Data items and parameters for Gaia catalog search operations. More...
#include <GaiaDatabaseFile.h>
Inheritance diagram for pcl::GaiaSearchData:
Public Attributes | |
| pcl_bool | normalizeSpectrum = false |
| pcl_bool | photonFluxUnits = false |
| Public Attributes inherited from pcl::XPSD::SearchData< GaiaStarData > | |
| Array< GaiaStarData > | stars |
| The list of stars found by the search operation (output data). | |
| Public Attributes inherited from pcl::XPSD::SearchDataBase | |
| double | centerDec = 0 |
| Field center declination coordinate in degrees (search parameter). | |
| double | centerRA = 0 |
| Field center right ascension coordinate in degrees (search parameter). | |
| uint32 | countIO = 0u |
| Total number of I/O operations performed (output data). | |
| uint32 | excessCount = 0u |
| uint32 | exclusionFlags = 0u |
| uint32 | inclusionFlags = 0u |
| float | magnitudeHigh = 26 |
| float | magnitudeLow = -1.5 |
| double | radius = 1 |
| Field radius in degrees (search parameter). | |
| uint32 | rejectCount = 0u |
| uint32 | requiredFlags = 0u |
| uint32 | sourceLimit = uint32_max |
| double | timeDecode = 0 |
| Time consumed by data decoding in seconds (output data). | |
| double | timeIO = 0 |
| Time consumed by I/O operations in seconds (output data). | |
| double | timeTotal = 0 |
| Total search time in seconds (output data). | |
| double | timeUncompress = 0 |
| Time consumed by data uncompression in seconds (output data). | |
Additional Inherited Members | |
| Public Member Functions inherited from pcl::XPSD::SearchData< GaiaStarData > | |
| void | ResetSearchResults () |
Detailed Description
Definition at line 223 of file GaiaDatabaseFile.h.
Member Data Documentation
◆ normalizeSpectrum
| pcl_bool pcl::GaiaSearchData::normalizeSpectrum = false |
When enabled, search operations provide sampled spectrum data normalized to the [0,1] range for each star. When normalization is disabled, spectrum data is provided in either the original power units of spectral irradiance (W*m^-2*nm^-1), or in spectral photon flux units (ph*s^-1*m^-2*nm^-1) if photonFluxUnits=true. Spectrum normalization is disabled by default.
Definition at line 225 of file GaiaDatabaseFile.h.
◆ photonFluxUnits
| pcl_bool pcl::GaiaSearchData::photonFluxUnits = false |
When true, sampled spectrum data will be transformed to spectral photon flux units (ph*s^-1*m^-2*nm^-1) and then optionally normalized to [0,1] if normalizeSpectrum=true. Photon flux units are disabled by default.
Definition at line 234 of file GaiaDatabaseFile.h.
The documentation for this struct was generated from the following file:
