution. See the documentation for IsRawHighPassEnabled() for more information.

Definition at line 318 of file SeparableConvolution.h.

◆ EnableRowConvolution()

void pcl::SeparableConvolution::EnableRowConvolution ( bool enable = true )

inline

Enables (or disables) convolution of pixel rows.

Definition at line 343 of file SeparableConvolution.h.

◆ Filter() [1/2]

const SeparableFilter& pcl::SeparableConvolution::Filter ( ) const

inline

Returns a constant reference to the separable filter currently associated with this SeparableConvolution object.

Note: If this object has not been initialized, this member function throws an Error exception.

Definition at line 183 of file SeparableConvolution.h.

◆ Filter() [2/2]

coefficient_vector pcl::SeparableConvolution::Filter ( int phase ) const

inline

Returns a copy of the internal one-dimensional filter vector corresponding to the specified phase. If phase is zero, a copy of the row filter vector is returned; otherwise a copy of the column filter vector is returned.

Note: If this object has not been initialized, this member function throws an Error exception.

Definition at line 198 of file SeparableConvolution.h.

◆ FilterAs()

template<typename T >

GenericVector<T> pcl::SeparableConvolution::FilterAs	(	int	phase,
		T *
	)		const

inline

Returns a copy of the internal one-dimensional filter vector corresponding to the specified phase, with components converted to the scalar type T. If phase is zero, a copy of the row filter vector is returned; otherwise a copy of the column filter vector is returned.

Definition at line 211 of file SeparableConvolution.h.

◆ FilterWeight()

double pcl::SeparableConvolution::FilterWeight ( ) const

inline

Returns the current filter weight. The filter weight is computed each time a separable filter is associated with this object. It is only applied for low-pass filters as a normalization factor. For more information, see the documentation for SeparableFilter::Weight().

The filter weight and other filter properties are cached in private data members for quick reference.

Definition at line 235 of file SeparableConvolution.h.

◆ IsColumnConvolutionEnabled()

bool pcl::SeparableConvolution::IsColumnConvolutionEnabled ( ) const

inline

Returns true iff this object will convolve pixel columns on target images.

Definition at line 362 of file SeparableConvolution.h.

◆ IsHighPassFilter()

bool pcl::SeparableConvolution::IsHighPassFilter ( ) const

inline

Returns true if the separable filter currently associated with this SeparableConvolution object is a high-pass filter; false if it is a low-pass filter. For more information, see the documentation for SeparableFilter::IsHighPassFilter().

Each time a separable filter is associated with this object, its high-pass nature is checked and stored, along with other filter properties, in private data members. This allows for quick lookup of critical filter characteristics without degrading performance.

Definition at line 251 of file SeparableConvolution.h.

◆ IsHighPassRescalingEnabled()

bool pcl::SeparableConvolution::IsHighPassRescalingEnabled ( ) const

inline

Returns true iff out-of-range values will be rescaled for normalization of images after convolution with a high-pass filter.

A high-pass filter has negative coefficients. As a result, some pixels in the convolved image may have negative values. Saturated pixels (values above one) can also result, depending on the filter coefficients. The standard behavior is to truncate out-of-range pixel values to the [0,1] range, which preserves the dynamics of the convolved image, so high-pass rescaling is disabled by default. When high-pass rescaling is enabled, the resulting image is normalized (that is, rescaled to [0,1] only if there are out-of-range values) and hence all the data after convolution are preserved at the cost of reducing the overall contrast of the image. Finally, if raw high-pass convolution has been enabled, out-of-range values are neither truncated nor rescaled irrespective of the value returned by this function. See the documentation for IsRawHighPassEnabled() for more information.

Definition at line 274 of file SeparableConvolution.h.

◆ IsRawHighPassEnabled()

bool pcl::SeparableConvolution::IsRawHighPassEnabled ( ) const

inline

Returns true iff raw high-pass convolution is enabled. When raw high-pass convolution is enabled, out-of-range values after convolution with a high-pass filter are neither truncated nor normalized. Note that this is only relevant to convolution of floating point data.

Raw high-pass convolution is disabled by default. For more information on out-of-range convolution results, refer to the documentation for IsHighPassRescalingEnabled().

Definition at line 309 of file SeparableConvolution.h.

◆ IsRowConvolutionEnabled()

bool pcl::SeparableConvolution::IsRowConvolutionEnabled ( ) const

inline

Returns true iff this object will convolve pixel rows on target images.

Definition at line 335 of file SeparableConvolution.h.

◆ operator=() [1/2]

SeparableConvolution& pcl::SeparableConvolution::operator= ( const SeparableConvolution & x )

inline

Copy assignment operator. Returns a reference to this object.

Definition at line 151 of file SeparableConvolution.h.

◆ operator=() [2/2]

SeparableConvolution& pcl::SeparableConvolution::operator= ( SeparableConvolution && )

default

Move assignment operator. Returns a reference to this object.

◆ OverlappingDistance()

int pcl::SeparableConvolution::OverlappingDistance ( ) const

inline

Returns the length in pixels of the overlapping regions between adjacent areas processed by parallel execution threads. The overlapping distance is a function of the filter size and the interlacing distance.

Definition at line 391 of file SeparableConvolution.h.

◆ SetFilter()

void pcl::SeparableConvolution::SetFilter ( const SeparableFilter & filter )

inline

Sets a new filter to be applied by this SeparableConvolution object.

Definition at line 220 of file SeparableConvolution.h.

References pcl::SeparableFilter::Clone().

The documentation for this class was generated from the following file:

SeparableConvolution.h

Public Types

Public Member Functions

Static Public Member Functions

Protected Member Functions

Detailed Description

Member Typedef Documentation

◆ coefficient

◆ coefficient_vector

Constructor & Destructor Documentation

◆ SeparableConvolution() [1/4]

◆ SeparableConvolution() [2/4]

◆ SeparableConvolution() [3/4]

◆ SeparableConvolution() [4/4]

◆ ~SeparableConvolution()

Member Function Documentation

◆ Apply() [1/5]

◆ Apply() [2/5]

◆ Apply() [3/5]

◆ Apply() [4/5]

◆ Apply() [5/5]

◆ DisableColumnConvolution()

◆ DisableHighPassRescaling()

◆ DisableRawHighPass()

◆ DisableRowConvolution()

◆ EnableColumnConvolution()

◆ EnableHighPassRescaling()

◆ EnableRawHighPass()

◆ EnableRowConvolution()

◆ Filter() [1/2]

◆ Filter() [2/2]

◆ FilterAs()

◆ FilterWeight()

◆ IsColumnConvolutionEnabled()

◆ IsHighPassFilter()

◆ IsHighPassRescalingEnabled()

◆ IsRawHighPassEnabled()

◆ IsRowConvolutionEnabled()

◆ operator=() [1/2]

◆ operator=() [2/2]

◆ OverlappingDistance()

◆ SetFilter()
