pcl::ICCProfileTransformation Class Reference

Conversion of pixel values between ICC profile color spaces. More...

#include <ICCProfileTransformation.h>

Inheritance diagram for pcl::ICCProfileTransformation:

Public Types
using	profile_list = Array< ICCProfile::handle >
using	rendering_intent = ICCRenderingIntent::value_type
using	transformation_handle = void *

Public Member Functions
	ICCProfileTransformation ()=default
	ICCProfileTransformation (const ICCProfileTransformation &)=delete
	ICCProfileTransformation (ICCProfileTransformation &&x)
	~ICCProfileTransformation () override
void	Add (const ICCProfile &profile)
void	Add (const ICCProfile::handle profileHandle)
void	Add (const String &profilePath)
void	Clear ()
void	Create ()
void	DisableBlackPointCompensation (bool disable=true)
void	DisableHighResolutionCLUT (bool disable=true)
void	DisableLowResolutionCLUT (bool disable=true)
void	EnableBlackPointCompensation (bool enable=true)
void	EnableHighResolutionCLUT (bool enable=true)
void	EnableLowResolutionCLUT (bool enable=true)
void	ForceFloatingPointTransformation (bool force=true)
bool	ForcesFloatingPointTransformation () const
bool	IsProofingTransformation () const
bool	IsSourceRGBProfile () const
bool	IsTargetRGBProfile () const
bool	IsValid () const
ICCProfileTransformation &	operator= (const ICCProfileTransformation &)=delete
ICCProfileTransformation &	operator= (ICCProfileTransformation &&x)
const profile_list &	Profiles () const
void	RelaxFloatingPointTransformation (bool relax=true)
rendering_intent	RenderingIntent () const
void	SetRenderingIntent (rendering_intent i)
bool	UsingBlackPointCompensation () const
bool	UsingHighResolutionCLUT () const
bool	UsingLowResolutionCLUT () const
Public Member Functions inherited from pcl::ImageTransformation
	ImageTransformation ()=default
	ImageTransformation (const ImageTransformation &)=default
virtual	~ImageTransformation ()
template<class P >
GenericImage< P > &	operator>> (GenericImage< P > &image) const
ImageVariant &	operator>> (ImageVariant &image) const
Public Member Functions inherited from pcl::ParallelProcess
	ParallelProcess ()=default
	ParallelProcess (const ParallelProcess &)=default
virtual	~ParallelProcess ()
void	DisableParallelProcessing (bool disable=true) noexcept
void	EnableParallelProcessing (bool enable=true, int maxProcessors=0) noexcept
bool	IsParallelProcessingEnabled () const noexcept
int	MaxProcessors () const noexcept
ParallelProcess &	operator= (const ParallelProcess &)=default
void	SetMaxProcessors (int maxProcessors) noexcept
void	Swap (ParallelProcess &process) noexcept

Protected Member Functions
void	Apply (pcl::DImage &) const override
void	Apply (pcl::Image &) const override
void	Apply (pcl::UInt16Image &) const override
void	Apply (pcl::UInt32Image &) const override
void	Apply (pcl::UInt8Image &) const override
Protected Member Functions inherited from pcl::ImageTransformation
virtual void	Apply (pcl::ComplexImage &image) const
virtual void	Apply (pcl::DComplexImage &image) const

Detailed Description

ICCProfileTransformation is a portable color transformation based on ICC color profiles. This class is a high-level interface to the color management functionality implemented in the PixInsight core application.

ICCProfileTransformation implements simple profile-to-profile color transformations, multiprofile transformations, and device proofing transformations with out-of-gamut checks.

See also

ICCProfile, ImageTransformation

Definition at line 94 of file ICCProfileTransformation.h.

Member Typedef Documentation

profile_list

using pcl::ICCProfileTransformation::profile_list = Array<ICCProfile::handle>

Represents a list of handles to open ICC profiles.

Definition at line 111 of file ICCProfileTransformation.h.

rendering_intent

using pcl::ICCProfileTransformation::rendering_intent = ICCRenderingIntent::value_type

Represents an ICC rendering intent.

Definition at line 101 of file ICCProfileTransformation.h.

transformation_handle

using pcl::ICCProfileTransformation::transformation_handle = void*

Represents an opaque handle to a server-side ICC transformation.

Definition at line 106 of file ICCProfileTransformation.h.

Constructor & Destructor Documentation

ICCProfileTransformation() [1/3]

pcl::ICCProfileTransformation::ICCProfileTransformation ( )

default

Constructs an empty ICCPRofileTransformation object.

ICCProfileTransformation() [2/3]

pcl::ICCProfileTransformation::ICCProfileTransformation ( ICCProfileTransformation &&  x )

inline

Move constructor.

Definition at line 121 of file ICCProfileTransformation.h.

ICCProfileTransformation() [3/3]

pcl::ICCProfileTransformation::ICCProfileTransformation ( const ICCProfileTransformation &  )

delete

Copy constructor. This constructor is disabled because ICC color profile transformations are unique objects.

~ICCProfileTransformation()

pcl::ICCProfileTransformation::~ICCProfileTransformation ( )

inlineoverride

Destroys an ICCPRofileTransformation object.

Definition at line 180 of file ICCProfileTransformation.h.

Member Function Documentation

Add() [1/3]

void pcl::ICCProfileTransformation::Add

(

const ICCProfile &

profile

)

Adds the specified ICC profile to this ICC profile transformation.

Add() [2/3]

void pcl::ICCProfileTransformation::Add

(

const ICCProfile::handle

profileHandle

)

Adds an already open ICC profile profileHandle to this ICC profile transformation.

Add() [3/3]

void pcl::ICCProfileTransformation::Add

(

const String &

profilePath

)

Loads an ICC profile from a file at profilePath and adds it to this ICC profile transformation.

Apply() [1/5]

void pcl::ICCProfileTransformation::Apply ( pcl::DImage &  image ) const

overrideprotectedvirtual

Applies this transformation to a 64-bit floating point image.

Reimplemented from pcl::ImageTransformation.

Apply() [2/5]

void pcl::ICCProfileTransformation::Apply ( pcl::Image &  image ) const

overrideprotectedvirtual

Applies this transformation to a 32-bit floating point image.

Reimplemented from pcl::ImageTransformation.

Apply() [3/5]

void pcl::ICCProfileTransformation::Apply ( pcl::UInt16Image &  image ) const

overrideprotectedvirtual

Applies this transformation to a 16-bit unsigned integer image.

Reimplemented from pcl::ImageTransformation.

Apply() [4/5]

void pcl::ICCProfileTransformation::Apply ( pcl::UInt32Image &  image ) const

overrideprotectedvirtual

Applies this transformation to a 32-bit unsigned integer image.

Reimplemented from pcl::ImageTransformation.

Apply() [5/5]

void pcl::ICCProfileTransformation::Apply ( pcl::UInt8Image &  image ) const

overrideprotectedvirtual

Applies this transformation to an 8-bit unsigned integer image.

Reimplemented from pcl::ImageTransformation.

Clear()

void pcl::ICCProfileTransformation::Clear

(

)

Resets this ICCProfileTransformation object to a default state.

The list of ICC profiles is cleared and the underlying transformation and all associated data structures are destroyed.

Create()

void pcl::ICCProfileTransformation::Create ( )

inline

Forces the immediate creation (or re-creation) of the underlying low-level transformation.

You normally shouldn't need to call this member function, since ICCProfileTransformation automatically creates the necessary low-level transformations at the points they are required.

Definition at line 406 of file ICCProfileTransformation.h.

DisableBlackPointCompensation()

void pcl::ICCProfileTransformation::DisableBlackPointCompensation ( bool  disable = true )

inline

Disables or enables black point compensation for this ICC profile transformation.

This is a convenience member function, equivalent to EnableBlackPointCompensation( !disable )

Definition at line 274 of file ICCProfileTransformation.h.

DisableHighResolutionCLUT()

void pcl::ICCProfileTransformation::DisableHighResolutionCLUT ( bool  disable = true )

inline

Disables or enables usage of high-resolution CLUT tables for this ICC profile transformation.

This is a convenience member function, equivalent to EnableHighResolutionCLUT( !disable )

Definition at line 348 of file ICCProfileTransformation.h.

DisableLowResolutionCLUT()

void pcl::ICCProfileTransformation::DisableLowResolutionCLUT ( bool  disable = true )

inline

Disables or enables usage of low-resolution color lookup tables (CLUTs) in this ICC color transformation.

This is a convenience member function, equivalent to EnableLowResolutionCLUT( !disable )

Definition at line 385 of file ICCProfileTransformation.h.

EnableBlackPointCompensation()

void pcl::ICCProfileTransformation::EnableBlackPointCompensation ( bool  enable = true )

inline

Enables or disables black point compensation for this ICC profile transformation.

When not enabled explicitly with this function, no black point compensation is applied by default.

Definition at line 261 of file ICCProfileTransformation.h.

EnableHighResolutionCLUT()

void pcl::ICCProfileTransformation::EnableHighResolutionCLUT ( bool  enable = true )

inline

Enables or disables usage of high-resolution CLUT tables for this ICC profile transformation.

Definition at line 334 of file ICCProfileTransformation.h.

EnableLowResolutionCLUT()

void pcl::ICCProfileTransformation::EnableLowResolutionCLUT ( bool  enable = true )

inline

Enables or disables usage of low-resolution color lookup tables (CLUTs) in this ICC color transformation.

Definition at line 371 of file ICCProfileTransformation.h.

ForceFloatingPointTransformation()

void pcl::ICCProfileTransformation::ForceFloatingPointTransformation ( bool  force = true )

inline

Enables or disables enforcement of floating point computations for this ICC profile transformation.

Definition at line 298 of file ICCProfileTransformation.h.

ForcesFloatingPointTransformation()

bool pcl::ICCProfileTransformation::ForcesFloatingPointTransformation ( ) const

inline

Returns true iff this ICC profile transformation forces the use of floating point operations for computation of transformed pixel samples of all numerical data types.

When this option is disabled (which is its default state), 16-bit integer arithmetics will be used for 8-bit and 16-bit integer images. Floating point will always be used for the rest of images, irrespective of the state of this option, in order to preserve numerical accuracy.

Definition at line 289 of file ICCProfileTransformation.h.

IsProofingTransformation()

bool pcl::ICCProfileTransformation::IsProofingTransformation ( ) const

inline

Returns true iff this object represents a device proofing transformation.

Definition at line 393 of file ICCProfileTransformation.h.

IsSourceRGBProfile()

bool pcl::ICCProfileTransformation::IsSourceRGBProfile ( ) const

inline

Returns true iff the starting ICC profile in this transformation is a RGB profile.

Definition at line 436 of file ICCProfileTransformation.h.

IsTargetRGBProfile()

bool pcl::ICCProfileTransformation::IsTargetRGBProfile ( ) const

inline

Returns true iff the target (last) ICC profile in this transformation is a RGB profile.

Definition at line 445 of file ICCProfileTransformation.h.

IsValid()

bool pcl::ICCProfileTransformation::IsValid ( ) const

inline

Returns true iff this object represents a valid color space transformation based on ICC color profiles.

For this member function to return true, the underlying low-level transformation should have been created, either implicitly by using this object to apply a color transformation, or explicitly by calling Create().

Definition at line 211 of file ICCProfileTransformation.h.

operator=() [1/2]

ICCProfileTransformation& pcl::ICCProfileTransformation::operator= ( const ICCProfileTransformation &  )

delete

Copy assignment. This operator is disabled because ICC color profile transformations are unique objects.

operator=() [2/2]

ICCProfileTransformation& pcl::ICCProfileTransformation::operator= ( ICCProfileTransformation &&  x )

inline

Move assignment operator. Returns a reference to this object.

Definition at line 144 of file ICCProfileTransformation.h.

Profiles()

const profile_list& pcl::ICCProfileTransformation::Profiles ( ) const

inline

Returns a reference to the immutable list of ICC profiles in this ICC profile transformation.

Definition at line 220 of file ICCProfileTransformation.h.

RelaxFloatingPointTransformation()

void pcl::ICCProfileTransformation::RelaxFloatingPointTransformation ( bool  relax = true )

inline

Disables or enables enforcement of floating point computations for this ICC profile transformation.

This is a convenience member function, equivalent to ForceFloatingPointTransformation( !relax )

Definition at line 311 of file ICCProfileTransformation.h.

RenderingIntent()

rendering_intent pcl::ICCProfileTransformation::RenderingIntent ( ) const

inline

Returns the ICC rendering intent for this ICC profile transformation.

Definition at line 228 of file ICCProfileTransformation.h.

SetRenderingIntent()

void pcl::ICCProfileTransformation::SetRenderingIntent ( rendering_intent  i )

inline

Sets the ICC rendering intent for this ICC profile transformation.

When no intent is set explicitly with this function, the default rendering intent is ICCRenderingIntent::Perceptual.

Definition at line 239 of file ICCProfileTransformation.h.

UsingBlackPointCompensation()

bool pcl::ICCProfileTransformation::UsingBlackPointCompensation ( ) const

inline

Returns true iff this ICC profile transformation applies a black point compensation algorithm.

Definition at line 249 of file ICCProfileTransformation.h.

UsingHighResolutionCLUT()

bool pcl::ICCProfileTransformation::UsingHighResolutionCLUT ( ) const

inline

Returns true iff this ICC profile transformation uses high-resolution color lookup tables (CLUTs) for precalculation of device link functions.

Disabling high-resolution CLUTs may provide a (usually small) speed improvement.

By default, ICCProfileTransformation uses high-resolution CLUTs.

Definition at line 325 of file ICCProfileTransformation.h.

UsingLowResolutionCLUT()

bool pcl::ICCProfileTransformation::UsingLowResolutionCLUT ( ) const

inline

Returns true iff this ICC profile transformation uses low-resolution color lookup tables (CLUTs) for precalculation of device link functions.

Enabling low-resolution CLUTs may provide a (usually small) speed improvement.

By default, ICCProfileTransformation uses high-resolution CLUTs.

Definition at line 362 of file ICCProfileTransformation.h.

---

The documentation for this class was generated from the following file:

• ICCProfileTransformation.h
