Base class of all projection systems. More...

#include <ProjectionBase.h>

Inheritance diagram for pcl::ProjectionBase:

Public Member Functions
virtual	~ProjectionBase ()

Vector	CelestialPoleNativeCoordinates () const

virtual ProjectionBase *	Clone () const =0

virtual bool	Direct (DPoint &pW, const DPoint &pRD) const noexcept

virtual void	GetWCS (WCSKeywords &wcs) const

virtual IsoString	Identifier () const =0

virtual bool	Inverse (DPoint &pRD, const DPoint &pW) const noexcept

virtual IsoString	Name () const =0

virtual IsoString	ProjCode () const =0

virtual DPoint	ProjectionOrigin () const

Vector	ReferenceCelestialCoordinates () const

Vector	ReferenceNativeCoordinates () const

Static Public Member Functions
static double	Distance (const DPoint &p1, const DPoint &p2)

static double	DistanceFast (const DPoint &p1, const DPoint &p2)

static IsoString	ProjectionIdentifierToWCSCode (const IsoString &identifier)

static IsoString	WCSCodeToProjectionIdentifier (const IsoString &wcsCode)

Protected Member Functions
	ProjectionBase ()=default

	ProjectionBase (const ProjectionBase &)=default

void	InitFromRefPoint (double lng0, double lat0, const Optional< double > &lonpole=Optional< double >())

void	InitFromWCS (const WCSKeywords &)

virtual bool	Project (DPoint &pW, const DPoint &pN) const noexcept=0

virtual bool	Unproject (DPoint &pN, const DPoint &pW) const noexcept=0

Detailed Description

Definition at line 79 of file ProjectionBase.h.

Constructor & Destructor Documentation

◆ ~ProjectionBase()

virtual pcl::ProjectionBase::~ProjectionBase ( )

inlinevirtual

Virtual destructor.

Definition at line 86 of file ProjectionBase.h.

◆ ProjectionBase() [1/2]

pcl::ProjectionBase::ProjectionBase ( )

protecteddefault

Default constructor.

◆ ProjectionBase() [2/2]

pcl::ProjectionBase::ProjectionBase ( const ProjectionBase & )

protecteddefault

Copy constructor.

Member Function Documentation

◆ CelestialPoleNativeCoordinates()

Vector pcl::ProjectionBase::CelestialPoleNativeCoordinates ( ) const

inline

Returns the native coordinates (longitude and latitude in degrees) of the north celestial pole in this projection system.

The returned value is a vector suitable for XISF property serialization.

Definition at line 214 of file ProjectionBase.h.

References pcl::Deg().

◆ Clone()

virtual ProjectionBase* pcl::ProjectionBase::Clone ( ) const

pure virtual

Returns a dynamically allocated duplicate of this object.

Implemented in pcl::ZenithalProjectionBase, pcl::StereographicProjection, pcl::ZenithalEqualAreaProjection, pcl::PlateCarreeProjection, pcl::OrthographicProjection, pcl::MercatorProjection, pcl::HammerAitoffProjection, and pcl::GnomonicProjection.

◆ Direct()

virtual bool pcl::ProjectionBase::Direct	(	DPoint &	pW,
		const DPoint &	pRD
	)		const

inlinevirtualnoexcept

Transforms from celestial coordinates to world coordinates.

Reimplemented in pcl::GnomonicProjection.

Definition at line 119 of file ProjectionBase.h.

References pcl::IsFinite(), pcl::GenericPoint< T >::x, and pcl::GenericPoint< T >::y.

◆ Distance()

static double pcl::ProjectionBase::Distance	(	const DPoint &	p1,
		const DPoint &	p2
	)

inlinestatic

Returns the distance in degrees between two locations in equatorial coordinates.

Definition at line 161 of file ProjectionBase.h.

References pcl::Abs(), pcl::Rad(), pcl::SinCos(), pcl::GenericPoint< T >::x, and pcl::GenericPoint< T >::y.

◆ DistanceFast()

static double pcl::ProjectionBase::DistanceFast	(	const DPoint &	p1,
		const DPoint &	p2
	)

inlinestatic

Returns the distance in degrees between two locations in equatorial coordinates. Uses an approximate, faster algorithm.

Definition at line 177 of file ProjectionBase.h.

References pcl::ArcCos(), pcl::Cos(), pcl::Deg(), pcl::Rad(), pcl::SinCos(), pcl::GenericPoint< T >::x, and pcl::GenericPoint< T >::y.

◆ GetWCS()

virtual void pcl::ProjectionBase::GetWCS ( WCSKeywords & wcs ) const

virtual

Updates the specified WCS metadata with field values corresponding to this projection.

◆ Identifier()

virtual IsoString pcl::ProjectionBase::Identifier ( ) const

pure virtual

Returns the XISF serializable projection identifier.

Implemented in pcl::ZenithalProjectionBase, pcl::StereographicProjection, pcl::ZenithalEqualAreaProjection, pcl::PlateCarreeProjection, pcl::OrthographicProjection, pcl::MercatorProjection, pcl::HammerAitoffProjection, and pcl::GnomonicProjection.

◆ InitFromRefPoint()

void pcl::ProjectionBase::InitFromRefPoint	(	double	lng0,
		double	lat0,
		const Optional< double > &	lonpole = `Optional< double >()`
	)

protected

Initialization from reference celestial coordinates and optional native longitude of the celestial pole.

◆ InitFromWCS()

void pcl::ProjectionBase::InitFromWCS ( const WCSKeywords & )

protected

Initialization from WCS metadata.

◆ Inverse()

virtual bool pcl::ProjectionBase::Inverse	(	DPoint &	pRD,
		const DPoint &	pW
	)		const

inlinevirtualnoexcept

Transforms from world coordinates to celestial coordinates.

Reimplemented in pcl::GnomonicProjection.

Definition at line 128 of file ProjectionBase.h.

References pcl::IsFinite(), pcl::GenericPoint< T >::x, and pcl::GenericPoint< T >::y.

◆ Name()

virtual IsoString pcl::ProjectionBase::Name ( ) const

pure virtual

Returns the readable name of this projection system.

Implemented in pcl::ZenithalProjectionBase, pcl::StereographicProjection, pcl::ZenithalEqualAreaProjection, pcl::PlateCarreeProjection, pcl::OrthographicProjection, pcl::MercatorProjection, pcl::HammerAitoffProjection, and pcl::GnomonicProjection.

◆ ProjCode()

virtual IsoString pcl::ProjectionBase::ProjCode ( ) const

pure virtual

Returns the FITS WCS projection identifier for this projection system.

Implemented in pcl::ZenithalProjectionBase, pcl::StereographicProjection, pcl::ZenithalEqualAreaProjection, pcl::PlateCarreeProjection, pcl::OrthographicProjection, pcl::MercatorProjection, pcl::HammerAitoffProjection, and pcl::GnomonicProjection.

◆ Project()

virtual bool pcl::ProjectionBase::Project	(	DPoint &	pW,
		const DPoint &	pN
	)		const

protectedpure virtualnoexcept

Transforms from world coordinates to native spherical coordinates.

Implemented in pcl::ZenithalProjectionBase, pcl::PlateCarreeProjection, pcl::OrthographicProjection, pcl::MercatorProjection, pcl::HammerAitoffProjection, and pcl::GnomonicProjection.

◆ ProjectionIdentifierToWCSCode()

static IsoString pcl::ProjectionBase::ProjectionIdentifierToWCSCode ( const IsoString & identifier )

static

Returns the standard FITS WCS projection code corresponding to the specified XISF projection identifier.

◆ ProjectionOrigin()

virtual DPoint pcl::ProjectionBase::ProjectionOrigin ( ) const

inlinevirtual

Returns the equatorial coordinates of the projection origin.

Definition at line 152 of file ProjectionBase.h.

References pcl::Deg().

◆ ReferenceCelestialCoordinates()

Vector pcl::ProjectionBase::ReferenceCelestialCoordinates ( ) const

inline

Returns the celestial equatorial coordinates (right ascension and declination in degrees) of the reference point of this projection system.

The returned value is a vector suitable for XISF property serialization.

Definition at line 192 of file ProjectionBase.h.

References pcl::Deg().

◆ ReferenceNativeCoordinates()

Vector pcl::ProjectionBase::ReferenceNativeCoordinates ( ) const

inline

Returns the native coordinates (longitude and latitude in degrees) of the reference point of this projection system.

The returned value is a vector suitable for XISF property serialization.

Definition at line 203 of file ProjectionBase.h.

◆ Unproject()

virtual bool pcl::ProjectionBase::Unproject	(	DPoint &	pN,
		const DPoint &	pW
	)		const

protectedpure virtualnoexcept

Transforms from native spherical coordinates to world coordinates.

Implemented in pcl::ZenithalProjectionBase, pcl::PlateCarreeProjection, pcl::OrthographicProjection, pcl::MercatorProjection, pcl::HammerAitoffProjection, and pcl::GnomonicProjection.

◆ WCSCodeToProjectionIdentifier()

static IsoString pcl::ProjectionBase::WCSCodeToProjectionIdentifier ( const IsoString & wcsCode )

static

Returns the XISF projection identifier corresponding to the specified FITS WCS projection code.

The documentation for this class was generated from the following file:

ProjectionBase.h
