Client-side interface to a PixInsight modal dialog. More...

#include <Dialog.h>

Inheritance diagram for pcl::Dialog:

Public Types
using	execute_event_handler = void(Control::*)(Dialog &sender)

using	return_event_handler = void(Control::*)(Dialog &sender, int retCode)

using	std_code = StdDialogCode::value_type

Public Types inherited from pcl::Control
using	child_event_handler = void(Control::*)(Control &sender, Control &child)

using	close_event_handler = void(Control::*)(Control &sender, bool &allowClose)

using	event_handler = void(Control::*)(Control &sender)

using	file_drag_event_handler = void(Control::*)(Control &sender, const pcl::Point &pos, const StringList &files, unsigned modifiers, bool &wantsFiles)

using	file_drop_event_handler = void(Control::*)(Control &sender, const pcl::Point &pos, const StringList &files, unsigned modifiers)

using	keyboard_event_handler = void(Control::*)(Control &sender, int key, unsigned modifiers, bool &wantsKey)

using	mouse_button_event_handler = void(Control::*)(Control &sender, const pcl::Point &pos, int button, unsigned buttons, unsigned modifiers)

using	mouse_event_handler = void(Control::*)(Control &sender, const pcl::Point &pos, unsigned buttons, unsigned modifiers)

using	mouse_wheel_event_handler = void(Control::*)(Control &sender, const pcl::Point &pos, int delta, unsigned buttons, unsigned modifiers)

using	move_event_handler = void(Control::*)(Control &sender, const pcl::Point &newPos, const pcl::Point &oldPos)

using	paint_event_handler = void(Control::*)(Control &sender, const pcl::Rect &updateRect)

using	resize_event_handler = void(Control::*)(Control &sender, int newWidth, int newHeight, int oldWidth, int oldHeight)

using	view_drag_event_handler = void(Control::*)(Control &sender, const pcl::Point &pos, const View &view, unsigned modifiers, bool &wantsView)

using	view_drop_event_handler = void(Control::*)(Control &sender, const pcl::Point &pos, const View &view, unsigned modifiers)

Public Member Functions
	Dialog (Control &parent=Control::Null())

	~Dialog () override

void	Cancel ()

void	DisableUserResizing (bool disable=true)

void	EnableUserResizing (bool=true)

int	Execute ()

bool	IsUserResizable () const

void	Ok ()

void	OnExecute (execute_event_handler handler, Control &receiver)

void	OnReturn (return_event_handler handler, Control &receiver)

void	Open ()

void	Return (int retCode)

Public Member Functions inherited from pcl::Control
	Control (const Control &)=delete

	Control (Control &&)=delete

	Control (Control &parent=Null(), uint32=0)

	~Control () override

void	ActivateRealTimePreview ()

void	ActivateTrackView ()

void	ActivateWindow ()

void	AdjustToContents ()

RGBA	AlternateCanvasColor () const

RGBA	BackgroundColor () const

pcl::Rect	BoundsRect () const

void	BringToFront ()

RGBA	ButtonColor () const

RGBA	ButtonTextColor () const

bool	CanUpdate () const

RGBA	CanvasColor ()

Control &	ChildByPos (const pcl::Point &p) const

Control &	ChildByPos (int x, int y) const

pcl::Rect	ChildrenRect () const

Control &	ChildToFocus () const

void	ClearInfoText ()

int	ClientHeight () const

pcl::Rect	ClientRect () const

int	ClientWidth () const

void	ControlToLocal (const Control &, int &x, int &y) const

pcl::Point	ControlToLocal (const Control &w, const pcl::Point &p) const

pcl::Cursor	Cursor () const

void	DeactivateRealTimePreview ()

void	DeactivateTrackView ()

void	Disable (bool disabled=true)

void	DisableExpansion (bool horzDisable=true, bool vertDisable=true)

void	DisableMouseTracking (bool disable=true)

void	DisableUpdates (bool disable=true)

double	DisplayPixelRatio () const

virtual void	Enable (bool enabled=true)

void	EnableExpansion (bool horzEnable=true, bool vertEnable=true)

void	EnableMouseTracking (bool=true)

void	EnableUpdates (bool enable=true)

void	EnsureLayoutUpdated ()

void	EnsureUnique () override

void	Focus (bool focus=true)

Control &	FocusedChild () const

FocusStyles	FocusStyle () const

pcl::Font	Font () const

RGBA	ForegroundColor () const

int	FrameHeight () const

pcl::Rect	FrameRect () const

int	FrameWidth () const

pcl::Cursor	GetCursor () const

pcl::Font	GetFont () const

void	GetMaxSize (int &w, int &h) const

void	GetMinSize (int &w, int &h) const

void	GetScaledMaxSize (int &w, int &h) const

void	GetScaledMinSize (int &w, int &h) const

pcl::Sizer	GetSizer () const

pcl::Point	GlobalToLocal (const pcl::Point &p) const

void	GlobalToLocal (int &x, int &y) const

int	Height () const

void	Hide ()

RGBA	HighlightColor () const

RGBA	HighlightedTextColor () const

String	InfoText () const

bool	IsActiveWindow () const

bool	IsAncestorOf (const Control &) const

virtual bool	IsEnabled () const

bool	IsFixedHeight () const

bool	IsFixedWidth () const

bool	IsFocused () const

bool	IsHidden () const

bool	IsHorizontalExpansionEnabled () const

bool	IsMaximized () const

bool	IsMinimized () const

bool	IsModal () const

bool	IsMouseTrackingEnabled () const

bool	IsRealTimePreviewActive () const

bool	IsTrackViewActive () const

bool	IsUnderMouse () const

bool	IsVerticalExpansionEnabled () const

bool	IsVisible () const

bool	IsWindow () const

void	LocalToControl (const Control &, int &x, int &y) const

pcl::Point	LocalToControl (const Control &w, const pcl::Point &p) const

pcl::Point	LocalToGlobal (const pcl::Point &p) const

void	LocalToGlobal (int &x, int &y) const

pcl::Point	LocalToParent (const pcl::Point &p) const

void	LocalToParent (int &x, int &y) const

int	LogicalPixelsToPhysical (int size) const

int	LogicalPixelsToResource (int size) const

int	MaxHeight () const

int	MaxWidth () const

int	MinHeight () const

int	MinWidth () const

void	Move (const pcl::Point &p)

void	Move (int x, int y)

Control &	NextSiblingToFocus () const

void	OnChildCreate (child_event_handler, Control &)

void	OnChildDestroy (child_event_handler, Control &)

void	OnClose (close_event_handler, Control &)

void	OnDestroy (event_handler, Control &)

void	OnEnter (event_handler, Control &)

void	OnFileDrag (file_drag_event_handler, Control &)

void	OnFileDrop (file_drop_event_handler, Control &)

void	OnGetFocus (event_handler, Control &)

void	OnHide (event_handler, Control &)

void	OnKeyPress (keyboard_event_handler, Control &)

void	OnKeyRelease (keyboard_event_handler, Control &)

void	OnLeave (event_handler, Control &)

void	OnLoseFocus (event_handler, Control &)

void	OnMouseDoubleClick (mouse_event_handler, Control &)

void	OnMouseMove (mouse_event_handler, Control &)

void	OnMousePress (mouse_button_event_handler, Control &)

void	OnMouseRelease (mouse_button_event_handler, Control &)

void	OnMouseWheel (mouse_wheel_event_handler, Control &)

void	OnMove (move_event_handler, Control &)

void	OnPaint (paint_event_handler, Control &)

void	OnResize (resize_event_handler, Control &)

void	OnShow (event_handler, Control &)

void	OnViewDrag (view_drag_event_handler, Control &)

void	OnViewDrop (view_drop_event_handler, Control &)

Control &	operator= (const Control &)=delete

Control &	operator= (Control &&)=delete

Control &	Parent () const

pcl::Point	ParentToLocal (const pcl::Point &p) const

void	ParentToLocal (int &x, int &y) const

int	PhysicalPixelsToLogical (int size) const

pcl::Point	Position () const

void	Repaint ()

void	Repaint (const pcl::Rect &r)

void	Repaint (int x0, int y0, int x1, int y1)

void	Resize (int w, int h)

double	ResourcePixelRatio () const

int	ResourcePixelsToLogical (int size) const

void	Restyle ()

Point	ScaledCursorHotSpot (const Point &hotSpot) const

Point	ScaledCursorHotSpot (int xHot, int yHot) const

int	ScaledMaxHeight () const

int	ScaledMaxWidth () const

int	ScaledMinHeight () const

int	ScaledMinWidth () const

template<class R >
String	ScaledResource (R resource) const

template<class S >
String	ScaledStyleSheet (S cssCode, int fontDPI=0) const

void	Scroll (const pcl::Point &d)

void	Scroll (const pcl::Point &d, const pcl::Rect &r)

void	Scroll (int dx, int dy)

void	Scroll (int dx, int dy, int x0, int y0, int x1, int y1)

void	SendToBack ()

void	SetAlternateCanvasColor (RGBA)

void	SetBackgroundColor (RGBA)

void	SetButtonColor (RGBA)

void	SetButtonTextColor (RGBA)

void	SetCanvasColor (RGBA)

void	SetChildToFocus (Control &)

void	SetClientRect (const pcl::Rect &r)

void	SetClientRect (int x0, int y0, int x1, int y1)

void	SetCursor (const pcl::Cursor &)

void	SetCursorToParent ()

void	SetFixedHeight ()

void	SetFixedHeight (int h)

void	SetFixedSize ()

void	SetFixedSize (int w, int h)

void	SetFixedWidth ()

void	SetFixedWidth (int w)

void	SetFocusStyle (FocusStyles)

void	SetFont (const pcl::Font &)

void	SetForegroundColor (RGBA)

void	SetHighlightColor (RGBA)

void	SetHighlightedTextColor (RGBA)

void	SetInfoText (const String &)

void	SetMaxHeight ()

void	SetMaxHeight (int h)

void	SetMaxSize ()

void	SetMaxSize (int w, int h)

void	SetMaxWidth ()

void	SetMaxWidth (int w)

void	SetMinHeight ()

void	SetMinHeight (int h)

void	SetMinSize ()

void	SetMinSize (int w, int h)

void	SetMinWidth ()

void	SetMinWidth (int w)

void	SetNextSiblingToFocus (Control &)

void	SetParent (Control &)

void	SetRealTimePreviewActive (bool=true)

void	SetScaledFixedHeight (int h)

void	SetScaledFixedSize (int w, int h)

void	SetScaledFixedWidth (int w)

void	SetScaledMaxHeight (int h)

void	SetScaledMaxSize (int w, int h)

void	SetScaledMaxWidth (int w)

void	SetScaledMinHeight (int h)

void	SetScaledMinSize (int w, int h)

void	SetScaledMinWidth (int w)

void	SetSizer (pcl::Sizer &)

void	SetStyleSheet (const String &css)

void	SetTextColor (RGBA)

void	SetToolTip (const String &)

void	SetTrackViewActive (bool=true)

void	SetVariableHeight ()

void	SetVariableSize ()

void	SetVariableWidth ()

void	SetVisible (bool visible)

void	SetWindowOpacity (double)

void	SetWindowTitle (const String &)

void	Show ()

pcl::Sizer	Sizer () const

void	StackUnder (Control &)

String	StyleSheet () const

RGBA	TextColor () const

String	ToolTip () const

void	Unfocus ()

void	Update ()

void	Update (const pcl::Rect &r)

void	Update (int x0, int y0, int x1, int y1)

pcl::Rect	VisibleRect () const

int	Width () const

Control &	Window () const

double	WindowOpacity () const

String	WindowTitle () const

int	X () const

int	Y () const

Public Member Functions inherited from pcl::UIObject
virtual	~UIObject () noexcept(false)

bool	IsAlias () const

bool	IsGarbage () const

bool	IsNull () const

bool	IsSameObject (const UIObject &o) const

bool	IsUnique () const

String	ObjectId () const

IsoString	ObjectType () const

bool	operator< (const UIObject &o) const

bool	operator== (const UIObject &o) const

size_type	RefCount () const

void	SetObjectId (const String &id)

Static Public Member Functions
static void	ProcessEvents (bool excludeUserInputEvents=false)

Static Public Member Functions inherited from pcl::Control
static void	HideToolTip ()

static Control &	Null ()

static void	ShowToolTip (const Point &pos, const String &text, const Control &control=Control::Null(), const Rect &rect=Rect(0))

static void	ShowToolTip (int x, int y, const String &text, const Control &control=Control::Null(), const Rect &rect=Rect(0))

static String	ToolTipText ()

Static Public Member Functions inherited from pcl::UIObject
static UIObject &	Null ()

Additional Inherited Members
Protected Member Functions inherited from pcl::UIObject
	UIObject ()=default

	UIObject (const UIObject &x)

	UIObject (UIObject &&x)

UIObject &	operator= (const UIObject &x)

UIObject &	operator= (UIObject &&x)

Detailed Description

Dialogs are top-level windows that execute modally relative to the main window of the PixInsight core application.

Definition at line 96 of file Dialog.h.

Member Typedef Documentation

◆ std_code

using pcl::Dialog::std_code = StdDialogCode::value_type

Represents a standard dialog return code.

Definition at line 103 of file Dialog.h.

Constructor & Destructor Documentation

◆ Dialog()

pcl::Dialog::Dialog ( Control & parent = Control::Null() )

Constructs a Dialog object.

If the specified parent control is a non-null control, the dialog will be shown centered over its parent. Otherwise the dialog window will be shown centered on the current workspace. Note that specifying a dialog parent does not change the dialog's modality: all dialog windows are application-modal in PixInsight. See the Execute() and Open() member functions for more information.

◆ ~Dialog()

pcl::Dialog::~Dialog ( )

inlineoverride

Destroys a Dialog object.

Definition at line 120 of file Dialog.h.

Member Function Documentation

◆ Cancel()

void pcl::Dialog::Cancel ( )

inline

This is a convenience member function equivalent to:
Return( StdDialogCode::Cancel )

Definition at line 185 of file Dialog.h.

◆ DisableUserResizing()

void pcl::Dialog::DisableUserResizing ( bool disable = true )

inline

Disables or enables user resizing for this dialog.

This is a convenience member function, equivalent to: EnableUserResizing( !disable )

Definition at line 207 of file Dialog.h.

◆ EnableUserResizing()

void pcl::Dialog::EnableUserResizing ( bool = true )

Enables or disables user resizing for this dialog.

◆ Execute()

int pcl::Dialog::Execute ( )

Shows a modal dialog and executes a separate event loop.

This function creates a new event loop and does not return until the loop has exited and the dialog has been closed. During the event loop, the dialog behaves as an application modal window: Only the dialog window allows user interaction while the rest of the GUI is blocked in the PixInsight core application. To exit the modal event loop, the Ok() and Cancel() member functions can be used to return the standard dialog exit codes StdDialogCode::Ok and StdDialogCode::Cancel, respectively.

This function returns a dialog return code. Although dialog return codes are arbitrary (they can be forced to any integer value with the Return() member function), dialogs with standard OK and Cancel buttons should always return a standard code, as defined in the StdDialogCode namespace.

For a non-blocking alternative to use dialog windows, see the Open() member function.

See also: Ok(), Cancel(), Return(), Open()

◆ IsUserResizable()

bool pcl::Dialog::IsUserResizable ( ) const

Returns true iff this dialog is user-resizable. User-resizable dialogs can be resized interactively with the mouse and standard window controls.

◆ Ok()

void pcl::Dialog::Ok ( )

inline

This is a convenience member function equivalent to:
Return( StdDialogCode::Ok )

Definition at line 176 of file Dialog.h.

◆ Open()

void pcl::Dialog::Open ( )

Shows a modal dialog window.

This function opens the dialog window and returns immediately, allowing normal execution to continue without entering a separate event loop. As happens with Dialog::Execute(), this member function creates a modal dialog that blocks the rest of the PixInsight core application for GUI user interaction. The essential difference between both member functions is that Open() does not enter a new event loop. Typically, this function is used to provide feedback to the user during long procedures, as well as the possibility to interrupt or pause those procedures. For example, a progress dialog can be shown as a modal window during a file copy operation, or while a long calculation routine is being executed.

See also: Execute()

◆ ProcessEvents()

static void pcl::Dialog::ProcessEvents ( bool excludeUserInputEvents = false )

static

Processes pending user interface events.

This member function is a convenience wrapper with the same functionality as ProcessInterface::ProcessEvents().

◆ Return()

void pcl::Dialog::Return ( int retCode )

Closes this modal dialog and forces a return value retCode for the Execute() member function.

The documentation for this class was generated from the following file:

Dialog.h

Public Types

Public Member Functions

Static Public Member Functions

Additional Inherited Members

Detailed Description

Member Typedef Documentation

◆ std_code

Constructor & Destructor Documentation

◆ Dialog()

◆ ~Dialog()

Member Function Documentation

◆ Cancel()

◆ DisableUserResizing()

◆ EnableUserResizing()

◆ Execute()

◆ IsUserResizable()

◆ Ok()

◆ Open()

◆ ProcessEvents()

◆ Return()
