Image cropping/expansion algorithm More...

#include <Crop.h>

Inheritance diagram for pcl::Crop:

Public Types
using	crop_mode = CropMode::value_type

Public Member Functions
	Crop (const Crop &)=default

template<typename T >
	Crop (const GenericRectangle< T > &r)

	Crop (double left=0, double top=0, double right=0, double bottom=0)

const DVector &	FillValues () const

void	GetNewSizes (int &width, int &height) const override

bool	IsAbsolute () const

bool	IsRelative () const

DRect	Margins () const

crop_mode	Mode () const

Crop &	operator= (const Crop &)=default

void	SetFillValues (const DVector &fillValues)

template<typename T >
void	SetMargins (const GenericRectangle< T > &r)

void	SetMargins (int left, int top, int right, int bottom)

void	SetMode (crop_mode mode)

Public Member Functions inherited from pcl::GeometricTransformation
	GeometricTransformation ()=default

	GeometricTransformation (const GeometricTransformation &)=default

	GeometricTransformation (GeometricTransformation &&)=default

	~GeometricTransformation () override

GeometricTransformation &	operator= (const GeometricTransformation &)=default

GeometricTransformation &	operator= (GeometricTransformation &&)=default

Public Member Functions inherited from pcl::ImageTransformation
	ImageTransformation ()=default

	ImageTransformation (const ImageTransformation &)=default

virtual	~ImageTransformation ()

template<class P >
GenericImage< P > &	operator>> (GenericImage< P > &image) const

ImageVariant &	operator>> (ImageVariant &image) const

Public Member Functions inherited from pcl::ImageResolution
	ImageResolution ()=default

	ImageResolution (const ImageResolution &)=default

void	GetResolution (double &x, double &y)

double	HorizontalResolution () const

bool	IsMetricResolution () const

ImageResolution &	operator= (const ImageResolution &)=default

double	Resolution () const

void	SetMetricResolution (bool m)

void	SetResolution (double r)

void	SetResolution (double x, double y)

double	VerticalResolution () const

Protected Member Functions
void	Apply (pcl::ComplexImage &) const override

void	Apply (pcl::DComplexImage &) const override

void	Apply (pcl::DImage &) const override

void	Apply (pcl::Image &) const override

void	Apply (pcl::UInt16Image &) const override

void	Apply (pcl::UInt32Image &) const override

void	Apply (pcl::UInt8Image &) const override

Additional Inherited Members
Static Public Member Functions inherited from pcl::GeometricTransformation
template<class P >
static void	ApplyGammaExponentCorrection (typename P::sample *samples, size_type length, double gamma, AbstractImage::ThreadData &threadData, int maxProcessors=PCL_MAX_PROCESSORS)

template<class P >
static void	ApplyInverseGammaExponentCorrection (typename P::sample *samples, size_type length, double gamma, AbstractImage::ThreadData &threadData, int maxProcessors=PCL_MAX_PROCESSORS)

template<class P >
static void	ApplyInverseSRGBGammaCorrection (typename P::sample *samples, size_type length, AbstractImage::ThreadData &threadData, int maxProcessors=PCL_MAX_PROCESSORS)

template<class P >
static void	ApplySRGBGammaCorrection (typename P::sample *samples, size_type length, AbstractImage::ThreadData &threadData, int maxProcessors=PCL_MAX_PROCESSORS)

Detailed Description

Crop is a noninterpolating geometric transformation class that allows cropping an image or expanding it by specifying separate cropping margins for each side. When a cropping margin is negative the image is cropped, and when it is positive, the image is expanded.

Definition at line 101 of file Crop.h.

Member Typedef Documentation

◆ crop_mode

using pcl::Crop::crop_mode = CropMode::value_type

Represents a cropping mode.

Definition at line 109 of file Crop.h.

Constructor & Destructor Documentation

◆ Crop() [1/3]

pcl::Crop::Crop	(	double	left = `0`,
		double	top = `0`,
		double	right = `0`,
		double	bottom = `0`
	)

inline

Constructs a Crop object with the specified cropping margins for the left, top, right and bottom sides.

Definition at line 115 of file Crop.h.

◆ Crop() [2/3]

template<typename T >

pcl::Crop::Crop ( const GenericRectangle< T > & r )

inline

Constructs a Crop object whose cropping margins are defined by the components of a rectangle r.

Definition at line 126 of file Crop.h.

◆ Crop() [3/3]

pcl::Crop::Crop ( const Crop & )

default

Copy constructor.

Member Function Documentation

◆ Apply() [1/7]

void pcl::Crop::Apply ( pcl::ComplexImage & image ) const

overrideprotectedvirtual

Applies this transformation to a 32-bit complex image.

Reimplemented from pcl::ImageTransformation.

◆ Apply() [2/7]

void pcl::Crop::Apply ( pcl::DComplexImage & image ) const

overrideprotectedvirtual

Applies this transformation to a 64-bit complex image.

Reimplemented from pcl::ImageTransformation.

◆ Apply() [3/7]

void pcl::Crop::Apply ( pcl::DImage & image ) const

overrideprotectedvirtual

Applies this transformation to a 64-bit floating point image.

Reimplemented from pcl::ImageTransformation.

◆ Apply() [4/7]

void pcl::Crop::Apply ( pcl::Image & image ) const

overrideprotectedvirtual

Applies this transformation to a 32-bit floating point image.

Reimplemented from pcl::ImageTransformation.

◆ Apply() [5/7]

void pcl::Crop::Apply ( pcl::UInt16Image & image ) const

overrideprotectedvirtual

Applies this transformation to a 16-bit unsigned integer image.

Reimplemented from pcl::ImageTransformation.

◆ Apply() [6/7]

void pcl::Crop::Apply ( pcl::UInt32Image & image ) const

overrideprotectedvirtual

Applies this transformation to a 32-bit unsigned integer image.

Reimplemented from pcl::ImageTransformation.

◆ Apply() [7/7]

void pcl::Crop::Apply ( pcl::UInt8Image & image ) const

overrideprotectedvirtual

Applies this transformation to an 8-bit unsigned integer image.

Reimplemented from pcl::ImageTransformation.

◆ FillValues()

const DVector& pcl::Crop::FillValues ( ) const

inline

Returns the current vector of per-channel filling values for uncovered image regions.

See the documentation for SetFillValues() for more information.

Definition at line 212 of file Crop.h.

◆ GetNewSizes()

void pcl::Crop::GetNewSizes	(	int &	width,
		int &	height
	)		const

overridevirtual

Predicts transformed image dimensions.

Parameters

[in,out]	width	Reference to a variable whose value is a horizontal dimension in pixels (width). On output, it will receive the predicted horizontal dimension after the transformation.
[in,out]	height	Reference to a variable whose value is a vertical dimension in pixels (height). On output, it will receive the predicted vertical dimension after the transformation.

Note: This is a pure virtual member function that must be reimplemented in every derived class.

Implements pcl::GeometricTransformation.

◆ IsAbsolute()

bool pcl::Crop::IsAbsolute ( ) const

inline

Returns true iff this Crop object interprets its cropping margins as absolute increments. Returns false if cropping margins are interpreted relative to current image dimensions.

Definition at line 193 of file Crop.h.

◆ IsRelative()

bool pcl::Crop::IsRelative ( ) const

inline

Returns true iff this Crop object interprets its cropping margins relative to current image dimensions. Returns false if cropping margins are interpreted as absolute increments.

Definition at line 183 of file Crop.h.

◆ Margins()

DRect pcl::Crop::Margins ( ) const

inline

Returns a rectangle whose components correspond to the current cropping margins of this Crop object.

Definition at line 146 of file Crop.h.

◆ Mode()

crop_mode pcl::Crop::Mode ( ) const

inline

Returns the current cropping mode of this Crop object.

Definition at line 173 of file Crop.h.

◆ operator=()

Crop& pcl::Crop::operator= ( const Crop & )

default

Copy assignment operator. Returns a reference to this object.

◆ SetFillValues()

void pcl::Crop::SetFillValues ( const DVector & fillValues )

inline

Sets a vector of per-channel filling values for uncovered image regions.

Uncovered regions result when a Crop instance extends an image due to positive cropping margins.

By default, there are no filling values defined (and hence the returned vector is empty by default). When the Crop instance is executed and a filling value is not defined for a channel of the target image, uncovered regions are filled with the minimum sample value in the native range of the image (usually zero).

Definition at line 229 of file Crop.h.

◆ SetMargins() [1/2]

template<typename T >

void pcl::Crop::SetMargins ( const GenericRectangle< T > & r )

inline

Sets the cropping margins equal to the components of a specified rectangle r.

Definition at line 156 of file Crop.h.

◆ SetMargins() [2/2]

void pcl::Crop::SetMargins	(	int	left,
		int	top,
		int	right,
		int	bottom
	)

inline

Sets the specified left, top, right and bottom cropping margins.

Definition at line 165 of file Crop.h.

◆ SetMode()

void pcl::Crop::SetMode ( crop_mode mode )

inline

Sets the cropping mode for this Crop object.

Definition at line 201 of file Crop.h.

The documentation for this class was generated from the following file:

Crop.h
