Base class of all two-dimensional images in PCL. More...

#include <AbstractImage.h>

Inheritance diagram for pcl::AbstractImage:

Classes
struct	ThreadData
	Thread synchronization data for status monitoring of parallel image processing tasks. More...

Public Types
using	color_space = ImageColor::color_space

using	selection_stack = Array< ImageSelections >

Public Types inherited from pcl::ImageColor
using	color_space = ColorSpace::value_type

Public Member Functions
	~AbstractImage () override

bool	CanPopSelections () const noexcept

void	DisableRangeClipping (bool disableLow=true, bool disableHigh=true) const noexcept

void	EnableRangeClipping (bool enableLow=true, bool enableHigh=true) const noexcept

int	FirstSelectedChannel () const noexcept

void	GetSelectedChannelRange (int &c0, int &c1) const noexcept

pcl::StatusCallback *	GetStatusCallback () const noexcept

bool	HasAlphaChannels () const noexcept

bool	IsCompletelySelected () const noexcept

bool	IsEmptySelection () const noexcept

bool	IsFullSelection () const noexcept

bool	IsHighRangeClippingEnabled () const noexcept

bool	IsLowRangeClippingEnabled () const noexcept

bool	IsRangeClippingEnabled () const noexcept

int	LastSelectedChannel () const noexcept

int	NumberOfAlphaChannels () const noexcept

size_type	NumberOfAlphaSamples () const noexcept

int	NumberOfNominalChannels () const noexcept

size_type	NumberOfNominalSamples () const noexcept

int	NumberOfSelectedChannels () const noexcept

size_type	NumberOfSelectedPixels () const noexcept

size_type	NumberOfSelectedSamples () const noexcept

int	NumberOfThreads (size_type count, int maxProcessors=0, size_type overheadLimit=16u) const noexcept

int	NumberOfThreadsForRows (int rowCount=0, int rowWidth=0, int maxProcessors=0, size_type overheadLimitPx=1024u) const noexcept

Array< size_type >	OptimalThreadRows (int rowCount=0, int rowWidth=0, int maxProcessors=0, size_type overheadLimitPx=1024u) const noexcept

bool	ParseChannel (int &channel) const noexcept

bool	ParseRect (Rect &rect) const noexcept

bool	ParseSelection (Rect &rect, int &channel) const noexcept

bool	ParseSelection (Rect &rect, int &firstChannel, int &lastChannel) const noexcept

void	PopSelections () const

void	PushSelections () const

double	RangeClipHigh () const noexcept

double	RangeClipLow () const noexcept

void	ResetChannelRange () const noexcept

void	ResetPoint () const noexcept

void	ResetRangeClipping () const noexcept

void	ResetSelection () const noexcept

void	ResetSelections () const noexcept

void	SelectAlphaChannels () const noexcept

void	SelectChannel (int c) const noexcept

void	SelectChannelRange (int c0, int c1) const noexcept

int	SelectedChannel () const noexcept

const Point &	SelectedPoint () const noexcept

const Rect &	SelectedRectangle () const noexcept

ImageSelections &	Selections () const noexcept

void	SelectNominalChannels () const noexcept

void	SelectPoint (const Point &p) const noexcept

void	SelectPoint (int x, int y) const noexcept

void	SelectRectangle (const Point &p0, const Point &p1) const noexcept

void	SelectRectangle (const Rect &r) const noexcept

void	SelectRectangle (int x0, int y0, int x1, int y1) const noexcept

void	SetRangeClipHigh (double clipHigh) const noexcept

void	SetRangeClipLow (double clipLow) const noexcept

void	SetRangeClipping (double clipLow, double clipHigh) const noexcept

void	SetStatusCallback (pcl::StatusCallback *callback) const noexcept

StatusMonitor &	Status () const noexcept

pcl::StatusCallback *	StatusCallback () const noexcept

Public Member Functions inherited from pcl::ImageGeometry
Rect	Bounds () const noexcept

template<typename T >
bool	Clip (pcl::GenericPoint< T > &p) const noexcept

template<typename T >
bool	Clip (pcl::GenericRectangle< T > &r) const noexcept

template<typename T >
bool	Clip (T &x, T &y) const noexcept

template<typename T >
bool	Clip (T &x0, T &y0, T &x1, T &y1) const noexcept

int	Height () const noexcept

template<typename T >
bool	Includes (const GenericPoint< T > &p) const noexcept

template<typename T >
bool	Includes (const GenericRectangle< T > &r) const noexcept

template<typename T >
bool	Includes (T x, T y) const noexcept

template<typename T >
bool	Includes (T x0, T y0, T x1, T y1) const noexcept

template<typename T >
bool	Intersects (const pcl::GenericRectangle< T > &r) const noexcept

template<typename T >
bool	Intersects (T x0, T y0, T x1, T y1) const noexcept

bool	IsEmpty () const noexcept

bool	IsValidChannelIndex (int c) const noexcept

int	LastChannel () const noexcept

int	NumberOfChannels () const noexcept

size_type	NumberOfPixels () const noexcept

size_type	NumberOfSamples () const noexcept

distance_type	PixelOffset (int x, int y) const noexcept

distance_type	RowOffset (int y) const noexcept

int	Width () const noexcept

Public Member Functions inherited from pcl::ImageColor
String	ChannelId (int c) const noexcept

color_space	ColorSpace () const noexcept

bool	IsColor () const noexcept

const RGBColorSystem &	RGBWorkingSpace () const noexcept

virtual void	SetRGBWorkingSpace (const RGBColorSystem &RGBWS)

Public Member Functions inherited from pcl::ParallelProcess
	ParallelProcess ()=default

	ParallelProcess (const ParallelProcess &)=default

virtual	~ParallelProcess ()

void	DisableParallelProcessing (bool disable=true) noexcept

void	EnableParallelProcessing (bool enable=true, int maxProcessors=0) noexcept

bool	IsParallelProcessingEnabled () const noexcept

int	MaxProcessors () const noexcept

ParallelProcess &	operator= (const ParallelProcess &)=default

void	SetMaxProcessors (int maxProcessors) noexcept

void	Swap (ParallelProcess &process) noexcept

Static Public Member Functions
template<class thread >
static void	RunThreads (ReferenceArray< thread > &threads, ThreadData &data, bool useAffinity=true)

Static Public Member Functions inherited from pcl::ImageColor
static const RGBColorSystem &	DefaultRGBWorkingSpace () noexcept

static void	ResetDefaultRGBWorkingSpace ()

static void	SetDefaultRGBWorkingSpace (const RGBColorSystem &RGBWS)

Detailed Description

AbstractImage encapsulates ImageGeometry and ImageColor into a single class employed as the root base class for all two-dimensional images in PCL.

This class provides fundamental properties and functionality that are independent on the particular data types used to store and manage pixel samples.

AbstractImage also provides a simple selection mechanism consisting of a rectangular selection (also known as region of interest, or ROI), a channel range, and an anchor point. Image selections can be stored in a local stack for quick retrieval (see PushSelections() and PopSelections()). Note that for practical reasons, image selections have been implemented as mutable data members internally, so modifying selections is possible for immutable AbstractImage instances.

Finally, AbstractImage provides function and data members to manage status monitoring of images. The status monitoring mechanism can be used to provide feedback to the user about the progress of a running process. Status monitoring is implemented through the StatusMonitor and StatusCallback classes. See the Status(), StatusCallback() and SetStatusCallback() member functions for more information.

See also: ImageGeometry, ImageColor, GenericImage, ImageVariant

Definition at line 118 of file AbstractImage.h.

Member Typedef Documentation

◆ color_space

using pcl::AbstractImage::color_space = ImageColor::color_space

An enumerated type that represents the set of supported color spaces. Valid constants for this enumeration are defined in the ColorSpace namespace.

Definition at line 134 of file AbstractImage.h.

◆ selection_stack

using pcl::AbstractImage::selection_stack = Array<ImageSelections>

A type used to implement a stack of stored image selections.

Definition at line 127 of file AbstractImage.h.

Constructor & Destructor Documentation

◆ ~AbstractImage()

pcl::AbstractImage::~AbstractImage ( )

inlineoverride

Virtual destructor.

Definition at line 139 of file AbstractImage.h.

Member Function Documentation

◆ CanPopSelections()

bool pcl::AbstractImage::CanPopSelections ( ) const

inlinenoexcept

Returns true iff one or more selections have been pushed to the internal selection stack, that is, if the PopSelections() function can be called to restore them.

Definition at line 674 of file AbstractImage.h.

◆ DisableRangeClipping()

void pcl::AbstractImage::DisableRangeClipping	(	bool	disableLow = `true`,
		bool	disableHigh = `true`
	)		const

inlinenoexcept

Disables range clippings for statistical calculations.

See IsRangeClippingEnabled() for more information on range clipping.

Definition at line 529 of file AbstractImage.h.

◆ EnableRangeClipping()

void pcl::AbstractImage::EnableRangeClipping	(	bool	enableLow = `true`,
		bool	enableHigh = `true`
	)		const

inlinenoexcept

Enables range clippings for statistical calculations.

See IsRangeClippingEnabled() for more information on range clipping.

Definition at line 518 of file AbstractImage.h.

◆ FirstSelectedChannel()

int pcl::AbstractImage::FirstSelectedChannel ( ) const

inlinenoexcept

Returns the channel index of the first selected channel.

Definition at line 282 of file AbstractImage.h.

◆ GetSelectedChannelRange()

void pcl::AbstractImage::GetSelectedChannelRange	(	int &	c0,
		int &	c1
	)		const

inlinenoexcept

Copies the first and last channel indices of the current channel selection to the specified variables.

Parameters

[out]	c0	Index of the first selected channel.
[out]	c1	Index of the last selected channel.

Definition at line 302 of file AbstractImage.h.

◆ GetStatusCallback()

pcl::StatusCallback* pcl::AbstractImage::GetStatusCallback ( ) const

inlinenoexcept

Deprecated:: This function has been deprecated. It is included in this version of PCL to keep existing code functional. Use StatusCallback() in newly produced code.

Definition at line 819 of file AbstractImage.h.

◆ HasAlphaChannels()

bool pcl::AbstractImage::HasAlphaChannels ( ) const

inlinenoexcept

Returns true iff this image has one or more alpha channels.

Alpha channels are those in excess of nominal channels, e.g. a fourth channel in a RGB image, or a second channel in a grayscale image.

Definition at line 167 of file AbstractImage.h.

References pcl::ColorSpace::NumberOfNominalChannels().

◆ IsCompletelySelected()

bool pcl::AbstractImage::IsCompletelySelected ( ) const

inlinenoexcept

Returns true if this image is completely selected; false if it is only partially selected.

In a completely selected image, the current rectangular selection includes the whole image, and the current channel range selection comprises all existing channels, including nominal and alpha channels.

Definition at line 428 of file AbstractImage.h.

Referenced by pcl::GenericImage< UInt8PixelTraits >::GenericImage().

◆ IsEmptySelection()

bool pcl::AbstractImage::IsEmptySelection ( ) const

inlinenoexcept

Returns true iff the current selection is empty, i.e. if its area is zero.

Definition at line 395 of file AbstractImage.h.

◆ IsFullSelection()

bool pcl::AbstractImage::IsFullSelection ( ) const

inlinenoexcept

Returns true iff the current rectangular selection comprises the entire image.

Definition at line 404 of file AbstractImage.h.

◆ IsHighRangeClippingEnabled()

bool pcl::AbstractImage::IsHighRangeClippingEnabled ( ) const

inlinenoexcept

Returns true iff range clipping is currently enabled for the high clipping bound. When this is true, pixel samples with values greater than or equal to the high clipping bound (as reported by RangeClipHigh() ) will be rejected for statistical calculations.

See IsRangeClippingEnabled() for more information on range clipping.

Definition at line 508 of file AbstractImage.h.

◆ IsLowRangeClippingEnabled()

bool pcl::AbstractImage::IsLowRangeClippingEnabled ( ) const

inlinenoexcept

Returns true iff range clipping is currently enabled for the low clipping bound. When this is true, pixel samples with values less than or equal to the low clipping bound (as reported by RangeClipLow() ) will be rejected for statistical calculations.

See IsRangeClippingEnabled() for more information on range clipping.

Definition at line 495 of file AbstractImage.h.

◆ IsRangeClippingEnabled()

bool pcl::AbstractImage::IsRangeClippingEnabled ( ) const

inlinenoexcept

Returns true iff range clipping is currently enabled for this image.

When range clipping is enabled, pixel samples outside the current clipping range:

( RangeClipLow(), RangeClipHigh() )

are ignored by statistics calculation routines. Note that range bounds are always excluded, since the range is open on both sides. The clipping range is always defined in the normalized [0,1] range for all pixel sample data types; the necessary conversions are performed transparently.

When range clipping is disabled, the clipping range is ignored and all pixel samples are considered for statistical calculations.

To make it more flexible, range clipping can be enabled/disabled separately for the low and high bounds.

The default clipping range is the normalized (0,1) range. Range clipping is disabled by default.

Definition at line 482 of file AbstractImage.h.

◆ LastSelectedChannel()

int pcl::AbstractImage::LastSelectedChannel ( ) const

inlinenoexcept

Returns the channel index of the last selected channel.

Definition at line 290 of file AbstractImage.h.

◆ NumberOfAlphaChannels()

int pcl::AbstractImage::NumberOfAlphaChannels ( ) const

inlinenoexcept

Returns the number of existing alpha channels in this image.

Definition at line 176 of file AbstractImage.h.

References pcl::ColorSpace::NumberOfNominalChannels().

◆ NumberOfAlphaSamples()

size_type pcl::AbstractImage::NumberOfAlphaSamples ( ) const

inlinenoexcept

Returns the number of existing alpha samples in this image. The returned value is equal to the number of alpha channels multiplied by the area of the image in square pixels.

Definition at line 187 of file AbstractImage.h.

◆ NumberOfNominalChannels()

int pcl::AbstractImage::NumberOfNominalChannels ( ) const

inlinenoexcept

Returns the number of nominal channels corresponding to the current color space of this image.

Definition at line 147 of file AbstractImage.h.

References pcl::ColorSpace::NumberOfNominalChannels().

◆ NumberOfNominalSamples()

size_type pcl::AbstractImage::NumberOfNominalSamples ( ) const

inlinenoexcept

Returns the number of nominal samples in this image. This is equal to the area in square pixels multiplied by the number of nominal channels.

Definition at line 156 of file AbstractImage.h.

References pcl::ColorSpace::NumberOfNominalChannels().

◆ NumberOfSelectedChannels()

int pcl::AbstractImage::NumberOfSelectedChannels ( ) const

inlinenoexcept

Returns the number of selected channels.

Definition at line 274 of file AbstractImage.h.

Referenced by pcl::ImageInfo::ImageInfo().

◆ NumberOfSelectedPixels()

size_type pcl::AbstractImage::NumberOfSelectedPixels ( ) const

inlinenoexcept

Returns the number of selected pixels. This is the area in square pixels of the current selection rectangle.

Definition at line 442 of file AbstractImage.h.

◆ NumberOfSelectedSamples()

size_type pcl::AbstractImage::NumberOfSelectedSamples ( ) const

inlinenoexcept

Returns the number of selected samples. This is the area in square pixels of the current selection rectangle multiplied by the number of selected channels.

Definition at line 455 of file AbstractImage.h.

◆ NumberOfThreads()

int pcl::AbstractImage::NumberOfThreads	(	size_type	count,
		int	maxProcessors = `0`,
		size_type	overheadLimit = `16u`
	)		const

inlinenoexcept

Returns the maximum number of threads that this image can use concurrently to process a set of items.

Parameters

count	Number of processing units. A processing unit can be a single pixel, a row of pixels, or any suitable item, according to the task being performed by the caller.
maxProcessors	If a value greater than zero is specified, it is the maximum number of processors allowed, which takes precedence over the current limit set for this image (see the MaxProcessors() and SetMaxProcessors() member functions). If zero or a negative value is specified, it is ignored and the current MaxProcessors() limit is applied.
overheadLimit	Thread overhead limit in processing units. The function returns a maximum number of threads such that no thread would have to process less processing units than this value. The default overhead limit is 16 processing units.

This function takes into account if parallel processing is currently enabled for this image, as well as the maximum number of processors allowed for the calling process.

See also: Thread::NumberOfThreads()

Definition at line 859 of file AbstractImage.h.

◆ NumberOfThreadsForRows()

int pcl::AbstractImage::NumberOfThreadsForRows	(	int	rowCount = `0`,
		int	rowWidth = `0`,
		int	maxProcessors = `0`,
		size_type	overheadLimitPx = `1024u`
	)		const

inlinenoexcept

Returns the maximum number of threads that this image can use concurrently to process a set of pixel rows.

Parameters

rowCount	Number of pixel rows to be processed. If zero or a negative value is specified, the height of the image in pixels will be used. The default value is zero.
rowWidth	Width in pixels of the ROI being processed. If zero or a negative value is specified, the width of the image in pixels is used. The default value is zero.
maxProcessors	If a value greater than zero is specified, it is the maximum number of processors allowed, which takes precedence over the current limit set for this image (see the MaxProcessors() and SetMaxProcessors() member functions). If zero or a negative value is specified, it is ignored and the current MaxProcessors() limit is applied. The default value is zero.
overheadLimitPx	Thread overhead limit in pixels. The function will calculate the minimum number of pixel rows that a single thread can process, based on this value and on the specified rowWidth (or the image's width if zero is passed for that parameter). The default overhead limit is 1024 pixels.

This function takes into account if parallel processing is currently enabled for this image, as well as the maximum number of processors allowed for the calling process.

See also: NumberOfThreads(), Thread::NumberOfThreads()

Definition at line 897 of file AbstractImage.h.

References pcl::Max().

◆ OptimalThreadRows()

Array<size_type> pcl::AbstractImage::OptimalThreadRows	(	int	rowCount = `0`,
		int	rowWidth = `0`,
		int	maxProcessors = `0`,
		size_type	overheadLimitPx = `1024u`
	)		const

inlinenoexcept

Returns a list of per-thread counts optimized for parallel processing of a set of pixel rows.

Parameters

rowCount	Number of pixel rows to be processed. If zero or a negative value is specified, the height of the image in pixels will be used. The default value is zero.
rowWidth	Width in pixels of the ROI being processed. If zero or a negative value is specified, the width of the image in pixels is used. The default value is zero.
maxProcessors	If a value greater than zero is specified, it is the maximum number of processors allowed, which takes precedence over the current limit set for this image (see the MaxProcessors() and SetMaxProcessors() member functions). If zero or a negative value is specified, it is ignored and the current MaxProcessors() limit is applied. The default value is zero.
overheadLimitPx	Thread overhead limit in pixels. The function will calculate the minimum number of pixel rows that a single thread can process, based on this value and on the specified rowWidth (or the image's width if zero is passed for that parameter). The default overhead limit is 1024 pixels.

This function takes into account if parallel processing is currently enabled for this image, as well as the maximum number of processors allowed for the calling process.

This function returns a dynamic array of unsigned integers, where each element is the number of pixel rows that the corresponding thread should process in order to make an optimal usage of the processor resources currently available. The length of the returned array is the maximum number of threads that the calling process should execute concurrently to process the specified number of pixel rows, with the specified overhead limit and maximum number of processors.

See also: Thread::OptimalThreadLoads()

Definition at line 944 of file AbstractImage.h.

References pcl::Max(), and pcl::Thread::OptimalThreadLoads().

◆ ParseChannel()

bool pcl::AbstractImage::ParseChannel ( int & channel ) const

inlinenoexcept

Interprets a channel index as a parameter to define a pixel sample selection.

Parameters

[in,out] channel If a negative channel index is specified, this parameter will be replaced with the currently selected channel index in this image.

Returns true iff the output channel index is valid.

Definition at line 714 of file AbstractImage.h.

◆ ParseRect()

bool pcl::AbstractImage::ParseRect ( Rect & rect ) const

inlinenoexcept

Interprets the coordinates of a rectangle as a parameter to define a pixel selection.

Parameters

[in,out] rect If this rectangle is empty (defining either a point or a line), this function sets it to the current rectangular selection in this image. If this rectangle is nonempty, this function constrains its coordinates to stay within image boundaries.

Returns true iff the output rectangle is nonempty.

Definition at line 691 of file AbstractImage.h.

◆ ParseSelection() [1/2]

bool pcl::AbstractImage::ParseSelection	(	Rect &	rect,
		int &	channel
	)		const

inlinenoexcept

Interprets the coordinates of a rectangle and one channel index as parameters to define a pixel sample selection.

Parameters

[in,out]	rect	If this rectangle is empty (defining either a point or a line), this function sets it to the current rectangular selection in this image. If this rectangle is nonempty, this function constrains its coordinates to stay within image boundaries.
[in,out]	channel	If a negative channel index is specified, this parameter will be replaced with the currently selected channel index in this image.

Returns true iff the output rectangle is nonempty and the output channel index is valid.

Definition at line 789 of file AbstractImage.h.

◆ ParseSelection() [2/2]

bool pcl::AbstractImage::ParseSelection	(	Rect &	rect,
		int &	firstChannel,
		int &	lastChannel
	)		const

inlinenoexcept

Interprets the coordinates of a rectangle and two channel indexes as parameters to define a pixel sample selection.

Parameters

[in,out]	rect	If this rectangle is empty (defining either a point or a line), this function sets it to the current rectangular selection in this image. If this rectangle is nonempty, this function constrains its coordinates to stay within image boundaries.
[in,out]	firstChannel	If a negative channel index is specified, this parameter will be replaced with the first channel index of the current channel range selection in this image.
[in,out]	lastChannel	If a negative channel index is specified, this parameter will be replaced with the last channel index of the current channel range selection in this image.

Returns true iff the output rectangle is nonempty and the output channel range is valid. When true is returned, this function ensures that firstChannel ≤ lastChannel.

Definition at line 752 of file AbstractImage.h.

Referenced by pcl::GenericMatrix< coefficient >::FromImage().

◆ PopSelections()

void pcl::AbstractImage::PopSelections ( ) const

inline

Restores and pops (removes) the current selections (rectangular area, channel range, anchor point and range clipping) from the internal selection stack.

If no selections have been previously pushed to the internal selection stack, this function is ignored.

Definition at line 659 of file AbstractImage.h.

◆ PushSelections()

void pcl::AbstractImage::PushSelections ( ) const

inline

Saves the current selections (rectangular area, channel range, anchor point and range clipping), pushing them to the internal selection stack.

Definition at line 646 of file AbstractImage.h.

◆ RangeClipHigh()

double pcl::AbstractImage::RangeClipHigh ( ) const

inlinenoexcept

Returns the upper bound of the current clipping range.

See IsRangeClippingEnabled() for more information on range clipping.

Definition at line 550 of file AbstractImage.h.

◆ RangeClipLow()

double pcl::AbstractImage::RangeClipLow ( ) const

inlinenoexcept

Returns the lower bound of the current clipping range.

See IsRangeClippingEnabled() for more information on range clipping.

Definition at line 540 of file AbstractImage.h.

◆ ResetChannelRange()

void pcl::AbstractImage::ResetChannelRange ( ) const

inlinenoexcept

Resets the channel range selection to include all existing channels (all nominal and alpha channels) in this image.

Definition at line 265 of file AbstractImage.h.

References pcl::Max().

◆ ResetPoint()

void pcl::AbstractImage::ResetPoint ( ) const

inlinenoexcept

Resets the anchor point to the origin of image coordinates, i.e to x=y=0.

Definition at line 330 of file AbstractImage.h.

◆ ResetRangeClipping()

void pcl::AbstractImage::ResetRangeClipping ( ) const

inlinenoexcept

Resets the range clipping parameters:

Clipping range lower bound = 0.0 Clipping range upper bound = 1.0 Range clipping disabled

Definition at line 601 of file AbstractImage.h.

◆ ResetSelection()

void pcl::AbstractImage::ResetSelection ( ) const

inlinenoexcept

Resets the rectangular selection to include the entire image boundaries.

Definition at line 387 of file AbstractImage.h.

◆ ResetSelections()

void pcl::AbstractImage::ResetSelections ( ) const

inlinenoexcept

Resets all image selections to default values:

All channels are selected, including nominal and alpha channels.
The anchor point is located at {0,0}, that is the upper left corner.
The rectangular selection is set to comprise the entire image.
The clipping range is set to [0,1].
Range clipping is disabled.

Calling this member function is equivalent to:

ResetChannelRange();
ResetPoint();
ResetSelection();
ResetRangeClipping();

Definition at line 626 of file AbstractImage.h.

◆ RunThreads()

template<class thread >

static void pcl::AbstractImage::RunThreads	(	ReferenceArray< thread > &	threads,
		ThreadData &	data,
		bool	useAffinity = `true`
	)

inlinestatic

Runs a set of threads with synchronized status monitoring and task abortion.

Parameters

threads	Reference to a ReferenceArray container of threads. ReferenceArray contains pointers to objects and allows direct iteration and access by reference. It cannot contain null pointers. Each ReferenceArray element must be an instance of a derived class of Thread, where a reimplemented Thread::Run() member function should perform the required parallel processing.
data	Reference to a ThreadData object for synchronization.
useAffinity	If (1) this parameter is true, (2) the threads array contains two or more threads, and (3) this function is being called from the root thread (see Thread::IsRootThread()), then each thread will be run with its affinity set to a single processor (on systems that support thread processor affinity). If one or more of the three conditions above is false, the thread(s) will be run without forcing their processor affinities.

When the threads array contains more than one thread, this static member function launches the threads in sequence and waits until all threads have finished execution. While the threads are running, the status member of ThreadData is incremented regularly to perform the process monitoring task. This also ensures that the graphical interface remains responsive during the whole process.

When the threads array contains just one thread, this member function simply calls the Thread::Run() member function for the unique thread in the array, so no additional parallel execution is performed in the single-threaded case. If the reimplemented Thread::Run() member function uses standard PCL macros to perform the thread monitoring task (see the INIT_THREAD_MONITOR() and UPDATE_THREAD_MONITOR() macros), all possible situations will be handled correctly and automatically.

For normal execution of multiple concurrent threads with maximum performance, the useAffinity parameter should be true in order to minimize cache invalidations due to processor reassignments of running threads. However, there are cases where forcing processor affinities can be counterproductive. An example is real-time previewing of intensive processes requiring continuous GUI updates. In these cases, disabling processor affinity can help to keep the GUI responsive with the required granularity.

The threads can be aborted asynchronously with the standard Thread::Abort() mechanism, or through StatusMonitor/StatusCallback. If one or more threads are aborted, this function destroys all the threads by calling ReferenceArray::Destroy(), and then throws a ProcessAborted exception. In the single-threaded case, if the reimplemented Thread::Run() member function throws an exception, the array is also destroyed and the exception is thrown. Otherwise, if all threads complete execution normally, the threads array is left intact and the function returns. The caller is then responsible for destroying the threads when appropriate.

Warning: For parallel execution of two or more threads, do not call this function from a high-priority thread. Doing so can lead to a significant performance loss because this function will consume too much processing time just for process monitoring. In general, you should call this function from normal priority threads.

Definition at line 1072 of file AbstractImage.h.

References pcl::ReferenceArray< T, A >::Begin(), pcl::AbstractImage::ThreadData::count, pcl::ReferenceArray< T, A >::Destroy(), pcl::ReferenceArray< T, A >::End(), pcl::ReferenceArray< T, A >::IsEmpty(), pcl::Thread::IsRootThread(), pcl::ReferenceArray< T, A >::Length(), pcl::AbstractImage::ThreadData::mutex, pcl::AbstractImage::ThreadData::numThreads, pcl::StatusMonitor::RefreshRate(), pcl::AbstractImage::ThreadData::status, pcl::AbstractImage::ThreadData::total, pcl::Mutex::TryLock(), and pcl::Mutex::Unlock().

◆ SelectAlphaChannels()

void pcl::AbstractImage::SelectAlphaChannels ( ) const

inlinenoexcept

Sets the current channel range selection to include the existing alpha channels only, excluding the nominal channels.

Note: If this image has no alpha channels, this function selects the last nominal channel. The channel range selection cannot be empty by design.

Definition at line 254 of file AbstractImage.h.

References pcl::ColorSpace::NumberOfNominalChannels().

◆ SelectChannel()

void pcl::AbstractImage::SelectChannel ( int c ) const

inlinenoexcept

Selects a single channel.

Parameters

c	Channel index, 0 ≤ c < n, where n is the total number of channels in this image, including alpha channels.

Definition at line 200 of file AbstractImage.h.

◆ SelectChannelRange()

void pcl::AbstractImage::SelectChannelRange	(	int	c0,
		int	c1
	)		const

inlinenoexcept

Selects a range of channels by their channel indices. The selected range includes the two channels specified.

Parameters

c0	Index of the first channel to select.
c1	Index of the last channel to select.

Definition at line 227 of file AbstractImage.h.

◆ SelectedChannel()

int pcl::AbstractImage::SelectedChannel ( ) const

inlinenoexcept

Returns the index of the currently selected channel.

If the current channel selection includes more than one channel, this function returns the index of the first selected channel.

This function is a convenience synonym for FirstSelectedChannel().

Definition at line 215 of file AbstractImage.h.

◆ SelectedPoint()

const Point& pcl::AbstractImage::SelectedPoint ( ) const

inlinenoexcept

Returns the current anchor point.

Definition at line 338 of file AbstractImage.h.

◆ SelectedRectangle()

const Rect& pcl::AbstractImage::SelectedRectangle ( ) const

inlinenoexcept

Returns the current rectangular selection.

Definition at line 415 of file AbstractImage.h.

Referenced by pcl::ImageInfo::ImageInfo().

◆ Selections()

ImageSelections& pcl::AbstractImage::Selections ( ) const

inlinenoexcept

Returns a reference to the internal ImageSelections object in this image.

Definition at line 637 of file AbstractImage.h.

◆ SelectNominalChannels()

void pcl::AbstractImage::SelectNominalChannels ( ) const

inlinenoexcept

Sets the current channel range selection to include all nominal channels exclusively, excluding alpha channels.

Definition at line 240 of file AbstractImage.h.

References pcl::ColorSpace::NumberOfNominalChannels().

◆ SelectPoint() [1/2]

void pcl::AbstractImage::SelectPoint ( const Point & p ) const

inlinenoexcept

Selects a new anchor point p in image coordinates.

Definition at line 322 of file AbstractImage.h.

◆ SelectPoint() [2/2]

void pcl::AbstractImage::SelectPoint	(	int	x,
		int	y
	)		const

inlinenoexcept

Selects an anchor point by its separate image coordinates.

Parameters

x	Horizontal coordinate of the new anchor point.
y	Vertical coordinate of the new anchor point.

Definition at line 314 of file AbstractImage.h.

◆ SelectRectangle() [1/3]

void pcl::AbstractImage::SelectRectangle	(	const Point &	p0,
		const Point &	p1
	)		const

inlinenoexcept

Defines the current rectangular selection by its separate corner points in image coordinates.

Parameters

p0	Position of the upper left corner of the new selection.
p1	Position of the lower right corner of the new selection.

Definition at line 370 of file AbstractImage.h.

◆ SelectRectangle() [2/3]

void pcl::AbstractImage::SelectRectangle ( const Rect & r ) const

inlinenoexcept

Defines the current rectangular selection as the specified rectangle r in image coordinates.

Definition at line 379 of file AbstractImage.h.

◆ SelectRectangle() [3/3]

void pcl::AbstractImage::SelectRectangle	(	int	x0,
		int	y0,
		int	x1,
		int	y1
	)		const

inlinenoexcept

Defines the current rectangular selection by its separate image coordinates.

Parameters

x0,y0	Upper left corner coordinates (horizontal, vertical) of the new rectangular selection.
x1,y1	Lower right corner coordinates (horizontal, vertical) of the new rectangular selection.

The resulting selection is constrained to stay within the image boundaries.

Definition at line 356 of file AbstractImage.h.

◆ SetRangeClipHigh()

void pcl::AbstractImage::SetRangeClipHigh ( double clipHigh ) const

inlinenoexcept

Sets the upper bound of the clipping range.

See IsRangeClippingEnabled() for more information on range clipping.

Definition at line 572 of file AbstractImage.h.

References pcl::Swap().

◆ SetRangeClipLow()

void pcl::AbstractImage::SetRangeClipLow ( double clipLow ) const

inlinenoexcept

Sets the lower bound of the clipping range.

See IsRangeClippingEnabled() for more information on range clipping.

Definition at line 560 of file AbstractImage.h.

References pcl::Swap().

◆ SetRangeClipping()

void pcl::AbstractImage::SetRangeClipping	(	double	clipLow,
		double	clipHigh
	)		const

inlinenoexcept

Sets the lower and upper bounds of the clipping range and enables range clipping (both low and high clipping bounds), in a single function call.

See IsRangeClippingEnabled() for more information on range clipping.

Definition at line 585 of file AbstractImage.h.

References pcl::Swap().

◆ SetStatusCallback()

void pcl::AbstractImage::SetStatusCallback ( pcl::StatusCallback * callback ) const

inlinenoexcept

Specifies the address of an object that will be used to perform status monitoring callbacks for this image.

Definition at line 828 of file AbstractImage.h.

◆ Status()

StatusMonitor& pcl::AbstractImage::Status ( ) const

inlinenoexcept

Returns a reference to the status monitoring object associated with this image.

Definition at line 800 of file AbstractImage.h.

◆ StatusCallback()

pcl::StatusCallback* pcl::AbstractImage::StatusCallback ( ) const

inlinenoexcept

Returns the address of the status monitoring callback object currently selected for this image.

Definition at line 809 of file AbstractImage.h.

The documentation for this class was generated from the following file:

AbstractImage.h

Classes

Public Types

Public Member Functions

Static Public Member Functions

Detailed Description

Member Typedef Documentation

◆ color_space

◆ selection_stack

Constructor & Destructor Documentation

◆ ~AbstractImage()

Member Function Documentation

◆ CanPopSelections()

◆ DisableRangeClipping()

◆ EnableRangeClipping()

◆ FirstSelectedChannel()

◆ GetSelectedChannelRange()

◆ GetStatusCallback()

◆ HasAlphaChannels()

◆ IsCompletelySelected()

◆ IsEmptySelection()

◆ IsFullSelection()

◆ IsHighRangeClippingEnabled()

◆ IsLowRangeClippingEnabled()

◆ IsRangeClippingEnabled()

◆ LastSelectedChannel()

◆ NumberOfAlphaChannels()

◆ NumberOfAlphaSamples()

◆ NumberOfNominalChannels()

◆ NumberOfNominalSamples()

◆ NumberOfSelectedChannels()

◆ NumberOfSelectedPixels()

◆ NumberOfSelectedSamples()

◆ NumberOfThreads()

◆ NumberOfThreadsForRows()

◆ OptimalThreadRows()

◆ ParseChannel()

◆ ParseRect()

◆ ParseSelection() [1/2]

◆ ParseSelection() [2/2]

◆ PopSelections()

◆ PushSelections()

◆ RangeClipHigh()

◆ RangeClipLow()

◆ ResetChannelRange()

◆ ResetPoint()

◆ ResetRangeClipping()

◆ ResetSelection()

◆ ResetSelections()

◆ RunThreads()

◆ SelectAlphaChannels()

◆ SelectChannel()

◆ SelectChannelRange()

◆ SelectedChannel()

◆ SelectedPoint()

◆ SelectedRectangle()

◆ Selections()

◆ SelectNominalChannels()

◆ SelectPoint() [1/2]

◆ SelectPoint() [2/2]

◆ SelectRectangle() [1/3]

◆ SelectRectangle() [2/3]

◆ SelectRectangle() [3/3]

◆ SetRangeClipHigh()

◆ SetRangeClipLow()

◆ SetRangeClipping()

◆ SetStatusCallback()

◆ Status()

◆ StatusCallback()
