pcl::InterlacedTransformation Class Reference

Interlaced image transformation in the spatial domain. More...

#include <InterlacedTransformation.h>

Inheritance diagram for pcl::InterlacedTransformation:

Public Member Functions
	InterlacedTransformation (const InterlacedTransformation &)=default
	InterlacedTransformation (int n=1)
	~InterlacedTransformation () override
void	DisableInterlacing ()
int	InterlacingDistance () const
bool	IsInterlaced () const
void	SetInterlacingDistance (int n)
Public Member Functions inherited from pcl::ImageTransformation
	ImageTransformation ()=default
	ImageTransformation (const ImageTransformation &)=default
virtual	~ImageTransformation ()
template<class P >
GenericImage< P > &	operator>> (GenericImage< P > &image) const
ImageVariant &	operator>> (ImageVariant &image) const

Additional Inherited Members
Protected Member Functions inherited from pcl::ImageTransformation
virtual void	Apply (pcl::ComplexImage &image) const
virtual void	Apply (pcl::DComplexImage &image) const
virtual void	Apply (pcl::DImage &image) const
virtual void	Apply (pcl::Image &image) const
virtual void	Apply (pcl::UInt16Image &image) const
virtual void	Apply (pcl::UInt32Image &image) const
virtual void	Apply (pcl::UInt8Image &image) const

Detailed Description

InterlacedTransformation represents an interlaced image transformation in PCL. An interlaced transformation can be applied to a subset of the pixels in a target image by acting exclusively on selected rows and columns of pixels, distributed at regular intervals.

The distance between two consecutive rows or columns of transformed pixels is the interlacing distance that characterizes an interlaced transformation. Intermediate pixels falling between selected rows or columns are ignored during the transformation.

In PCL, convolutions in the spatial domain and morphological transformations have been implemented as interlaced transformations. A good example of interlaced image transformation algorithm is the starlet transform (see the StarletTransform class), which uses interlaced convolutions to perform a multiscale decomposition.

Definition at line 88 of file InterlacedTransformation.h.

Constructor & Destructor Documentation

InterlacedTransformation() [1/2]

pcl::InterlacedTransformation::InterlacedTransformation ( int  n = 1 )

inline

Constructs an InterlacedTransformation object with the specified interlacing distance n > 0 in pixels.

Definition at line 96 of file InterlacedTransformation.h.

InterlacedTransformation() [2/2]

pcl::InterlacedTransformation::InterlacedTransformation ( const InterlacedTransformation &  )

default

Copy constructor.

~InterlacedTransformation()

pcl::InterlacedTransformation::~InterlacedTransformation ( )

inlineoverride

Destroys an InterlacedTransformation object.

Definition at line 110 of file InterlacedTransformation.h.

Member Function Documentation

DisableInterlacing()

void pcl::InterlacedTransformation::DisableInterlacing ( )

inline

Disables interlacing for this transformation.

This is a convenience function, equivalent to:

SetInterlacingDistance( 1 );

Definition at line 161 of file InterlacedTransformation.h.

InterlacingDistance()

int pcl::InterlacedTransformation::InterlacingDistance ( ) const

inline

Returns the current interlacing distance of this transformation in pixels.

See also

SetInterlacingDistance(), IsInterlaced()

Definition at line 133 of file InterlacedTransformation.h.

IsInterlaced()

bool pcl::InterlacedTransformation::IsInterlaced ( ) const

inline

Returns true iff this transformation is currently interlaced.

The transformation is interlaced if the current interlacing distance is greater than one pixel.

See also

InterlacingDistance()

Definition at line 122 of file InterlacedTransformation.h.

SetInterlacingDistance()

void pcl::InterlacedTransformation::SetInterlacingDistance ( int  n )

inline

Sets the current interlacing distance of this transformation to the specified value n > 0 in pixels.

The interlacing distance is the distance in pixels between two consecutive rows or columns of transformed pixels. Intermediate pixels falling between selected rows or columns are ignored.

See also

InterlacingDistance(), DisableInterlacing(), IsInterlaced()

Definition at line 148 of file InterlacedTransformation.h.

References pcl::Max().

---

The documentation for this class was generated from the following file:

• InterlacedTransformation.h
