Generic array of vectors. More...

#include <MultiVector.h>

Inheritance diagram for pcl::GenericMultiVector< T >:

Public Types
using	component = typename vector::component

using	const_iterator = typename multivector_implementation::const_iterator

using	const_vector_iterator = typename vector::const_iterator

using	iterator = typename multivector_implementation::iterator

using	multivector_implementation = Array< GenericVector< T > >

using	scalar = typename vector::scalar

using	vector = GenericVector< T >

using	vector_iterator = typename vector::iterator

Public Types inherited from pcl::Array< GenericVector< T > >
using	allocator = pcl::Allocator< GenericVector< T >, StandardAllocator >

using	block_allocator = StandardAllocator

using	const_iterator = const GenericVector< T > *

using	const_reverse_iterator = ReverseRandomAccessIterator< const_iterator, const GenericVector< T > >

using	iterator = GenericVector< T > *

using	reverse_iterator = ReverseRandomAccessIterator< iterator, GenericVector< T > >

Public Member Functions
	GenericMultiVector ()=default

	GenericMultiVector (const GenericMultiVector &)=default

	GenericMultiVector (const scalar &value, size_type length, int vectorLength)

	GenericMultiVector (const vector &v0, const vector &v1)

	GenericMultiVector (const vector &v0, const vector &v1, const vector &v2)

	GenericMultiVector (const vector &v0, const vector &v1, const vector &v2, const vector &v3)

	GenericMultiVector (GenericMultiVector &&)=default

	GenericMultiVector (size_type length)

	GenericMultiVector (size_type length, int vectorLength)

	~GenericMultiVector ()

component	MaxComponent () const

component	MinComponent () const

GenericMultiVector &	operator*= (const scalar &x)

GenericMultiVector &	operator+= (const scalar &x)

GenericMultiVector &	operator-= (const scalar &x)

GenericMultiVector &	operator/= (const scalar &x)

GenericMultiVector &	operator= (const GenericMultiVector &)=default

GenericMultiVector &	operator= (const scalar &x)

GenericMultiVector &	operator= (GenericMultiVector &&)=default

double	StableSum () const

double	Sum () const

Public Member Functions inherited from pcl::Array< GenericVector< T > >
	Array ()

	Array (Array &&x)

	Array (const Array &x)

	Array (FI i, FI j)

	Array (size_type n)

	Array (size_type n, const GenericVector< T > &v)

	Array (std::initializer_list< T1 > l)

	~Array ()

void	Add (const Array &x)

void	Add (const GenericVector< T > &v, size_type n=1)

void	Add (FI p, FI q)

const allocator &	Allocator () const noexcept

void	Append (const Array &x)

void	Append (const GenericVector< T > &v, size_type n=1)

void	Append (FI p, FI q)

void	Apply (F f)

void	Apply (F f) const noexcept(noexcept(f))

void	Assign (const Array &x)

void	Assign (const GenericVector< T > &v, size_type n=1)

void	Assign (FI i, FI j)

iterator	At (size_type i)

const_iterator	At (size_type i) const noexcept

size_type	Available () const noexcept

iterator	Begin ()

iterator	begin ()

const_iterator	Begin () const noexcept

const_iterator	begin () const noexcept

size_type	Capacity () const noexcept

void	Clear ()

const_iterator	ConstBegin () const noexcept

const_iterator	ConstEnd () const noexcept

const_reverse_iterator	ConstReverseBegin () const noexcept

const_reverse_iterator	ConstReverseEnd () const noexcept

bool	Contains (const GenericVector< T > &v) const noexcept

bool	Contains (const GenericVector< T > &v, BP p) const noexcept(noexcept(p))

iterator	ContainsSubset (const C &c) const noexcept

iterator	ContainsSubset (const C &c, BP p) const noexcept(noexcept(p))

iterator	ContainsSubset (FI i, FI j) const noexcept

iterator	ContainsSubset (FI i, FI j, BP p) const noexcept(noexcept(p))

size_type	Count (const GenericVector< T > &v) const noexcept

size_type	Count (const GenericVector< T > &v, BP p) const noexcept(noexcept(p))

size_type	CountIf (UP p) const noexcept(noexcept(p))

iterator	End ()

iterator	end ()

const_iterator	End () const noexcept

const_iterator	end () const noexcept

void	EnsureUnique ()

iterator	Expand (size_type n=1)

void	Fill (const GenericVector< T > &v)

iterator	FirstThat (F f)

const_iterator	FirstThat (F f) const noexcept(noexcept(f))

iterator	Grow (iterator i, size_type n=1)

uint64	Hash (uint64 seed=0) const noexcept

uint32	Hash32 (uint32 seed=0) const noexcept

uint64	Hash64 (uint64 seed=0) const

void	Import (iterator i, iterator j)

iterator	Insert (iterator i, const Array &x)

iterator	Insert (iterator i, const GenericVector< T > &v, size_type n=1)

iterator	Insert (iterator i, FI p, FI q)

bool	IsAliasOf (const Array &x) const noexcept

bool	IsEmpty () const noexcept

bool	IsUnique () const noexcept

bool	IsValid () const noexcept

const_iterator	LastThat (F f) const noexcept(noexcept(f))

size_type	Length () const noexcept

size_type	LowerBound () const noexcept

iterator	MaxItem ()

const_iterator	MaxItem () const noexcept

iterator	MaxItem (BP p)

const_iterator	MaxItem (BP p) const noexcept(noexcept(p))

iterator	MinItem ()

const_iterator	MinItem () const noexcept

iterator	MinItem (BP p)

const_iterator	MinItem (BP p) const noexcept(noexcept(p))

iterator	MutableIterator (const_iterator i)

GenericVector< T > &	operator* ()

const GenericVector< T > &	operator* () const noexcept

Array &	operator= (Array &&x)

Array &	operator= (const Array &x)

GenericVector< T > &	operator[] (size_type i)

const GenericVector< T > &	operator[] (size_type i) const noexcept

void	Prepend (const Array &x)

void	Prepend (const GenericVector< T > &v, size_type n=1)

void	Prepend (FI p, FI q)

iterator	Release ()

void	Remove (const GenericVector< T > &v)

void	Remove (const GenericVector< T > &v, BP p)

void	Remove (iterator i, iterator j)

void	Remove (iterator i, size_type n=1)

void	RemoveFirst (size_type n=1)

void	RemoveLast (size_type n=1)

iterator	Replace (iterator i, iterator j, const Array &x)

iterator	Replace (iterator i, iterator j, const GenericVector< T > &v, size_type n=1)

iterator	Replace (iterator i, iterator j, FI p, FI q)

void	Reserve (size_type n)

void	Resize (size_type n)

void	Reverse ()

reverse_iterator	ReverseBegin ()

const_reverse_iterator	ReverseBegin () const noexcept

reverse_iterator	ReverseEnd ()

const_reverse_iterator	ReverseEnd () const noexcept

void	Rotate (distance_type n)

iterator	Search (const GenericVector< T > &v)

const_iterator	Search (const GenericVector< T > &v) const noexcept

iterator	Search (const GenericVector< T > &v, BP p)

const_iterator	Search (const GenericVector< T > &v, BP p) const noexcept(noexcept(p))

iterator	SearchLast (const GenericVector< T > &v)

const_iterator	SearchLast (const GenericVector< T > &v) const noexcept

iterator	SearchLast (const GenericVector< T > &v, BP p)

const_iterator	SearchLast (const GenericVector< T > &v, BP p) const noexcept(noexcept(p))

iterator	SearchLastSubset (BI i, BI j)

const_iterator	SearchLastSubset (BI i, BI j) const noexcept

iterator	SearchLastSubset (BI i, BI j, BP p)

const_iterator	SearchLastSubset (BI i, BI j, BP p) const noexcept(noexcept(p))

iterator	SearchLastSubset (const C &x)

const_iterator	SearchLastSubset (const C &x) const noexcept

iterator	SearchLastSubset (const C &x, BP p)

const_iterator	SearchLastSubset (const C &x, BP p) const noexcept(noexcept(p))

iterator	SearchSubset (const C &x)

const_iterator	SearchSubset (const C &x) const noexcept

iterator	SearchSubset (const C &x, BP p)

const_iterator	SearchSubset (const C &x, BP p) const noexcept(noexcept(p))

iterator	SearchSubset (FI i, FI j)

const_iterator	SearchSubset (FI i, FI j) const noexcept

iterator	SearchSubset (FI i, FI j, BP p)

const_iterator	SearchSubset (FI i, FI j, BP p) const noexcept(noexcept(p))

void	SecureFill (const GenericVector< T > &v)

void	SetAllocator (const allocator &a)

void	ShiftLeft (const GenericVector< T > &v, size_type n=1)

void	ShiftRight (const GenericVector< T > &v, size_type n=1)

void	Shrink (size_type n=1)

size_type	Size () const noexcept

void	Sort ()

void	Sort (BP p)

void	Squeeze ()

S &	ToCommaSeparated (S &s) const

S &	ToNewLineSeparated (S &s) const

S &	ToSeparated (S &s, SP separator) const

S &	ToSeparated (S &s, SP separator, AF append) const

S &	ToSpaceSeparated (S &s) const

S &	ToTabSeparated (S &s) const

void	Transfer (Array &&x)

void	Transfer (Array &x)

void	Truncate (iterator i)

void	UniquifyIterator (iterator &i)

void	UniquifyIterators (iterator &i, iterator &j)

size_type	UpperBound () const noexcept

Detailed Description

template<typename T>
class pcl::GenericMultiVector< T >

A multivector is a dynamic array of vectors. It can also be seen as a vector of vectors, or a vector whose components are also vectors. GenericMultiVector implements a homogeneous multivector based on the Array and GenericVector template classes. Besides all the member functions inherited from its base class, it also provides some useful constructors and assignment operators, including arithmetic scalar-to-vector operators that work on all the contained vectors as a whole.

Some typical applications of multivectors include:

Implementation of more sophisticated mathematical objects and structures, such as tensors.

Matrices where rows (or equivalently, columns) have to be manipulated as independent structures. For example, to swap two rows of a GenericMatrix you have to swap each pair of row elements successively, which is an O(N) operation. Swapping two component vectors of a multivector is an O(1) operation thanks to the implicit data sharing feature of GenericVector, and hence does not require copying or duplicating data.

Arrays and matrices where each component is a vector of variable length.

As most PCL containers, GenericMultiVector is a reference-counted class with implicit data sharing (or copy-on-write) functionality.

See also: Array, GenericVector, GenericMatrix

Definition at line 100 of file MultiVector.h.

Member Typedef Documentation

◆ component

template<typename T >

using pcl::GenericMultiVector< T >::component = typename vector::component

Represents a vector component.

Definition at line 122 of file MultiVector.h.

◆ const_iterator

template<typename T >

using pcl::GenericMultiVector< T >::const_iterator = typename multivector_implementation::const_iterator

Represents an immutable multivector iterator.

Definition at line 132 of file MultiVector.h.

◆ const_vector_iterator

template<typename T >

using pcl::GenericMultiVector< T >::const_vector_iterator = typename vector::const_iterator

Represents an immutable vector iterator.

Definition at line 142 of file MultiVector.h.

◆ iterator

template<typename T >

using pcl::GenericMultiVector< T >::iterator = typename multivector_implementation::iterator

Represents a mutable multivector iterator.

Definition at line 127 of file MultiVector.h.

◆ multivector_implementation

template<typename T >

using pcl::GenericMultiVector< T >::multivector_implementation = Array<GenericVector<T> >

The structure implementing this multivector class.

Definition at line 107 of file MultiVector.h.

◆ scalar

template<typename T >

using pcl::GenericMultiVector< T >::scalar = typename vector::scalar

Represents a scalar.

Definition at line 117 of file MultiVector.h.

◆ vector

template<typename T >

using pcl::GenericMultiVector< T >::vector = GenericVector<T>

Represents a vector.

Definition at line 112 of file MultiVector.h.

◆ vector_iterator

template<typename T >

using pcl::GenericMultiVector< T >::vector_iterator = typename vector::iterator

Represents a mutable vector iterator.

Definition at line 137 of file MultiVector.h.

Constructor & Destructor Documentation

◆ GenericMultiVector() [1/9]

template<typename T >

pcl::GenericMultiVector< T >::GenericMultiVector ( )

default

Constructs an empty multivector. An empty multivector has no component vectors and zero length.

◆ GenericMultiVector() [2/9]

template<typename T >

pcl::GenericMultiVector< T >::GenericMultiVector ( size_type length )

inline

Constructs an uninitialized multivector of the specified length.

This constructor does not initialize component vectors. The newly created multivector will contain length empty vectors.

Definition at line 156 of file MultiVector.h.

◆ GenericMultiVector() [3/9]

template<typename T >

pcl::GenericMultiVector< T >::GenericMultiVector	(	size_type	length,
		int	vectorLength
	)

inline

Constructs a multivector with uninitialized component vectors.

Parameters

length	Number of multivector components.
vectorLength	Number of vector components (>= 0).

This constructor does not initialize vector components. The newly created vectors will contain unpredictable values.

Definition at line 171 of file MultiVector.h.

◆ GenericMultiVector() [4/9]

template<typename T >

pcl::GenericMultiVector< T >::GenericMultiVector	(	const scalar &	value,
		size_type	length,
		int	vectorLength
	)

inline

Constructs a multivector and fills it with a constant scalar.

Parameters

value	Initial value for all vector components.
length	Number of multivector components.
vectorLength	Number of vector components (>= 0).

Definition at line 187 of file MultiVector.h.

◆ GenericMultiVector() [5/9]

template<typename T >

pcl::GenericMultiVector< T >::GenericMultiVector	(	const vector &	v0,
		const vector &	v1
	)

inline

Constructs a multivector of two components initialized with copies of the specified vectors v0 and v1, respectively for the first and second component vectors.

Definition at line 199 of file MultiVector.h.

◆ GenericMultiVector() [6/9]

template<typename T >

pcl::GenericMultiVector< T >::GenericMultiVector	(	const vector &	v0,
		const vector &	v1,
		const vector &	v2
	)

inline

Constructs a multivector of three components initialized with copies of the specified vectors v0, v1 and v2, respectively for the first, second and third component vectors.

Definition at line 211 of file MultiVector.h.

◆ GenericMultiVector() [7/9]

template<typename T >

pcl::GenericMultiVector< T >::GenericMultiVector	(	const vector &	v0,
		const vector &	v1,
		const vector &	v2,
		const vector &	v3
	)

inline

Constructs a multivector of four components initialized with copies of the specified vectors v0, v1, v2 and v3, respectively for the first, second, third and fourth component vectors.

Definition at line 223 of file MultiVector.h.

◆ GenericMultiVector() [8/9]

template<typename T >

pcl::GenericMultiVector< T >::GenericMultiVector ( const GenericMultiVector< T > & )

default

Copy constructor.

◆ GenericMultiVector() [9/9]

template<typename T >

pcl::GenericMultiVector< T >::GenericMultiVector ( GenericMultiVector< T > && )

default

Move constructor.

◆ ~GenericMultiVector()

template<typename T >

pcl::GenericMultiVector< T >::~GenericMultiVector ( )

inline

Destroys a GenericMultiVector object.

Definition at line 243 of file MultiVector.h.

Member Function Documentation

◆ MaxComponent()

template<typename T >

component pcl::GenericMultiVector< T >::MaxComponent ( ) const

inline

Returns the value of the largest vector component. For empty multivectors, this function returns zero.

Definition at line 358 of file MultiVector.h.

◆ MinComponent()

template<typename T >

component pcl::GenericMultiVector< T >::MinComponent ( ) const

inline

Returns the value of the smallest vector component. For empty multivectors, this function returns zero.

Definition at line 342 of file MultiVector.h.

◆ operator*=()

template<typename T >

GenericMultiVector& pcl::GenericMultiVector< T >::operator*= ( const scalar & x )

inline

Multiplies all vector components in this multivector by a constant scalar x. Returns a reference to this object.

Definition at line 294 of file MultiVector.h.

◆ operator+=()

template<typename T >

GenericMultiVector& pcl::GenericMultiVector< T >::operator+= ( const scalar & x )

inline

Adds a constant scalar x to all vector components in this multivector. Returns a reference to this object.

Definition at line 272 of file MultiVector.h.

◆ operator-=()

template<typename T >

GenericMultiVector& pcl::GenericMultiVector< T >::operator-= ( const scalar & x )

inline

Subtracts a constant scalar x from all vector components of this multivector. Returns a reference to this object.

Definition at line 283 of file MultiVector.h.

◆ operator/=()

template<typename T >

GenericMultiVector& pcl::GenericMultiVector< T >::operator/= ( const scalar & x )

inline

Divides all vector components in this multivector by a constant scalar x. Returns a reference to this object.

Definition at line 305 of file MultiVector.h.

◆ operator=() [1/3]

template<typename T >

GenericMultiVector& pcl::GenericMultiVector< T >::operator= ( const GenericMultiVector< T > & )

default

Copy assignment operator. Returns a reference to this object.

◆ operator=() [2/3]

template<typename T >

GenericMultiVector& pcl::GenericMultiVector< T >::operator= ( const scalar & x )

inline

Assigns a constant scalar x to all vector components in this multivector. Returns a reference to this object.

Definition at line 261 of file MultiVector.h.

◆ operator=() [3/3]

template<typename T >

GenericMultiVector& pcl::GenericMultiVector< T >::operator= ( GenericMultiVector< T > && )

default

Move assignment operator. Returns a reference to this object.

◆ StableSum()

template<typename T >

double pcl::GenericMultiVector< T >::StableSum ( ) const

inline

Computes the sum of vector components using a numerically stable summation algorithm to minimize roundoff error.

Definition at line 327 of file MultiVector.h.

◆ Sum()

template<typename T >

double pcl::GenericMultiVector< T >::Sum ( ) const

inline

Returns the sum of all vector components.

Definition at line 315 of file MultiVector.h.

The documentation for this class was generated from the following file:

MultiVector.h

Public Types

Public Member Functions

Detailed Description

template<typename T> class pcl::GenericMultiVector< T >

Member Typedef Documentation

◆ component

◆ const_iterator

◆ const_vector_iterator

◆ iterator

◆ multivector_implementation

◆ scalar

◆ vector

◆ vector_iterator

Constructor & Destructor Documentation

◆ GenericMultiVector() [1/9]

◆ GenericMultiVector() [2/9]

◆ GenericMultiVector() [3/9]

◆ GenericMultiVector() [4/9]

◆ GenericMultiVector() [5/9]

◆ GenericMultiVector() [6/9]

◆ GenericMultiVector() [7/9]

◆ GenericMultiVector() [8/9]

◆ GenericMultiVector() [9/9]

◆ ~GenericMultiVector()

Member Function Documentation

◆ MaxComponent()

◆ MinComponent()

◆ operator*=()

◆ operator+=()

◆ operator-=()

◆ operator/=()

◆ operator=() [1/3]

◆ operator=() [2/3]

◆ operator=() [3/3]

◆ StableSum()

◆ Sum()

template<typename T>
class pcl::GenericMultiVector< T >
