Out-of-place discrete Fourier transform of two-dimensional images. More...

#include <FourierTransform.h>

Inheritance diagram for pcl::FourierTransform:

Public Member Functions
	FourierTransform ()=default

	FourierTransform (const FourierTransform &)=default

	FourierTransform (FourierTransform &&)=default

	~FourierTransform () override

void	Clear ()

ImageVariant &	DFT ()

const ImageVariant &	DFT () const

ImageVariant &	operator* ()

const ImageVariant &	operator* () const

FourierTransform &	operator= (const FourierTransform &)=default

FourierTransform &	operator= (FourierTransform &&)=default

ImageVariant	ReleaseTransform ()

Public Member Functions inherited from pcl::BidirectionalImageTransformation
	BidirectionalImageTransformation ()=default

	BidirectionalImageTransformation (const BidirectionalImageTransformation &)=default

	~BidirectionalImageTransformation () override

template<class P >
const GenericImage< P > &	operator<< (const GenericImage< P > &image)

const ImageVariant &	operator<< (const ImageVariant &image)

Public Member Functions inherited from pcl::ImageTransformation
	ImageTransformation ()=default

	ImageTransformation (const ImageTransformation &)=default

virtual	~ImageTransformation ()

template<class P >
GenericImage< P > &	operator>> (GenericImage< P > &image) const

ImageVariant &	operator>> (ImageVariant &image) const

Public Member Functions inherited from pcl::ParallelProcess
	ParallelProcess ()=default

	ParallelProcess (const ParallelProcess &)=default

virtual	~ParallelProcess ()

void	DisableParallelProcessing (bool disable=true) noexcept

void	EnableParallelProcessing (bool enable=true, int maxProcessors=0) noexcept

bool	IsParallelProcessingEnabled () const noexcept

int	MaxProcessors () const noexcept

ParallelProcess &	operator= (const ParallelProcess &)=default

void	SetMaxProcessors (int maxProcessors) noexcept

void	Swap (ParallelProcess &process) noexcept

Protected Member Functions
void	Apply (pcl::ComplexImage &) const override

void	Apply (pcl::DComplexImage &) const override

void	Apply (pcl::DImage &) const override

void	Apply (pcl::Image &) const override

void	Apply (pcl::UInt16Image &) const override

void	Apply (pcl::UInt32Image &) const override

void	Apply (pcl::UInt8Image &) const override

void	Transform (const pcl::ComplexImage &) override

void	Transform (const pcl::DComplexImage &) override

void	Transform (const pcl::DImage &) override

void	Transform (const pcl::Image &) override

void	Transform (const pcl::UInt16Image &) override

void	Transform (const pcl::UInt32Image &) override

void	Transform (const pcl::UInt8Image &) override

Detailed Description

FourierTransform performs out-of-place, discrete Fourier transforms of complex and real two-dimensional images, using fast Fourier transform algorithms.

FourierTransform stores a Fourier transform as either a ComplexImage (32-bit floating point) or a DComplexImage (64-bit floating point). The transform image is transported by an ImageVariant object. 64-bit transforms are created for 64-bit floating point (both real and complex) and 32-bit integer (real) images. For the rest of images a 32-bit transform is used.

See also: InPlaceFourierTransform

Definition at line 226 of file FourierTransform.h.

Constructor & Destructor Documentation

◆ FourierTransform() [1/3]

pcl::FourierTransform::FourierTransform ( )

default

Default constructor.

Creates a FourierTransform object with an empty Fourier transform.

◆ FourierTransform() [2/3]

pcl::FourierTransform::FourierTransform ( const FourierTransform & )

default

Copy constructor.

This constructor copies the Fourier transform in the specified source object. The Fourier transform is an ImageVariant object. This constructor creates an ImageVariant that references the same image as the source object.

◆ FourierTransform() [3/3]

pcl::FourierTransform::FourierTransform ( FourierTransform && )

default

Move constructor.

◆ ~FourierTransform()

pcl::FourierTransform::~FourierTransform ( )

inlineoverride

Destroys a FourierTransform object.

The current Fourier transform, if it exists, is automatically released. The Fourier transform is implemented as an ImageVariant object. If there are no external references to the image transported by the ImageVariant, then it is also destroyed and deallocated.

Definition at line 260 of file FourierTransform.h.

Member Function Documentation

◆ Apply() [1/7]

void pcl::FourierTransform::Apply ( pcl::ComplexImage & image ) const

overrideprotectedvirtual

Applies this transformation to a 32-bit complex image.

Reimplemented from pcl::ImageTransformation.

◆ Apply() [2/7]

void pcl::FourierTransform::Apply ( pcl::DComplexImage & image ) const

overrideprotectedvirtual

Applies this transformation to a 64-bit complex image.

Reimplemented from pcl::ImageTransformation.

◆ Apply() [3/7]

void pcl::FourierTransform::Apply ( pcl::DImage & image ) const

overrideprotectedvirtual

Applies this transformation to a 64-bit floating point image.

Reimplemented from pcl::ImageTransformation.

◆ Apply() [4/7]

void pcl::FourierTransform::Apply ( pcl::Image & image ) const

overrideprotectedvirtual

Applies this transformation to a 32-bit floating point image.

Reimplemented from pcl::ImageTransformation.

◆ Apply() [5/7]

void pcl::FourierTransform::Apply ( pcl::UInt16Image & image ) const

overrideprotectedvirtual

Applies this transformation to a 16-bit unsigned integer image.

Reimplemented from pcl::ImageTransformation.

◆ Apply() [6/7]

void pcl::FourierTransform::Apply ( pcl::UInt32Image & image ) const

overrideprotectedvirtual

Applies this transformation to a 32-bit unsigned integer image.

Reimplemented from pcl::ImageTransformation.

◆ Apply() [7/7]

void pcl::FourierTransform::Apply ( pcl::UInt8Image & image ) const

overrideprotectedvirtual

Applies this transformation to an 8-bit unsigned integer image.

Reimplemented from pcl::ImageTransformation.

◆ Clear()

void pcl::FourierTransform::Clear ( )

inline

Releases the current Fourier transform, if exists.

If there are no external references to the image transported by the internal ImageVariant object, then the transform matrix, which is either a ComplexImage or a DComplexImage object, is destroyed.

Definition at line 350 of file FourierTransform.h.

◆ DFT() [1/2]

ImageVariant& pcl::FourierTransform::DFT ( )

inline

Returns a reference to the Fourier transform in this FourierTransform object.

The Fourier transform is an ImageVariant object. It can transport either a 32-bit (float) or 64-bit (double) complex image, that is, either a ComplexImage or a DComplexImage, depending on the sample type of the transformed image.

Definition at line 303 of file FourierTransform.h.

◆ DFT() [2/2]

const ImageVariant& pcl::FourierTransform::DFT ( ) const

inline

Returns a constant reference to the Fourier transform in this FourierTransform object.

The Fourier transform is an ImageVariant object. It can transport either a 32-bit (float) or 64-bit (double) complex image, that is, either a ComplexImage or a DComplexImage, depending on the sample type of the transformed image.

Definition at line 289 of file FourierTransform.h.

◆ operator*() [1/2]

ImageVariant& pcl::FourierTransform::operator* ( )

inline

A synonym for DFT().

Definition at line 319 of file FourierTransform.h.

◆ operator*() [2/2]

const ImageVariant& pcl::FourierTransform::operator* ( ) const

inline

A synonym for DFT() const.

Definition at line 311 of file FourierTransform.h.

◆ operator=() [1/2]

FourierTransform& pcl::FourierTransform::operator= ( const FourierTransform & )

default

Copy assignment operator. Returns a reference to this object.

This operator copies the Fourier transform in the source object. The Fourier transform is an ImageVariant object. This operator causes the ImageVariant in this object to reference the same image as the source object. If this object already stores a Fourier transform, it is released before assignment.

◆ operator=() [2/2]

FourierTransform& pcl::FourierTransform::operator= ( FourierTransform && )

default

Move assignment operator. Returns a reference to this object.

◆ ReleaseTransform()

ImageVariant pcl::FourierTransform::ReleaseTransform ( )

inline

Transfers ownership of the current Fourier transform to the caller.

Returns a copy of the ImageVariant object that transports the current Fourier transform in this object. Then the internal ImageVariant of this object is released. The transform itself, which is either a ComplexImage or a DComplexImage, will not be destroyed, as the newly created ImageVariant will transport and reference it.

If this object stores no Fourier transform, the returned ImageVariant will be empty (no image transported).

Definition at line 336 of file FourierTransform.h.

◆ Transform() [1/7]

void pcl::FourierTransform::Transform ( const pcl::ComplexImage & image )

overrideprotectedvirtual

Transforms a 32-bit complex image.

Reimplemented from pcl::BidirectionalImageTransformation.

◆ Transform() [2/7]

void pcl::FourierTransform::Transform ( const pcl::DComplexImage & image )

overrideprotectedvirtual

Transforms a 64-bit complex image.

Reimplemented from pcl::BidirectionalImageTransformation.

◆ Transform() [3/7]

void pcl::FourierTransform::Transform ( const pcl::DImage & image )

overrideprotectedvirtual

Transforms a 64-bit floating point image.

Reimplemented from pcl::BidirectionalImageTransformation.

◆ Transform() [4/7]

void pcl::FourierTransform::Transform ( const pcl::Image & image )

overrideprotectedvirtual

Transforms a 32-bit floating point image.

Reimplemented from pcl::BidirectionalImageTransformation.

◆ Transform() [5/7]

void pcl::FourierTransform::Transform ( const pcl::UInt16Image & image )

overrideprotectedvirtual

Transforms a 16-bit unsigned integer image.

Reimplemented from pcl::BidirectionalImageTransformation.

◆ Transform() [6/7]

void pcl::FourierTransform::Transform ( const pcl::UInt32Image & image )

overrideprotectedvirtual

Transforms a 32-bit unsigned integer image.

Reimplemented from pcl::BidirectionalImageTransformation.

◆ Transform() [7/7]

void pcl::FourierTransform::Transform ( const pcl::UInt8Image & image )

overrideprotectedvirtual

Transforms an 8-bit unsigned integer image.

Reimplemented from pcl::BidirectionalImageTransformation.

The documentation for this class was generated from the following file:

FourierTransform.h
